21
BK5200
Eiserstraße 5 / D-33415 Verl / Telefon 05246/963-0 / Telefax 05246/963-149
BK5200
Potential isolation
The bus coupler BK5200 offers a potential isolation between the DeviceNet
bus cable and the communication electronic of the bus coupler.
Isolation
barrier
drain/shield
signal
power
Network
Power
Supply
Potential levels of the BK5200
BK52x0 DeviceNet
24 Power supply
Local source
BK5200 Block diagram
Node/App
Specific
uP / CAN
Optical
Isolators
Transceiver
Shield
Power Tap
Local
Node
Supply
no
function
5V Reg
MWP
V+
V-
