Figure 4-3: Transmitted Light shutter
2
Figure 4-4: Hinge-release knob and hinge
Item Description
1 Hinge-release knob
2 Hinge
3 Hinge-release knob
4 Assembly tipped back with hinge-release knob unscrewed
4
3
