2. Connect the power cable with an M12 connector to the specified port shown.
Note: The RLX2-IHNF-W radio can be powered over Ethernet (POE) with an approved
injector available from ProSoft. In this case, the Power connector would not be used.
If PoE is used, cap the Power Connector with the M12 Waterproof Cap.
3. Connect the Ethernet cable through the PoE injector (if using PoE) and into the
network switch.
Note: Most off-the-shelf PoE Injectors work with this unit except the 802.3at/ PoE+ Injectors.
Note: The M12 PoE cable is not included with the radio but can be ordered through ProSoft.
Warning: Do not connect or disconnect the M12 Power Port or PoE connection when
energized, that is, the cable is live.
Antennas are to be installed in accordance with Control Drawing 06/2514.
