9-3 Web Remote Control Interface Web Remote Control
Fast Mode
Click the double arrow button to enter Fast Mode, where the update rate can be significantly
faster than Normal mode, especially over low bit-rate connections. Only the measurement
data (yellow trace) is continually updated. The main menu keys and submenu keys may look
different than in Normal Mode, but their functions are the same. Error messages are not
shown in Fast Mode.
Fast Mode is not available with some Spectrum Analyzer measurement types, in which case
the Fast Mode button is disabled. The button is not displayed when the measurement mode is
something other than Spectrum Analyzer.
While in Fast mode, if a measurement type is selected that Fast mode does not support, the
instrument will return to Normal mode.
Pause Mode
Clicking the Pause button turns the Communication Activity dot in the lower right-hand
corner to yellow. If the interface was in Normal Mode, this stops the instrument display from
refreshing in the browser window. If the interface was in Fast Mode, the trace measurement
stops updating. Click the single arrow or the double arrow button to resume remote
communications with the instrument in Normal or Fast Mode, respectively. The
Communication Activity dot then returns to green.
Communication Activity
The moving dot labeled Communication Activity, when green, indicates that ongoing
communication is occurring between the instrument and PC. When you click Home, Capture
Screen, Capture Trace, File List, Device Management, or Logout on the menu bar, the
Communication Activity dot briefly turns yellow before the selected page opens in the
browser.
Configure Timeout
If the Ethernet connection is poor and you expect frequent lags in response time, you can
increase the timeout up to 20 seconds, before the instrument sends an "Instrument Busy"
message. The default timeout is 3 seconds.
