8.

Advanced System Operation

Besides the basic functions described in the previous chapters, you can access additional
functions via the menu. This chapter describes these functions and the menu navigation
procedure.
Menu Navigation
Using the LCD keypad on the front panel, you can navigate through the menus using
the menu navigation keys ( / ) and make simple yes/no decisions using the √ and Χ
keys.
The availability of menu items depends on the user code that you used to enter Menu
mode. Some menu items are limited to the Master code only (User 1). Certain menu
items, such as system programming functions, are not intended for the user and can
only be accessed by the installer.
The following example explains the procedure for Event Log viewing (Master code
access only).
Press √ to enter Menu mode.
1.
2. Enter the Master code; the first menu item in the main menu, Cancel
Report is displayed.
3. Press until 6. Event Log is displayed.
Press √ to enter the Event Log menu; 1. View Log is displayed.
4.
Press √ to choose the displayed item.
5.
Press Χ if you do not want to choose the displayed item. Pressing Χ also takes you back
to the previous menu level.
Menu mode automatically terminates two minutes after the last keystroke.
Throughout this chapter, we have tried to include all of the system functions using a
similar structure and order as they appear in the menu. The above procedure provides a
detailed explanation of menu navigation. However, in order to simplify the procedures
that appear in the rest of this chapter, the following conventions are used:
This...
From the Bypass Zones
menu, select Unbypass
All.
Select...
[61]
Means...
Enter the main menu by pressing √and entering your user
code. Using the arrow keys, navigate until you reach Bypass
Zones and press √. Using the arrow keys, navigate until you
reach Unbypass All and press √.
Use the arrow keys to scroll through the options and press √.
The shortcut to a specific menu item from the main menu. In
this case, this is the shortcut for View Log. These appear in
the procedures as an additional aid to menu navigation.
-36-
