Page 1 SUPERSERVER ® 8048B-TR3F 8048B-C0R3FT USER’S MANUAL Revision 1.0...
Page 2 This product, including software and documentation, is the property of Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except as expressly permitted by the terms of said license.
Page 3: About This Manual
Preface Preface About This Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SuperServer 8048B-TR3F/C0R3FT Installation and maintainance should be performed by experienced technicians only. The SuperServer 8048B-TR3F/C0R3FT is a high-end server based on the 748TQ-R1K43B tower/4U rackmount chassis and the X10QBL-(CT) quad processor serverboard.
Page 4 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Chapter 6: Advanced Chassis Setup Refer to Chapter 6 for detailed information on the 748TQ-R1K43B server tower/4U rackmount chassis. You should follow the procedures given in this chapter when installing, removing or reconﬁ guring SAS/SATA or peripheral drives and when replacing system power supply units and cooling fans.
Page 5 Preface Notes...
Page 6: Table Of Contents
Cooling System ....................1-5 Advanced Power Management ............... 1-6 Intel® Intelligent Power Node Manager (NM) ..........1-6 Manageability Engine (ME) ................1-6 Contacting Supermicro ..................1-7 Chapter 2 Server Installation Overview ......................2-1 Unpacking the System ..................2-1 Preparing for Setup ..................2-1 Choosing a Setup Location ................
Page 7 Table of Contents Circuit Overloading ..................2-3 Reliable Ground ..................2-4 Installing the System into a Rack ..............2-4 Removing the Feet ..................2-4 Identifying the Sections of the Rack Rails ............2-6 Tower Conﬁ guration Instructions ..............2-11 Checking the Serverboard Setup ..............2-12 Checking the Drive Bay Setup ..............
Page 8 Conﬁ guring the Storage Module ..............6-3 Tower or Rack Conﬁ guration................6-3 Adding Drives to the Storage Module ............. 6-5 Adding Five Hard Drives to a Supermicro Mobile Rack: ........ 6-8 Installing Hard Drives ..................6-10 Add-on Card/Expansion Slot Setup .............. 6-12 Installing the Air Shroud ................
Page 9 Table of Contents Chapter 7 BIOS Introduction ...................... 7-1 Starting the Setup Utility ................. 7-1 Main Setup ...................... 7-2 Advanced Setup Conﬁ gurations..............7-3 Event Logs ....................7-30 IPMI ....................... 7-32 Security ......................7-35 Boot ....................... 7-36 Save & Exit ....................7-38 Appendix A BIOS Error Beep Codes BIOS Error Beep Codes .................
Page 10 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Notes...
Page 11: Chapter 1 Introduction
748TQ-R1K43B tower/4U rackmount chassis and the X10QBL-(CT) dual processor serverboard. Please refer to our web site for information on operating systems that have been certiﬁ ed for use with the system (www.supermicro.com). In addition to the serverboard and chassis, various hardware components have been included with the SuperServer 8048B-TR3F/C0R3FT, as listed below: •...
Page 12: Serverboard Features
Each processor supports three full-width Intel QuickPath Interconnect (QPI) links (Data Transfer Rate of up to 9.6 GT/s per direction) Please refer to our web site for a complete listing of supported processors (www.supermicro.com). Memory The X10QBL-(CT) has thirty-two (32) single/dual/tri/quad channel 240-...
Page 13: Sas (8048B-C0R3Ft Server Only)
Ethernet ports and one dedicated IPMI LAN port. Note 1: For more information on IPMI conﬁ guration, please refer to the IPMI User's Guide posted on our website at http://www.supermicro.com/support/manuals/ Graphics Controller The X10QBL-(CT) features an integrated ASpeed AST2400 BMC (Baseboard Controller) for a graphics controller.
Page 14: Server Chassis Features
Four PCI expansion card slots are available in the rear of the chassis for two (2) PCI-E 3.0 x16 slots (CPU1 Slot1, CPU2 Slot3) and two (2) PCI-E 3.0 x8 slots (CPU2 Slot2, CPU2 Slot4). See our web site for details (http://www.supermicro.com/ products/nfo/UIO.cfm). See section 5-6 for further details.)
Page 15: Front Control Panel
Chapter 1: Introduction Front Control Panel The control panel on the SuperServer 8048B-TR3F/C0R3FT provides you with system monitoring and control. LEDs indicate system power, HDD activity, network activity, system overheat and power supply failure. A main power button and a system reset button are also included.
Page 16: Advanced Power Management
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Advanced Power Management Intel® Intelligent Power Node Manager (NM) The Intel Intelligent Power Node Manager (IPNM) provides your system with ® real-time thermal control and power management for maximum energy efﬁ ciency. Although IPNM Speciﬁ cation Version 1.5 is supported by the BMC (Baseboard Management Controller), your system must also have IPNM-compatible Manageability Engine (ME) ﬁ...
Page 17: Contacting Supermicro
Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...
Page 18 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Notes...
Page 19: Chapter 2 Server Installation
Chapter 2: Server Installation Chapter 2 Server Installation Overview This chapter provides a quick setup checklist to get your SuperServer 8048B-TR3F/C0R3FT up and running. Following these steps in the order given should enable you to have the system operational within a minimum amount of time. This quick setup assumes that your system has come to you with the processors and memory preinstalled.
Page 20: Warnings And Cautions
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual • This product is for installation only in a Restricted Access Location (dedicated equipment rooms, service closets and the like). • This product is not suitable for use with visual display work place devices acccording to §2 of the the German Ordinance for Work with Visual Display Units. Warnings and Cautions! Rack Precautions •...
Page 21: Rack Mounting Considerations
Chapter 2: Server Installation Rack Mounting Considerations Warning! To prevent bodily injury when mounting or servicing this unit in a rack, you must take special precautions to ensure that the system remains stable. The following guidelines are provided to ensure your safety: •...
