11.7.55 Date and time (4.5.3)

Fig. 102 Date and time
Description
In this display, date and time are set as well as how they are to be
shown in the display.
The clock has a built-in rechargeable voltage supply which can
supply the clock for up to 20 days if the voltage supply to the
Control MPC is interrupted.
If the clock is without voltage for more than 20 days, it must be
set again.
Setting range
The date can be set as day, month and year. The time can be set
as a 24-hour clock showing hours and minutes.
There are three formats.
Examples of format
2005-09-27 13:49
27-09-2005 13:49
9/27/2005 1:49pm
It is also possible to select if Sunday or Monday is to be the first
day of week.
Setting via control panel
1. Mark the Settings menu with
2. Mark Functions, CU 351 with
3. Mark Date and time with
4. Mark Day, Month and Year with
with or . Save with
5. Mark Hours and Minutes with
with or . Save with
6. Select the format with
7. Mark First day of week, Sunday or Monday with
and save with
Factory setting
Local time.
If the Control MPC has been without voltage for
more than 20 days since it left the factory, the
clock may have returned to the original setting:
01-01-2005 0:00.
Note
Date and time may have been changed during the
setting of Control MPC.
There is no automatic changeover to/from
daylight-saving time.
.
or , and press
or , and press .
or , and set the date
.
or , and set the time
.
or , and save with .
or

11.7.56 Passwords (4.5.4)

Fig. 103 Passwords
Description
In this display, it is possible to limit the access to the Operation
and Settings menus by means of a password. If the access is
limited, it is not possible to view or set any parameters in the
menus.
The password must consist of four digits and may be used for
both menus.
If you have forgotten the password(s), contact
Note
Grundfos.
Setting via control panel
1. Mark the Settings menu with
2. Mark Functions, CU 351 with
3. Mark Password with
4. Mark the password to be activated, and press
5. Mark Enter password, and press
Now the first digit of the password is flashing.
6. Select the digit with
Now the second digit of the password is flashing.
7. Repeat steps 4 to 6 if it is necessary to activate the other
password.
Factory setting
. Both passwords are deactivated. If a password is activated, the
factory setting will be "1234".
,
.
or , and press
or , and press .
.
.
or , and save with .
.
