11.7.54 Display units (4.5.2)

Fig. 100 Display units
Description
In this display, it is possible to select units for the various
parameters.
For the basic setting, it is possible to select between SI and US
units. It is also possible to select other units for the individual
parameters.
Setting range
Basic setting
Parameter
Pressure
Differential pressure
Head
Level
Flow rate
Volume
Specific energy kWh/m
Temperature
Differential temperature
Power
Energy
If units are changed from SI to US or vice versa,
all individually set parameters will be changed to
Note
the basic setting in question.
Setting via control panel
1. Mark the Settings menu with
2. Mark Functions, CU 351 with
3. Mark Units with or
4. Select the unit with or
A check mark shows that the unit has been selected.
5. Select the measuring parameter with
to open the display for the measuring parameter.
See the example.
56
Possible units
SI US
kPa, MPa, mbar,
bar psi
bar, m, psi
kPa, MPa, mbar,
m psi
bar, m, psi
m ft m, cm, ft, in
m ft m, cm, ft, in
3 3
m /s, m /h, l/s, gpm,
3
m /h gpm
3 3
yd /s, yd /min, yd
3 3
m gal l, m , gal, yd
3
kWh/m , Wh/gal,
3
Wh/gal Wh/kgal, BTU/gal,
HPh/gal
°C °F K, °C, °F
K K K
kW HP W, kW, MW, HP
kWh, MWh, BTU,
kWh kWh
HPh
.
or , and press
, and press .
, and save with .
or , and press
Fig. 101 Example of selection of display units
6. Select the unit with
A check mark shows that the unit has been selected.
Factory setting
The setting is done in the start-up wizard and depends on the
application.
3
/h
3
.
or , and save with .
