LedSync820C User's Manual
c) Generally, the start coordinates of output image (Hor_Str ,
Vert_Str ) should be identical to the start coordinates of the
input image that LED transmission card captured;
d) The resolution of output image can be adjusted to the lowest 8
×8 pixels;
e) The output image shall not exceed the output area of 1024×
768 pixels;
f) While the current video image of LedSync820C is valid image,
the video color can be adjusted;
g) The custom video color is only accessible by pressing
"DEF" button while in operation mode;
h) If there are no valid input signals in LedSync820C, when it
enters setup mode, a green screen will be generated as
reference image;
i) It is strongly recommended to connect a VGA monitor to VGA
OUT of LedSync820C, so as to intuitively display all above
adjustment and setups.
---------------------------------------------------------------------------------------------------
