Port Screens—Digital Subscriber
Lines
The ports on the 800 CO-BRI module are linked to Digital Subscriber Lines
(DSLs). Therefore, a DSL option has been added to the Port menu. By choosing
DSL from this menu, the user can check the status of, busy-out, restore, or check
the error events for the DSL port.
Follow the screens and instructions below to get to the DSL menu.
Screen Display
Step
1
P o r t :
M a k e a s e l e c t i o n
L i n e / T r u n k
S t a t i o n
RS232 Port1
RS232 Port2
E x i t
2
DSL
:
E n t e r D S L ( s s p p )
B a c k s p a c e
E x i t
3 DSL x x x x :
M a k e a s e l e c t i o n
S t a t u s
B u s y O u t
R e s t o r e
E r r o r E v e n t s
E x i t

Port Screens-Digital Subscriber Lines

6-16
Modem
B-Channel
DSL
E n t e r
Procedure
From the Port menu, select DSL.
Enter the DSL slot and port number
and select Enter.
NOTE:
The slot number ranges from 01 to 17;
the port number ranges from 01 to 08
for the 800 CO-BRI module.
At the DSL port menu, select the
option you want, and proceed as you
would for any other port on the system
(see the Maintenance and
Troubleshooting Guide, (555-620-
143).
