GPS (Option 31)
6-3

Resetting GPS

To reset the GPS, press the Reset submenu key. The green GPS icon shows a red cross mark
when satellite tracking is lost after tracking four or more satellites. The GPS latitude and
longitude are saved in the instrument memory until the Spectrum Master is turned off or
until GPS is turned off by using the GPS On/Off key.
Figure 6-3.
GPS Icon, Tracking Lost
6-4

Saving and Recalling Traces with GPS Information

Saving Traces with GPS Information

The GPS coordinates of a location can be saved along with a measurement trace. Refer to
"Save Menu" on page 4-10
with the measurement traces whenever GPS is on and actively tracking satellites.

Recalling GPS Information

If the GPS coordinates were saved with a measurement, the coordinates will be recalled when
the measurement is recalled. Refer to
recalling a saved trace.
MS2712E/13E User Guide
GPS
for more information. The current GPS coordinates will be saved
"Recall Menu" on page 4-13
PN: 10580-00251 Rev. T
6-3 Resetting GPS
for more information on
6-3
