11.7.25 Emergency run (4.3.5)

Fig. 66 Emergency run
Description
This function is used in booster applications. When this function
has been activated, the pumps will keep running regardless of
warnings or alarms. The pumps will run according to a setpoint
set specifically for this function.
In case of sensor fault, both main and standby
Caution
pumps will run at 100 % speed!
Setting range
• Setting of digital input (11.7.26 Digital inputs (4.3.7)).
• Setting of digital output (11.7.31 Digital outputs (4.3.9)).
• Setting of setpoint for emergency run.
Setting via control panel
1. Mark the Settings menu with
2. Mark Secondary functions with
3. Mark Emergency run with
4. Mark Go to setting of digital input with
press .
5. Select a digital input with
6. Mark Emergency run with
7. Return by pressing
8. Mark Go to setting of digital output with
press .
9. Select a digital output with
10. Mark Emergency run with
11. Return by pressing
12. Mark Setpoint, emergency run with
13. Set the value with or
When this function has been set as described
above, it can also be activated via the display
Note
System operating mode (2.1.1).
40
or , and press
or , and press
or , and
or , and press
or , and save with
twice.
or
or , and press
or , and save with
twice.
or .
, and save with .

11.7.26 Digital inputs (4.3.7)

Fig. 67 Digital inputs
Description
In this menu, the digital inputs of the CU 351 can be set. Each
input, except DI1, can be activated and related to a certain
function.
As standard, the Control MPC has three digital inputs. If the
Control MPC incorporates an IO 351B module (option), the
number of digital inputs is 12.
In the display, all digital inputs are shown so that their physical
position in the Control MPC can be identified.
Example
DI1 (IO 351-41), [10]:
DI1:
(IO 351-41):
[10]:
.
. For further information on the connection of various digital inputs,
see the wiring diagram supplied with the control cabinet.
Setting range
.
The digital input to be set is selected in the display Digital inputs
.
(4.3.7).
DI1 (CU 351) cannot be selected.
Note
, and
Setting via control panel
.
1. Mark the Settings menu with
.
2. Mark Secondary functions with
3. Mark Digital inputs
4. Select the digital input with
Digital input No 1
IO 351, GENIbus number 41
Terminal No 10
.
or
or , and press
or , and press
, and press .
.
.
