ImageXpress Micro High Content Imaging System Options User Guide
68
3. Turn the adjustment ring, which is located below the arm of the
Transmitted Light tower, to the middle of the aperture range.
1
Figure 4-16: Aperture stop position for phase ring alignment
Item
1
2
2
Description
Label indicating aperture range
Adjustment ring
5014166 D