Page 22: Reliable Ground
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Reliable Ground A reliable ground must be maintained at all times. To ensure this, the rack itself should be grounded. Particular attention should be given to power supply connections other than the direct connections to the branch circuit (i.e. the use of power strips, etc.).
Page 23 Chapter 2: Server Installation Removing the Chassis Feet 1. Place the chassis on its side with the chassis side cover facing upward. 2. Remove the screw holding the chassis foot in place. 3. The foot lock is a tab located in the center of the foot that prevents the foot from sliding.
Page 24: Identifying The Sections Of The Rack Rails
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Identifying the Sections of the Rack Rails The chassis package includes two rack rail assemblies in the rack mounting kit. Each assembly consists of two sections: an inner ﬁ xed chassis rail that secures directly to the server chassis and an outer ﬁ xed rack rail that secures directly to the rack itself (see Figure 2-2 for details).
Page 25 Chapter 2: Server Installation 5. Align the inner rails against the chassis, as shown in Figure 2-4. Conﬁ rm that the rails are ﬂ ushed against the edge of the chassis. Figure 2-4: Installing the Inner Rack Rails 6. Tighten the screws. Do not over tighten. 7.
Page 26 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Installing the Outer Rails to the Rack (Figure 2-5) 1. Attach the front and rear short brackets to the outside of the long bracket. Both bracket ends must face the same direction. 2. Adjust both the brackets to the proper distance so that the rail ﬁ ts snugly into the rack.
Page 27 Chapter 2: Server Installation Installing the Chassis into a Rack 1. Conﬁ rm that chassis includes the inner rails and the outer rails. 2. Line chassis rails with the front of the rack rails (Figure 2-6). Figure 2-6. Installing the Rack Rails...
Page 28 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual 3. Slide the chassis rails into the rack rails, keeping the pressure even on both sides (you may have to depress the locking tabs when inserting). When the server has been pushed completely into the rack, you should hear the locking tabs "click"...
Page 29: Tower Conﬁ Guration Instructions
Chapter 2: Server Installation Tower Conﬁ guration Instructions The SC748 tower/4U rackmount chassis is shipped with the chassis cover and feet pre-installed. To use the chassis as a desktop server, no other installation is required. Use the instructions in this section if you have converted the chassis for rack use and need to return the chassis to tower mounting.
Page 30: Checking The Serverboard Setup
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual approximately one-half inch over the front of the chassis (Figure 2-8). 3. Slide the chassis cover toward the rear of the chassis to lock the cover into place. Placing the Chassis Feet (Figure 2-9) 1. Place the chassis foot in the foot receptacle and slide the foot toward the front of the chassis.
Page 31 Chapter 2: Server Installation Figure 2-10: Removing the Chassis Cover Remove Screws Checking the Components and Setup 1. You may have one or two processors already installed into the serverboard. Each processor needs its own heat sink. See Chapter 5 for instructions on processor and heat sink installation.
Page 32: Checking The Drive Bay Setup
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Checking the Drive Bay Setup Next, you should check to make sure the peripheral drives and the SAS/SATA drives have been properly installed and all connections have been made. Checking the Drives 1. All drives are accessable from the front of the server. For servicing the DVD- ROM, you will need to remove the top chassis cover.
Page 33: Chapter 3 System Interface
Chapter 3: System Interface Chapter 3 System Interface Overview Most SC748 tower/4U rackmount chassis models have two buttons on the chassis a control panel; a reset button and an on/off switch. Figure 4-1: Front Control Panel Front Control Panel...
Page 34: Power
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Control Panel Buttons There are two buttons located on the front of the chassis: a reset button and a power on/off button. Power The main power switch is used to apply or remove power from the power supply to the server system.
Page 35: Universal Information Led
Chapter 3: System Interface Universal Information LED See the following table for the status shown by this LED. Universal Information LED Status Description Continously on and red An overheat ocondition has occured. (This may be caused by cable congestion.) Blinking red (1 Hz) Fan failure: check for an inoperative fan.
Page 36: Drive Carrier Leds
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Drive Carrier LEDs The SC748 tower/4U rackmount chassis includes externally accessible SAS/SATA drives. Each drive carrier displays two status LEDs on the front of the carrier. LED Color State Status Green Solid On SAS drive installed Activity LED Green Blinking...
Page 37: About Standardized Warning Statements
Only certiﬁ ed technicians should attempt to install or conﬁ gure components. Read this appendix in its entirety before installing or conﬁ guring components in the Supermicro chassis. These warnings may also be found on our web site at http://www.supermicro.com/ about/policies/safety_information.cfm. Warning Deﬁ nition Warning! This warning symbol means danger.
Page 38 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie beﬁ nden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
Page 39 Warning Statements for AC Systems ‫ﺟﺴﺪﻳﺔ‬ ‫ﺍﺻﺎﺑﺔ‬ ‫ﺗﺘﺴﺒﺐ ﻓﻲ‬ ‫ﺣﺎﻟﺔ ﻳﻤﻜﻦ ﺃﻥ‬ ‫ﺍﻧﻚ ﻓﻲ‬ ‫ﺧﻄﺮ‬ ‫ﻳﻌﻨﻲ‬ ‫ﻫﺬﺍ ﺍﻟﺮﻣﺰ‬ !‫ﺗﺤﺬﻳﺮ‬ ‫ﺍﻟﺪﻭﺍﺋﺮ‬ ‫ﺑﺎﻟﻤﺨﺎﻁﺮ ﺍﻟﻨﺎﺟﻤﺔ ﻋﻦ‬ ‫ﻦ ﻋﻠﻰ ﻋﻠﻢ‬ ، ‫ﻛ‬ ‫ﻣﻌﺪﺍﺕ‬ ‫ﺗﻌﻤﻞ ﻋﻠﻰ ﺃﻱ‬ ‫ﻗﺒﻞ ﺃﻥ‬ ‫ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ‬ ‫ﺣﻮﺍﺩﺙ‬ ‫ﺃﻱ‬ ‫ﻭﻗﻮﻉ‬ ‫ﻤﻨﻊ‬ ‫ﻟ‬ ‫ﺍﻟﻮﻗﺎﺋﻴﺔ‬...
Page 40: Installation Instructions
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 設置手順書システムを電源に接続する前に、設置手順書をお読み下さい。警告将此系统连接电源前,请先阅读安装说明。警告將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación.
Page 41: Circuit Breaker
