RLX2 Industrial Hotspot Series

RLX2-IHNF-WC

The following components are included with Weatherproof Hazardous Location RLX2
radio products:
Qty.
Part Name
RLX2 Series Radio
1
5 foot CAT 6 Ethernet
1
PoE cable
5 foot flying leads power
1
cable
U bolts for mounting
2
Oval Clip & Seal Cap
1
ProSoft Solutions DVD
1

Industrial Hotspot Bench Test Kit (RLX-IHBTK)

The standard radio products are intended for deployment into production systems and
do not include accessory power supplies or cables. For bench testing of radios, an
optional bench test kit provides these accessories:
Part Name
Qty.
Power Supply
1
Cable
1
Cable
1
Adapter
1

Personality Module

The RLX2 series of industrial hotspots include a feature for quickly moving the
configuration from an installed radio to a replacement using a provided MicroSD card.
This feature reduces the time to replacement of a damaged radio. Consideration of how
to use this feature in advance of installation is necessary to take advantage of this
feature.
Note: The RLX2-IHNF-W and -WC do not have a Personality Module.
Important: Before installing, please verify all listed product items are present. If any of these
components are missing, please contact ProSoft Technology Support for replacements.
Page 18 of 208
Part Number Part Description
RLX2-IHNF-WC RadioLinx
Preinstalled 6 foot CAT 6 Ethernet PoE cable
Preinstalled 6 foot flying leads power cable
Pole mounting brackets
Oval clip and seal cap for conduit connections
Contains sample programs, utilities, firmware
DVD-001
images, and documentation.
Part Number Part Description
RL-PS007-2 AC Power Adapter, 12V1.6A w/2 pin & 4 plug
Set
RL-CBL025 5 foot Ethernet Straight-Thru Cable
085-1007 6 foot RS232 serial cable
HRDNULL-DB9 RS232 null modem serial adapter
® RLX2 802.11 Industrial Hotspot
ProSoft Technology, Inc.
