Sample arrangement of a process image in
the bus coupler
The following example will illustrate the assignment of input/output chan-
nels to the process image. Our sample construction is to consist of the
following bus terminal components:
Position Function component on the track
POS01
Bus coupler
POS02
2-channel digital input
POS03
2-channel digital input
POS04
2-channel digital input
POS05
2-channel digital input
POS06
2-channel digital input
POS07 2-channel digital output
POS08 2-channel digital output
POS09 2-channel digital output
POS10 2-channel analog input
POS11 2-channel analog output
POS12 2-channel analog output
POS13
2-channel analog input
POS14
Power input terminal
POS15
2-channel digital input
POS16
2-channel digital input
POS17
2-channel digital input
POS18
2-channel digital output
POS19 2-channel digital output
POS20 2-channel analog output
POS21 End terminal
By default all analog terminals are mapped without a Control/Status byte.
Please read the technical documentation for the analog terminals for
further details.
Relative byte Bit position
address
0, 1 none
2, 3
none
4, 5
none
6, 7, none
8, 9 none
10, 11 none
Process image in Position in the
the control unit block
O0, O1 POS11
O2, O3 POS11
O4, O5 POS12
O6, O7 POS12
O8, O9 POS19
O10, O11 POS19
