System Operations

Reset Menu

Key Sequence: Shift, System (8) > System Options > Reset
Reset
Factory
Defaults
Master
Reset
Update
Firmware
Back
Figure 5-11. Reset Menu
5-4

Preset Menu

Key Sequence: Shift, Preset (1)
Preset
Preset
Save
Setup
Recall
Setup
Figure 5-12. Preset Menu
MS2712E/13E User Guide
Factory Defaults: Press this submenu key to restore the instrument to its
factory default settings, including Ethernet (Option 411), language, volume,
and brightness settings. The instrument will power cycle as part of this
operation. Press the Enter key to initiate the reset, or press Esc to abort.
Master Reset: Press this submenu key to restore all instrument settings to
factory defaults and to delete all user files from the instrument internal
memory. The instrument will power cycle as part of this operation. Press the
Enter key to initiate the reset, or press Esc to abort.
Update Firmware: Press this submenu key to update the instrument
operating system using an external USB drive. Press Load Firmware to start
the update procedure, or press the Menu key to cancel and display the Menu
key screen of application icons. Refer to
Firmware" on page 5-11
options.
Back: Press this submenu key to return to the
on page 5-4.
Preset: This key resets the instrument to the default starting conditions.
Save Setup: Opens the Save dialog box (see
name and save the current operating settings, allowing them to be recalled
later to return the instrument to the state it was in at the time the setup was
saved.
The saved setup can be named using the touch screen keyboard. Use the
Caps key to select an uppercase letter. Use the Left/Right directional
arrows to move the cursor position. Press Enter to save the setup.
Note: Set the File type as Setup. Refer to
details.
Recall Setup: This key allows the selection and recall of a previously
stored instrument setup using the
rotary knob, the Up/Down arrow keys, or the touch screen to highlight the
saved setup, and press Enter. All current instrument settings are replaced
by the stored setup information.
PN: 10580-00251 Rev. T
"Updating the Spectrum Master
for additional information on both firmware update
"Save Menu" on page 4-10
"Recall Menu" on page
5-4 Preset Menu
"System Options Menu"
Figure 4-1 on page
4-13. Use the
4-2) to
for
5-9
