Web Remote Control

Capture Screen

Captures a JPEG image of the current instrument display and saves it directly to internal
memory. A file name is automatically created using the current date and time stamp. The
captured display is loaded to the browser page, under the menu bar. See
Windows, you can right-click on the screen image and select Copy. With iOS, press and hold
on the picture. This makes it easy to create documentation using screen captures.
Figure 9-4. Capture Screen Page

Capture Trace

Opens an input dialog to enter a name for the trace to be saved. See
Save, a confirmation dialog opens to indicate the trace was successfully saved to the
instrument.
Figure 9-5. Capture Trace Page
Depending on the browser and operating system used, different prompts may appear. Some
operating systems like iOS may not support file saving from a browser.
MS2712E/13E User Guide PN: 10580-00251 Rev. T
9-3 Web Remote Control Interface
Figure
Figure 9-5. After clicking
9-4. In
9-7