Chapter 4: Warning Statements for AC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 250 V, 20 A. サーキット・ブレーカーこの製品は、短絡（過電流）保護装置がある建物での設置を前提としています。保護装置の定格が250 V、...
Page 42: Power Disconnection Warning
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual ‫ﻓﻲ‬ ‫ﺍﻟﺘﻲ ﺗﻢ ﺗﺜﺒﻴﺘﻬﺎ‬ ‫ﻣﻦ ﺍﻟﺪﻭﺍﺋﺮﺍﻟﻘﺼﻴﺮﺓ‬ ‫ﺍﻟﺤﻤﺎﻳﺔ‬ ‫ﻣﻌﺪﺍﺕ‬ ‫ﻳﻌﺘﻤﺪ ﻋﻠﻰ‬ ‫ﻫﺬﺍ ﺍﻟﻤﻨﺘﺞ‬ ‫ﺍﻟﻤﺒﻨﻰ‬ ‫ﺃﻛﺜﺮ ﻣﻦ‬ ‫ﻟﻴﺲ‬ ‫ﻮﻗﺎﺋﻲ‬ ‫ﺍﻟ‬ ‫ﺍﻟﺠﻬﺎﺯ‬ ‫ﺗﻘﻴﻴﻢ‬ ‫ﺃﻥ‬ ‫ﺗﺄﻛﺪ ﻣﻦ‬ 20A, 250V 경고! 이 제품은 전원의 단락(과전류)방지에 대해서 전적으로 건물의 관련 설비에 의존합니다. 보호장치의 정격이 반드시 250V(볼트), 20A(암페어)를 초과하지 않도록...
Page 43 Chapter 4: Warning Statements for AC Systems Warnung Das System muss von allen Quellen der Energie und vom Netzanschlusskabel getrennt sein, das von den Spg.Versorgungsteilmodulen entfernt wird, bevor es auf den Chassisinnenraum zurückgreift, um Systemsbestandteile anzubringen oder zu entfernen. ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema.
Page 44: Equipment Installation
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Equipment Installation Warning! Only trained and qualiﬁ ed personnel should be allowed to install, replace, or service this equipment. 機器の設置トレーニングを受け認定された人だけがこの装置の設置、交換、またはサービスを許可されています。警告只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。警告只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualiﬁ...
Page 45: Restricted Area
Chapter 4: Warning Statements for AC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwaliﬁ ceerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.
Page 46: Battery Handling
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual ‫אזור עם גישה מוגבלת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ .('‫כלי אבטחה בלבד )מפתח, מנעול וכד‬ ‫ﻣﺤﻈﻮﺭﺓ‬ ‫ﻣﻨﺎﻁﻖ‬ ‫ﻟﺘﺮﻛﻴﺒﻬﺎ ﻓﻲ‬ ‫ﻫﺬﻩ ﺍﻟﻮﺣﺪﺓ‬ ‫ﺗﺨﺼﻴﺺ‬ ‫ﺗﻢ‬ ،‫ﺃﺩﺍﺓ ﺧﺎﺻﺔ‬ ‫ﻣﻦ ﺧﻼﻝ ﺍﺳﺘﺨﺪﺍﻡ‬ ‫ﻓﻘﻂ‬...
Page 47 Chapter 4: Warning Statements for AC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.
Page 48: Redundant Power Supplies
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 冗長電源装置このユニットは複数の電源装置が接続されている場合があります。ユニットの電源を切るためには、すべての接続を取り外さなければなりません。警告此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。警告此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden.
Page 49: Backplane Voltage
Chapter 4: Warning Statements for AC Systems ‫ﺍﻣﺪﺍﺩ ﺍﻟﻄﺎﻗﺔ‬ ‫ﺑﻮﺣﺪﺍﺕ‬ ‫ﻋﺪﺓ ﺍﺗﺼﺎﻻﺕ‬ ‫ﺠﻬﺎﺯ‬ ‫ﺍﻟ‬ ‫ﻳﻜﻮﻥ ﻟﻬﺬﺍ‬ ‫ﻗﺪ‬ ‫ﺍﻟﻜﻬﺮﺑﺎء‬ ‫ﻋﻦ‬ ‫ﻮﺣﺪﺓ‬ ‫ﺍﻟ‬ ‫ﻟﻌﺰﻝ‬ ‫ﻛﺎﻓﺔ ﺍﻻﺗﺼﺎﻻﺕ‬ ‫ﻳﺠﺐ ﺇﺯﺍﻟﺔ‬ 경고! 이 장치에는 한 개 이상의 전원 공급 단자가 연결되어 있을 수 있습니다. 이 장치에 전원을...
Page 50: Comply With Local And National Electrical Codes
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Attention Lorsque le système est en fonctionnement, des tensions électriques circulent sur le fond de panier. Prendre des précautions lors de la maintenance. ‫מתח בפנל האחורי‬ !‫הרה‬ ‫אז‬ ‫קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך‬ .‫העבודה‬...
Page 51: Product Disposal
Chapter 4: Warning Statements for AC Systems ¡Advertencia! La instalacion del equipo debe cumplir con las normas de electricidad locales y nacionales.Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ ‫הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫התקנת‬...
Page 52: Hot Swap Fan Warning
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Warnung Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen des Landes erfolgen. ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement.
Page 53 Chapter 4: Warning Statements for AC Systems 当您从机架移除风扇装置，风扇可能仍在转动。小心不要将手指、螺丝起子和其他物品太靠近风扇警告當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他物品太靠近風扇。 Warnung Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt. ¡Advertencia! Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.
Page 54: Power Cable And Ac Adapter
ﬁ re. Electrical Appliance and Material Safety Law prohibits the use of UL or CSA -certiﬁ ed cables (that have UL/CSA shown on the code) for any other electrical devices than products designated by Supermicro only. 電源コードとACアダプター...
Page 55 Appareils électroménagers et de loi sur la sécurité Matériel interdit l'utilisation de UL ou CSA câbles certiﬁ és qui ont UL ou CSA indiqué sur le code pour tous les autres appareils électriques que les produits désignés par Supermicro seulement.
Page 56 Elektrisch apparaat en veiligheidsinformatiebladen wet verbiedt het gebruik van UL of CSA gecertiﬁ ceerde kabels die UL of CSA die op de code voor andere elektrische apparaten dan de producten die door Supermicro alleen.
Page 57: Chapter 5 Advanced Serverboard Setup
Chapter 5: Advanced Serverboard Setup Chapter 5 Advanced Serverboard Setup This chapter covers the steps required to install the X10QBL-(CT) serverboard into the chassis, connect the data and power cables and install add-on cards. All serverboard jumpers and connections are also described. A layout and quick reference chart are included in this chapter for your reference.
Page 58: Connecting Cables
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Connecting Cables Now that the serverboard is installed, the next step is to connect the cables to the board. These include the data (ribbon) cables for the peripherals and control panel and the power cables. Connecting Data Cables The ribbon cables used to transfer data from the peripheral devices have been carefully routed to prevent them from blocking the ﬂ...
Page 59 Chapter 5: Advanced Serverboard Setup Figure 5-1. Control Panel Header Pins Ground 3.3 V FP PWRLED UID Switch HDD LED NIC1 Link LED NIC1 Activity LED NIC2 Activity LED NIC2 Link LED OH/Fan Fail/ UID LED PWR Fail LED) Power Fail LED 3.3V Reset Reset Button...
Page 60: I/O Ports
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual I/O Ports The I/O ports are color coded in conformance with the PC 99 speciﬁ cation. See Figure 5-2 below for the colors and locations of the various I/O ports. Figure 5-2. I/O Ports I/O Ports COM Port Back Panel (Vertical) USB 2.0 Port 2 VGA (Blue)
Page 61: Installing The Processor And Heatsink
CPU socket cap is in place, and none of the socket pins are bent; otherwise, contact your retailer immediately. 5. Refer to the Supermicro website for updates on CPU support. 6. With the CPU inside the socket, inspect the four corners of the CPU to make sure that the CPU is properly installed.
