LedSync820C User's Manual
5） Signals of other ports
Port name
RS232 IN
RS232 EXT
USB 1
USB 2
RJ45 port
(1, 2, 3, 4)
RJ45 port
(4)
SW
---------------------------------------------------------------------------------------------------
VEGAS LED SCREENS - LED VIDEO PROCESSOR
Vegas LED Screens
Description
Serial communication
Timing Control Software running on Upper
Controller can operate and control LedSync820C
via this communication port.
Reserved port, if LedSync820C has built-in LED
transmission card and this card has RS232 control
port, RS232 EXT port can bridge RS232 control
port of LED transmission card to outside of
LedSync820C case.
Reserved port.
Reserved port, if LedSync820C has built-in LED
transmission card and this card has USB control
port, USB2 port can bridge USB control port of
LED transmission
LedSync820C case.
Reserved port, if LedSync820C has built-in LED
transmission card and this card transfers signals
via RJ45 port, RJ45 port (1, 2, 3, 4) can bridge
RJ45 port of LED transmission card to outside of
LedSync820C case.
Reserved port, if LedSync820C has built-in
TCP/IP Ethernet communication module, RJ45
port (4) can bridge RJ45 port of built-in TCP/IP
Ethernet communication module to outside of
LedSync820C case.
Eject Select RS232 mode to operate and
out control LedSync820C, use RS232 IN
port as communication port.
Press-in Select TCP/IP mode to operate and
control LedSync820C, use RJ45 port
(4) port as communication port.
port, LedSync820C's
card to outside of
5
