RLX2 Industrial Hotspot Series
EtherNet/IP™ and Modbus TCP/IP Support
The RLX2 handles queries using either EtherNet/IP or Modbus TCP/IP protocols, via an
internal agent module, allowing you to obtain diagnostic and status information about
the RLX2.

Modbus TCP/IP Server Support

A Modbus TCP/IP client can poll the RLX2 radio for status information. The Modbus
TCP/IP server listens to port 502 and port 2000 and handles requests from the port eth0
(Ethernet port) or ppp0 (Point-to-Point Protocol). PPP is a data link layer protocol used
to establish a connection between two nodes.
The module supports up to five concurrent Modbus TCP/IP client connections to read
radio diagnostics.
Modbus Memory Map Diagnostic Information
Name
RLX2_Diag.SSID
RLX2_Diag.IPAddress
RLX2_Diag.MACAddress
RLX2_Diag.NeworkMode
RLX2_Diag.ConnectionState
RLX2_Diag.SignalStrength
RLX2_Diag.Channel
RLX2_Diag.WEP
RLX2_Diag.Flags
RLX2_Diag.MasterMACAddress
RLX2_Diag.HopCount
RLX2_DiagStatus
RLX2_Diag.NumAssociations
RLX2_Diag.NumBridgeAssocs
RLX2_Diag.TxRadioThroughput
RLX2_Diag.RxRadioThroughput
RLX2_Diag.Uptime
RLX2_Diag.LinkTime
RLX2_Diag.TxPktThput
RLX2_Diag.RxPktThput
RLX2_Diag.ModuleName
RLX2_Diag.ProductName
RLX2_Diag.ImageVerStr
RLX2_Diag.tx_good
Page 144 of 208
Data Type Access
SINT[32] Read
SINT[4] Read
SINT[6] Read
SINT Read
SINT Read
INT Read
SINT Read
SINT Read
DINT Read
SINT[6] Read
SINT Read
SINT Read
INT Read
INT Read
INT Read
INT Read
DINT Read
DINT Read
DINT Read
DINT Read
SINT[32] Read
SINT[32] Read
SINT[28] Read
DINT Read
Modbus Register
30001 – 30016
30017 – 30018
30019 – 30021
30022
30023
30024
30025
30026
30027 – 30028
30029 – 30031
30032
30033
30034
30035
30036
30037
30038 – 30039
30040 – 30041
30042 – 30043
30044 – 30045
30046 – 30061
30062 – 30077
30078 – 30091
30092 - 30093