Page 62 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Note: All graphics, drawings and pictures shown in this manual are for illustration only. The components that came with your machine may or may not look exactly the same as those shown in this manual. 2. Press the second load lever labeled 'Close 1st' to release the load plate that covers the CPU socket from its locking position.
Page 63 Chapter 5: Advanced Serverboard Setup 4. Use your thumb and the index ﬁ nger to loosen the lever and open the load plate. 5. Using your thumb and index ﬁ nger, hold the CPU on its edges. Align the CPU keys, which are semi-circle cutouts, against the socket keys.
Page 64 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual 7. With the CPU inside the socket, inspect the four corners of the CPU to make sure that the CPU is properly installed. Push down and lock the Gently close the load plate. lever labeled 'Close 1st'. 8.
Page 65: Installing A Passive Cpu Heatsink
Chapter 5: Advanced Serverboard Setup Installing a Passive CPU Heatsink 1. Do not apply any thermal grease to the heatsink or the CPU die -- the required amount has already been applied. 2. Place the heatsink on top of the CPU so that the four mounting holes are aligned with those on the Motherboard's and the Heatsink Bracket underneath.
Page 66: Removing The Heatsink
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Removing the Heatsink Caution: We do not recommend that the CPU or the heatsink be removed. However, if you do need to uninstall the heatsink, please follow the instructions below to uninstall the heatsink to prevent damage done to the CPU or the CPU socket. 1.
Page 67: Installing Memory
Use memory modules of the same type, speed, timing and same on a serverboard. For the latest memory updates, please refer to our website a at http://www.supermicro.com/products/motherboard. Notes: 1. For best system performance, we recommend that a pair of CPUs (CPU1/ CPU2) or two pairs of CPUs (CPU1/CPU2/CPU3/CPU4) be installed.
Page 68: Processor & Memory Module Population Conﬁ Guration
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Processor & Memory Module Population Conﬁ guration For memory to work properly, follow the tables below for memory installation. Fully-Populated Conﬁ guration Please follow the instructions below to populate all DIMM slots: Processors and their Corresponding Memory Modules CPU# Corresponding DIMM Modules for Full-Populated Conﬁ...
Page 69: Populating Memory Modules
QRx4 16GB 32GB 1333 1333 1333 1333 1333 LRDIMM (RM) 8Rx4 32GB 64GB 1066 1066 1066 Note: For detailed information on memory support and updates, please refer to the SMC Recommended Memory List posted on our website at http://www.supermicro.com/support/resources/mem.cfm. 5-13...
Page 70 64GB 1066 1066 1066 Note: For detailed information on memory support and updates, please refer to the SMC Recommended Memory List posted on our website at http://www.supermicro.com/support/resources/mem.cfm. Notes: • SR=Single Rank, DR=Dual Rank and QR=Quad Rank • Command Address Timing is 1N for 1DPC and 2N for 2DPC.
Page 71: Other Important Notes And Restrictions
Chapter 5: Advanced Serverboard Setup Other Important Notes and Restrictions • For the memory modules to work properly, please install DIMM modules of the same type, same speed and same operating frequency on the motherboard. Mixing of RDIMMs or LRDIMMs is not allowed. Do not install both ECC and Non-ECC memory modules on the same motherboard.
Page 72: Serverboard Details
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Serverboard Details Figure 5-4. X10QBL-(CT) Layout USB0/1 USB2 COM1 LED1 LEDBMC FAN9 IPMI_LAN LAN CTRL LAN1/2 FAN10 JPTG1 MAC CODE IPMI CODE BAR CODE SAS CODE JBT1 USB4/5 X10QBL-CT USB6/7 IB CODE BIOS Rev. 1.01 CPU4 CPU2 CLOSE 1st OPEN 1st...
Page 73 Chapter 5: Advanced Serverboard Setup X10QBL-(CT) Quick Reference Jumper Description Default Setting JBT1 Clear CMOS See Section 5-9 for details. C1/JI SMB to PCI-E slots Off (Disabled) JPB1 BMC Enable Pins 1-2 (Enabled) JPG1 VGA Enable Pins 1-2 (Enabled) JPL1 GLAN1/GLAN2 Enable (X10QBL) Pins 1-2 (Enabled) JPTG1...
Page 74 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Connector Description BT2 (Battery) Onboard CMOS Battery (See Chpt. 3 for used battery disposal.) COM1/COM2 Back panel COM port 1/Serial port 2 header FAN1-FAN10 CPU/System fan headers I-SATA0-5 Intel SATA 3.0/2.0 ports 0-5 (I-SATA 3.0 ports 0/1, I-SATA 2.0 ports 2-5) (supported by Intel PCH) Speaker/Power LED header Front Panel Control header...
Page 75: Connector Deﬁ Nitions
Chapter 5: Advanced Serverboard Setup Connector Deﬁ nitions Main ATX Power Supply Connector ATX Power 24-pin Connector Pin Deﬁ nitions A 24-pin main power supply connector Pin# Deﬁ nition Pin # Deﬁ nition ( J P W R 1 ) , a n d f o u r 8 - p i n C P U power connectors (JPWR2/JPWR3/ +3.3V +3.3V...
Page 76 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Reset Button Reset Button Pin Deﬁ nitions (JF1) The Reset Button connection is located Pin# Deﬁ nition on pins 3 and 4 of JF1. Attach it to a hardware reset switch on the computer Reset case. Refer to the table on the right for Ground pin deﬁ...
Page 77 Chapter 5: Advanced Serverboard Setup HDD/UID LED HDD LED Pin Deﬁ nitions (JF1) The HDD LED connection is located on Pin# Deﬁ nition pins 13 and 14 of JF1. Attach a cable UID LED here to indicate HDD activity and UID status.
Page 78 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Universal Serial Bus (USB) Back Panel USB 2.0 (USB 0/1 Pin Deﬁ nitions Three USB2.0 ports (USB 0/1, USB Pin# Deﬁ nition Pin# Deﬁ nition 2) are located on the I/O back panel. Two internal USB headers, located USB_PN1 USB_PN0 next to the I-SATA ports 4/5, provide...
Page 79 Note: UID can also be triggered via IPMI on the motherboard. For more information on IPMI, please refer to the IPMI User's Guide posted on our website @http://www.supermicro.com. Internal Speaker Internal Buzzer Pin Deﬁ nition The Internal Speaker (SP1) can be Pin# Deﬁ...
Page 80 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual IPMB Header IPMB Header Pin Deﬁ nitions A System Management Bus header for Pin# Deﬁ nition IPMI 2.0 is located at JIPMB1. Connect Data an appropriate cable here to use the IPMB I C connection on your system. Ground Clock No Connection...
Page 81 Chapter 5: Advanced Serverboard Setup SATA DOM Power Connectors DOM PWR Pin Deﬁ nitions Two power connectors for SATA DOM Pin# Deﬁ nition (Disk_On_Module) devices are located at JSD1/JSD2. Connect appropriate cables here to provide power support Ground for your Serial-Link DOM devices. Ground Chassis Intrusion Chassis Intrusion...
Page 82: Jumper Settings
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Jumper Settings Connector Pins Explanation of Jumpers To modify the operation of the Jumper motherboard, jumpers can be used to choose between optional settings. Jumpers create shorts between two Setting pins to change the function of the connector.
Page 83 Chapter 5: Advanced Serverboard Setup LAN Enable/Disable LAN1/2 Enable/Disable Jumper Settings JPL1 enables or disables Gigabit_LAN Jumper Setting Deﬁ nition ports on the X10QBL-CT, while JPTG1 Pins 1-2 Enabled enables or disables 10G-LAN ports on the X10QBL-T. See the table on the Pins 2-3 Disabled right for jumper settings.
Page 84 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual C Bus to PCI-Exp. Slots C for PCI-E slots Jumper Settings Use Jumpers JI C1 and JI C2 to Jumper Setting Deﬁ nition connect the System Management Normal (Default) Bus (I C) to the PCI-Express slots to improve PCI performance.
Page 85: 5-10 Onboard Indicators
Chapter 5: Advanced Serverboard Setup 5-10 Onboard Indicators GLAN LED GLAN LEDs Activity Link Speed There are two LAN ports (LAN1/2) on the motherboard. Each Ethernet LAN port has two LEDs. The Yellow LED on the right indicates connection and GLAN Activity Indicator (Right) LED Settings activity.
Page 86 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Onboard Power LED Onboard PWR LED Indicator LED States An Onboard Power LED indicator is LED Color Deﬁ nition located at LED15 (LEDPWR) on the System Off motherboard. When this LED is on, (PWR cable not connected) the system is on.
Page 87: 5-11 Sas/Sata Ports
Chapter 5: Advanced Serverboard Setup 5-11 SAS/SATA Ports SATA 3.0 Ports Six SATA connections supported by Intel PCH 602 are located on the motherboard. I-SATA ports 0/1 support SATA 3.0 connections, while I-SATA ports 2-5 support SATA 2.0. These SATA connectors provide serial-link connections, which are faster than Parallel ATA connections.
Page 88: 5-12 Installing Software
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual 5-12 Installing Software The Supermicro ftp site contains drivers and utilities for your system at ftp://ftp. supermicro.com. Some of these must be installed, such as the chipset driver. After accessing the ftp site, go into the CDR_Images directory and locate the ISO ﬁ...
Page 89: Superdoctor 5
The bottom icon with a CD on it allows you to view the entire contents. SuperDoctor 5 The Supermicro SuperDoctor 5 is a hardware and operating system services ®...
Page 90 Figure 5-7. SuperDoctor 5 Interface Display Screen (Remote Control) Note: The SuperDoctor 5 program and User’s Manual can be downloaded from the Supermicro web site at http://www.supermicro.com/products/nfo/sms_sd5.cfm. For Linux, we recommend that you use the SuperDoctor II application instead. 5-34...
Page 91: 5-13 Serverboard Battery
Chapter 5: Advanced Serverboard Setup 5-13 Serverboard Battery Caution: There is a danger of explosion if the onboard battery is installed upside down, which will reverse its polarites (see Figure 5-8). This battery must be replaced only with the same or an equivalent type recommended by the manufacturer (CR2032).
Page 92 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Notes 5-36...
Page 93: Chapter 6 Advanced Chassis Setup
Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform maintenance on the 748TQ-R1K43B tower/4U rackmount chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered.
Page 94: Control Panel
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Figure 6-1. Front and Rear Chassis Views Control Panel 5.25" PeripheralDrive Bays (3) SAS/SATA Drives (5) Power Supplies (3) In Mobile Rack USB Ports IPMI LAN COM1 Port VGA Port Ethernet Ports Standard Size PCI Slots (6) (4 on Motherboard) Control Panel The control panel (located on the front of the chassis) must be connected to the...
Page 95: Conﬁ Guring The Storage Module
90 degrees. This can be done before, during, or after setup. Also an extra rail is required for rack conﬁ guration and must be purchased separately, refer to our website at www.supermicro.com for part number. Figure 6-2: Chassis in Tower Mode...
Page 96 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Figure 6-4: Chassis Storage Module Rotating the Storage Module for Rack Mounting 1. Open the chassis cover. 2. Locate the storage module and disconnect any cables from the storage module to any component in the chassis. 3.
Page 97: Adding Drives To The Storage Module
Chapter 6: Advanced Chassis Setup Figure 6-5: Remove the Storage Module Storage Module Storage Module Release Lever Adding Drives to the Storage Module The storage module includes three full sized drive bays and the front LED panel. The storage module can be set up in a variety of conﬁ gurations: There are three basic conﬁ...
Page 98 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Installing Hard Drives into the Drive Tray 1. Open the chassis cover. 2. Locate the drive tray you want to replace and pull the tray release tab for the slot. Figure 6-6: Remove Drive Tray Drive Tray Release Tabs 3.
Page 99 6. Slide the peripheral into the chassis until the tray clicks into place. 7. Repeat these steps for each hard drive tray. Caution! Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, visit the Supermicro Web site at http://www.supermicro.com/products/nfo/ﬁ les/ storage/SAS-CompList.pdf.
Page 100: Adding Five Hard Drives To A Supermicro Mobile Rack
Figure 6-8: Add Hard Drive Rails to the DVD-ROM Drive Hard Drive Tray Hard Drive Rails Adding Five Hard Drives to a Supermicro Mobile Rack: The SC748 tower/4U rackmount chassis accepts a CSE-M35BP mobile rack in order to install hot swappable hard drives. The mobile rack replaces the storage module in the chassis.
Page 101 Chapter 6: Advanced Chassis Setup Figure 6-9: Removing the Drive Bay Drive Tray Release Tabs 4. Install all six storage module rails onto the mobile rack. Each rail requires two screws. Make sure the arrow on the rail points toward the front of the chassis (Figure 6-10).
Page 102: Installing Hard Drives
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Installing Hard Drives The drives are mounted in drive carriers to simplify their installation and removal from the chassis. These carriers also help promote proper airﬂ ow for the drive bays. Installing Hard Drives 1. Press the release button to extend the drive tray handle. 2.
Page 103 Chapter 6: Advanced Chassis Setup Figure 6-12: Removing the Dummy Drive Tray Drive Tray SAS/SATA or SCSI Hard Drive 5. Secure the hard drive to the tray using four screws (Figure 6-13). Figure 6-13: Installing the Hard Drive 6. Insert the hard drive into the chassis. To do this: a.
Page 104: Add-On Card/Expansion Slot Setup
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Add-on Card/Expansion Slot Setup After motherboard installation, install add-on cards to the chassis, such as PCI cards. Installing Add-on and Expansion Cards 1. Locate the release tab on the top of the PCI bracket. 2. Gently apply pressure in the middle of the release tab to unlock the PCI Slot bracket.
Page 105 Chapter 6: Advanced Chassis Setup 4. Remove the screw holding the bracket in place and pull the bracket from the chassis (Figure 6-15). Figure 6-15: Remove PCI Card Slot Guard 5. Install your PCI card or other add-on card into the PCI slot bracket and motherboard.
Page 106: Installing The Air Shroud
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Installing the Air Shroud Air shrouds concentrate airﬂ ow to maximize fan efﬁ ciency. The chassis air shroud does not require screws to set it up. The SC748 tower/4U rackmount chassis supports two different air shroud designs, one for AMD CPUs and, and another for Intel CPUs.
Page 107: System Fans
Chapter 6: Advanced Chassis Setup System Fans Six heavy duty fans provide cooling for the chassis. Three fans are located in the front of the chassis and three fans are in the rear. These fans circulate air through the chassis as a means of lowering the internal temperature of the chassis. The fans come pre-installed to the chassis and are NOT redundant, but each fan is hot-swappable and can be replaced without removing any connections.
Page 108: Replacing A Rear Chassis Fan
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Replacing a Rear Chassis Fan Rear Fan Replacement Procedure (Figure 6-19) 1. Press the rear fan release tab. 2. Pull the fan from the chassis top ﬁ rst. 3. Place the new fan in the chassis bottom ﬁ rst. 4.
Page 109: Power Supply
Chapter 6: Advanced Chassis Setup Power Supply Depending on your chassis model, the SC748 tower/4U rackmount chassis has two 1400 Watt (redundant) power supplies. This power supply is auto-switching capable. This enables it to automatically sense and operate at a 100v to 240v input voltage. An amber light will be illuminated on the power supply when the power is off.
Page 110 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Figure 6-20: Removing a Power Supply Pull the Drive Out Using the Handle Press the Release Button 6-18...
Page 111: Chapter 7 Bios
Chapter 7: BIOS Chapter 7 BIOS Introduction This chapter describes the AMI BIOS Setup Utility for the SuperServer 8048B-TR3F/C0R3FT. The 16 MB SPI AMI BIOS® SM Flash BIOS is stored in a Flash EEPROM and can be easily updated. This chapter describes the basic navigation of the AMI BIOS Setup Utility setup screens.
Page 112: Main Setup
ﬁ elds. The date must be entered in Day MM/DD/YYYY format. The time is entered in HH:MM:SS format. (Note: The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00.). Supermicro X10QBL/X10QBL-CT Version This item displays the SMC version of the BIOS ROM used in this system.
Page 113: Advanced Setup Conﬁ Gurations
Chapter 7: BIOS Memory Information Total Memory This item displays the amount of memory that is available in the system. Advanced Setup Conﬁ gurations Select the Advanced tab to access the following submenu items. Boot Features Boot Conﬁ guration Quiet Boot Use this item to select bootup screen display between POST messages and the OEM logo.
Page 114 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual AddOn ROM Display Mode Use this item to set the display mode for the Option ROM. Select Keep Current to use the current AddOn ROM Display setting. Select Force BIOS to use the Option ROM display set by the system BIOS. The options are Force BIOS and Keep Current.
Page 115 Chapter 7: BIOS Restore on AC Power Loss Use this item to set the power state after a power outage. Select Stay Off for the system power to remain off after a power outage. Select Power On to turn on the system power after a power outage.
Page 116 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Clock Spread Spectrum Select Enable to allow the BIOS to monitor and attempt to reduce the level of Electromagnetic Interference caused by the components whenever needed. The options are Disable and Enable. Cores Enabled This feature allows the user to set the number of CPU cores to enable. Enter "0" to enable all cores.
Page 117 Chapter 7: BIOS DCU (Data Cache Unit) Streamer Prefetcher (Available when supported by the CPU) If this item is set to Enable, the DCU Streamer Prefetcher will prefetch data streams from the cache memory to the DCU (Data Cache Unit) to speed up data accessing and processing for CPU performance enhancement.
Page 118: Cpu P State Control
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual CPU P State Control EIST EIST (Enhanced Intel SpeedStep Technology) allows the system to automatically adjust processor voltage and core frequency to reduce power consumption and heat dissipation. The options are Disabled, and Enabled. Turbo Mode (Available when Intel® EIST Technology is enabled) Select Enabled to use the Turbo Mode to boost system performance.
Page 119: Cpu T State Control
Chapter 7: BIOS Monitor/Mwait Select Enabled to enable the Monitor/MWait instructions. The Monitor instruction monitors a region of memory for writes, and MWait instructions instruct the CPU to stop until the monitored region begins to write. The options are Enable and Disable.
Page 120: North Bridge
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Chipset Conﬁ guration North Bridge This feature is used to conﬁ gure Intel North Bridge settings. Integrated IO Conﬁ guration EV DFX (Device Function On-Hide) Features When this feature is set to Enable, the EV_DFX Lock Bits that are located inside a processor will always remain clear during electric tuning.
Page 121 Chapter 7: BIOS LAN1/2 Use the items below to conﬁ gure the PCI-E settings for a PCI-E port speciﬁ ed by the user. The following items will display: • PCI-E Port Link Status • PCI-E Port Link Max • PCI-E Port Link Speed Link Speed Use this item to select the PCI-E link speed for the PCI-E port speciﬁ...
Page 122 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual IOAT (Intel® IO Acceleration) Conﬁ guration Enable IOAT Select Enable to enable Intel I/OAT (I/O Acceleration Technology) support, which will signiﬁ cantly reduce CPU overhead by leveraging CPU architectural improvements and freeing the system resource for other tasks. The options are Enable and Disable.
Page 123 Chapter 7: BIOS QPI (Quick Path Interconnect) Conﬁ guration QPI General Conﬁ guration  QPI Status The following information will display: • Number of CPU • Number of IIO • LInk Speed • Current QPI Link Frequency • QPI Global MMIO Low Base/Limit •...
Page 124 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual QPI Per Socket Conﬁ guration CPU 0/CPU 1 IO Resource Allocation Ratio Use this feature to set the IO resource-allocation ratio (from 0-8). The default setting is 1. MMIOL Resource Allocation Ratio Use this feature to set the Memory-Mapped IO resource-allocation ratio (from 0-8).
Page 125 Chapter 7: BIOS LRDIMM (Load-Reduction DIMM) Module Delay When this item is set to Disabled, the MRC (Memory Regulator Controller) will not use SPD bytes 90-95 for module delay on LRDIMM memory. The options are Disabled and Auto. Data Scrambling Select Enabled to enable data scrambling to enhance system performance and data integrity.
Page 126: Memory Topology
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Memory Topology This item displays the status of each DIMM module as detected by the BIOS. • Jordon Creek Revision ID • Node • Channel • DIMM Frequency Memory RAS (Reliability_Availability_Serviceability) Conﬁ guration (Available when a DIMM module is detected in a memory slot speciﬁ...
Page 127 Chapter 7: BIOS Leaky Bucket High Bit Use this feature to set the High Bit value for the Leaky Bucket algorithm which is used to check the data transmissions between CPU sockets and the memory controller. The default setting is 41. Memory Interleaving Use this feature to set the DIMM memory interleaving mood.
Page 128: South Bridge
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual DDDC Wirekill Select Enabled for Double-Device Data Correction (DDDC) Wire-kill support which will disable the wire connection between two DRAM devices when they fail. The options are Disabled and Enable. DDDC Wirekill Threshold Use this feature to set the DDDC Wirekill threshold. When the memory errors reach the threshold,wire-connections between the failed DRAM modules will be disconnected.
Page 129 Chapter 7: BIOS Port 60/64 Emulation Select Enabled for I/O port 60h/64h emulation support which will provide complete USB keyboard legacy support for the operating system that does not support Legacy USB devices. The options are Disabled and Enabled. USB Controller 0 Enable Select Enabled to enable USB Controller 0 which supports USB Port 0 to Port 7.
Page 130 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual SATA Port 0~ Port 5 This item displays the information detected on the installed SATA drive on the particular SATA port. • Display of drive number and capacity as detected by the BIOS • Software Preserve Port 0~ Port 5 Select Enabled to enable a SATA port speciﬁ...
Page 131 Chapter 7: BIOS Serial ATA Port 0~ Port 5 This item displays the information detected on the installed SATA drives on the particular SATA port. • Display of drive number and capacity as detected by the BIOS • Software Preserve Support Port 0~ Port 5 Select Enabled to enable a SATA port speciﬁ...
Page 132 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Select Auto to allow the system BIOS to automatically set the maximum Read Request size for a PCI-E device to enhance system performance. The options are Auto, 128 Bytes, 256 Bytes, 512 Bytes, 1024 Bytes, 2048 Bytes, and 4096 Bytes. ASPM Support This feature allows the user to set the Active State Power Management (ASPM) level for a PCI-E device.
Page 133: Acpi Settings
Chapter 7: BIOS This feature controls how the system executes UEFI (Uniﬁ ed Extensible Firmware Interface), and legacy Option ROM. Select Legacy Only to boot the system using a legacy video device. The options are Do not launch, UEFI Only and Legacy Only. VGA Priority This feature allows the user to select the graphics adapter to be used as the primary boot device.
Page 134 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual by the BIOS) Conﬁ guration Security Device Support Select Enabled on this item and enable the TPM jumper on the motherboard to enable onboard security devices to improve data integrity and network security. The options are Enabled and Disabled. TPM (Trusted-Platform Module) State Select Enabled to enable TPM security settings to improve data integrity and network security.
Page 135 Chapter 7: BIOS General ME Conﬁ guration Operational Firmware Version Recovery Firmware Version ME Firmware Features ME Firmware Status #1 ME Firmware Status #2 Current State Error Code Super IO Conﬁ guration Super IO Chip: This item displays the Super IO chip used in the motherboard. Serial Port 1 Conﬁ...
Page 136: Serial Port Console Redirection
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Change Port 2 Settings This option speciﬁ es the base I/O port address and the Interrupt Request address of Serial Port 2 (SOL). Select Disabled to prevent the serial port from accessing any system resources. When this option is set to Disabled, the serial port becomes unavailable.
Page 137 Chapter 7: BIOS Data Bits Use this feature to set the data transmission size for Console Redirection. The options are 7 (Bits) and 8 (Bits). Parity A parity bit can be sent along with regular data bits to detect data transmission errors.
Page 138 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual This feature selects Function Keys and KeyPad settings for Putty, which is a terminal emulator designed for the Windows OS. The options are VT100, LINUX, XTERMR6, SCO, ESCN, and VT400. Redirection After BIOS POST Use this feature to enable or disable legacy Console Redirection after BIOS POST.
Page 139 Chapter 7: BIOS Data Bits Use this feature to set the data transmission size for Console Redirection. The options are 7 (Bits) and 8 (Bits). Parity A parity bit can be sent along with regular data bits to detect data transmission errors.
Page 140: Event Logs
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual This feature selects Function Keys and KeyPad settings for Putty, which is a terminal emulator designed for the Windows OS. The options are VT100, LINUX, XTERMR6, SCO, ESCN, and VT400. Event Logs Select the Event Logs tab to access the following submenu items. ...
Page 141 Chapter 7: BIOS Erasing Settings Erase Event Log Select Enabled to erase the SMBIOS (System Management BIOS) event log, which is completed before a event logging is initialized upon system reboot. The options are No, Yes, Next reset, and Yes, Every reset. When Log is Full Select Erase Immediately to immediately erase SMBIOS error event logs that exceed the limit when the SMBIOS event log is full.
Page 142: Ipmi
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual View SMBIOS Event Log This item allows the user to view the event in the SMBIOS event log. Select this item and press <Enter> to view the status of an event in the log. The following categories are displayed: •...
Page 143 Chapter 7: BIOS Select Enabled to enable all system event logging support at bootup. The options are Enabled and Disabled. Erasing Settings Erase SEL Select Yes, On next reset to erase all system event logs upon next system reboot. Select Yes, On every reset to erase all system event logs upon each system reboot. Select No to keep all system event logs after each system reboot.
Page 144 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual  BMC Network Conﬁ guration The following items will be displayed: • IPMI LAN Selection • IPMI Network Link Status Update IPMI LAN Conﬁ guration Select Yes for the system BIOS to automatically reset the following IPMI settings at next system boot.
Page 145: Security
Chapter 7: BIOS Security This menu allows the user to conﬁ gure the following security settings for the system. Administrator Password Use this item to set the administrator password which is required to enter the BIOS setup utility. The length of the password should be from 3 characters to 20 characters long.
Page 146: Boot
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Boot This submenu allows the user to conﬁ gure the following boot settings for the system. Boot Mood Select Use this item to conﬁ gure boot mood select settings for the machine. The options are Legacy, UEFI, and Dual. Fixed Boot Order Priorities This option prioritizes the order of bootable devices that the system to boot from.
Page 147 Chapter 7: BIOS  Delete Boot Option Use this item to select a boot device to delete from the boot priority list. Delete Boot Option Select the target boot device to delete from the boot option list.  Delete Driver Option Use this item to select a driver to delete from the boot priority list.
Page 148: Save & Exit
SUPERSERVER 8048B-TR3F/C0R3FT User's Manual this drive) • UEFI Boot Order #1 Save & Exit This submenu allows the user to conﬁ gure the Save and Exit settings for the system. Save Changes and Exit When completing the system conﬁ guration changes, select this option to save the changes and exit from the BIOS setup utility.
Page 149 Chapter 7: BIOS Discard Changes and Exit Select this option to quit the BIOS setup without making any changes to the system conﬁ guration. Select Discard Changes and Exit, and press <Enter>. When the dialog box appears, asking you if you want to exit the BIOS setup without saving, select Yes to quit BIOS without saving the changes.
Page 150 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual to save conﬁ guration, select Yes to save the changes, or select No to return to the BIOS without making changes. Discard Changes Select this feature and press <Enter> to discard all the changes and return to the BIOS setup.
Page 151: Appendix A Bios Error Beep Codes
Appendix A: BIOS Error Beep Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed at each system boot, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue to boot.
Page 152 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Notes...
Page 153: Appendix B System Speciﬁ Cations
Appendix B: System Speciﬁ cations Appendix B System Speciﬁ cations Processors Quad Intel E7-4800/8800 v3 Series series (Socket R1 type) processors Note: In order to install the E7-4800/8800 v3 Series CPU, you must make sure that BIOS 1.0 version is installed to your system. Note: You must install at least two processors for full I/O functions to be supported.
Page 154 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual Expansion Slots Four PCI low-profile expansion card slots are available in the rear of the chassis for two (2) PCI-E 3.0 x16 slots (CPU1 Slot1, CPU2 Slot3) and two (2) PCI-E 3.0 x8 slots (CPU2 Slot2, CPU2 Slot4) Serverboard X10QBL-(CT) (Proprietary form factor) Dimensions: (LxW) 16.40"...
Page 155 Appendix B: System Speciﬁ cations Regulatory Compliance Electromagnetic Emissions: FCC Class A, EN 55022 Class A, EN 61000-3-2/-3- 3, CISPR 22 Class A Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11) Safety: CSA/EN/IEC/UL 60950-1 Compliant, UL or CSA Listed (USA and Canada), CE Marking (Europe) California Best Management Practices Regulations for Perchlorate Materials:...
Page 156 SUPERSERVER 8048B-TR3F/C0R3FT User's Manual (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in signiﬁ...

This manual is also suitable for:

Superserver 8048b-c0r3ft

Supermicro SUPERSERVER 8048B-TR3 User Manual

Chapter 1 Introduction

Chapter 2 Server Installation

Chapter 3 System Interface

Chapter 4 Standardized Warning Statements for AC Systems

Chapter 5 Advanced Serverboard Setup

Chapter 6 Advanced Chassis Setup

Chapter 7 BIOS

Appendix A BIOS Error Beep Codes

Appendix B System Speciﬁ Cations

Quick Links

Need help?

Questions and answers

Related Manuals for Supermicro SUPERSERVER 8048B-TR3

Summary of Contents for Supermicro SUPERSERVER 8048B-TR3

This manual is also suitable for:

Table of Contents
