SuperServer
8048B-TR4FT
USER'S MANUAL
Revision 1.0b

Advertisement

Table of Contents
loading

Related Manuals for Supermicro 8048B-TR4FT

Summary of Contents for Supermicro 8048B-TR4FT

  • Page 1 SuperServer 8048B-TR4FT USER'S MANUAL Revision 1.0b...
  • Page 2 This product, including software and documentation, is the property of Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except as expressly permitted by the terms of said license.

  • Page 3: About This Manual

    About This Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SuperServer 8048B-TR4FT. Installation and maintenance should be performed by experienced technicians only. The SuperServer 8048B-TR4FT is a high-end server based on the...
  • Page 4 SUPERSERVER 8048B-TR4FT USER'S MANUAL Chapter 6: Advanced Chassis Setup Refer to Chapter 6 for detailed information on the SC848XTS-R3240BP server chassis. You should follow the procedures given in this chapter when installing, removing or reconfi guring SATA or peripheral drives and when replacing system power supply units and cooling fans.
  • Page 5 Preface Notes...

  • Page 6: Table Of Contents

    SUPERSERVER 8048B-TR4FT USER'S MANUAL Table of Contents Chapter 1 Introduction Overview ......................1-1 Serverboard Features ..................1-2 Processors ...................... 1-2 Memory ......................1-2 Serial ATA ....................... 1-2 PCI Expansion Slots ..................1-2 Server Chassis Features ................1-3 System Power ....................1-3 SATA Subsystem .....................
  • Page 7 Table of Contents Installing the Chassis into a Rack..............2-8 Removing the Chassis from the Rack ............2-9 Chapter 3 System Interface Overview ......................3-1 Control Panel Buttons ..................3-2 Power ......................3-2 Reset ....................... 3-2 Control Panel LEDs ..................3-2 Power ......................
  • Page 8 SUPERSERVER 8048B-TR4FT USER'S MANUAL Removing the Heatsink ................... 5-9 Installing Memory .................... 5-9 Memory Support ....................5-9 Populating RDIMM/3DS LRDIMM (ECC) Memory Modules ....5-12 I/O Module Board ..................5-13 Adding PCI Expansion Cards ............... 5-15 Baseboard Details ..................5-16 Connector Defi...
  • Page 9 Table of Contents Save & Exit ....................7-35 Appendix A BIOS Error Beep Codes Appendix B System Specifi cations...
  • Page 10 SUPERSERVER 8048B-TR4FT USER'S MANUAL Notes...

  • Page 11: Chapter 1 Introduction

    Chapter 1 Introduction Overview The SuperServer 8048B-TR4FT is a high-end server comprised of four main subsystems: the SC848XTS-R3240BP 4U server chassis and the X10QBi quad processor serverboard (baseboard), eight X10QBi-MEM2 memory module cards and one AOM-X10QBi-A I/O card. Please refer to our website for information on operating systems that have been certifi...

  • Page 12: Serverboard Features

    SUPERSERVER 8048B-TR4FT USER'S MANUAL Serverboard Features At the heart of the SuperServer 8048B-TR4FT lies the X10QBi, a quad processor serverboard based on the Intel® C602J chipset and designed to provide maximum performance. The X10QBi acts as a baseboard, into which an I/O card and memory cards may be installed.

  • Page 13: Server Chassis Features

    Chapter 1: Introduction Server Chassis Features The following is a general outline of the main features of the SC848XTS server chassis. System Power The SC848XTS chassis model includes four 1620 Watt power supplies consisting of two active and two backup power modules. In the event your power supply fails, replacement is simple and can be accomplished without tools.

  • Page 14: Mounting Rails

    SUPERSERVER 8048B-TR4FT USER'S MANUAL Mounting Rails The SC848XTS includes a set of quick-release rails, and can be placed in a rack for secure storage and use. To setup your rack, follow the instructions described in Chapter 2. Memory Modules The X10QBi-MEM2 memory boards plug directly into the X10QBi baseboard. The memory boards feature a Jordan Creek C114 memory buffer chip.

  • Page 15: System Block Diagram

    Chapter 1: Introduction Figure 1-1. Intel Intel C602J Chipset: System Block Diagram Note: This is a general block diagram and may not exactly repre- sent the features on your serverboard. See the previous pages for the actual specifi cations of your serverboard. This block diagram is intended for your reference only.

  • Page 16: Contacting Supermicro

    SUPERSERVER 8048B-TR4FT USER'S MANUAL Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 17: Chapter 2 Rack Installation

    Chapter 2: Server Installation Chapter 2 Rack Installation Overview This chapter provides a quick setup checklist to get your chassis up and running. Following these steps in the order given should enable you to have the system operational within a minimal amount of time. Unpacking the System You should inspect the box which the chassis was shipped in and note if it was damaged in any way.

  • Page 18: Warnings And Precautions

    SUPERSERVER 8048B-TR4FT USER'S MANUAL Warnings and Precautions Rack Precautions • Ensure that the leveling jacks on the bottom of the rack are fully extended to the fl oor with the full weight of the rack resting on them. • In single rack installations, stabilizers should be attached to the rack.

  • Page 19: Reduced Airfl Ow

    Chapter 2: Server Installation Reduced Airfl ow Equipment should be mounted into a rack so that the amount of airfl ow required for safe operation is not compromised. Mechanical Loading Equipment should be mounted into a rack so that a hazardous condition does not arise due to uneven mechanical loading.

  • Page 20: Rack Mounting Instructions

    SUPERSERVER 8048B-TR4FT USER'S MANUAL Rack Mounting Instructions This section provides information on installing the SC848XTS chassis into a rack unit with the rails provided. There are a variety of rack units on the market, which may mean that the assembly procedure will differ slightly. You should also refer to the installation instructions that came with the rack unit you are using.

  • Page 21: Installing The Inner Rails On The Chassis

    Chapter 2: Server Installation Figure 2-2. Installing the Rails Installing the Inner Rails on the Chassis Installing the Inner Rails 1. The inner rails are etched with "L" (left side) and "R" (right side). Place one inner rail on the side of the chassis, aligning the hooks of the chassis with the inner rail holes.

  • Page 22: Installing The Outer Rails Onto A Rack

    SUPERSERVER 8048B-TR4FT USER'S MANUAL Figure 2-3. Assembling the Outer Rails Attach Outer Rails Together Secure to the Secure to the Front of the Rack Rear of the Rack Fixed Pins Installing the Outer Rails onto a Rack Installing the Outer Rails 1.
  • Page 23 Chapter 2: Server Installation Figure 2-4. Installing the Outer Rails to the Rack Screws and Washers Screws and Washers Note: fi gures are for illustrative purposes only. Always install servers into racks from the bottom up. Stability hazard. The rack stabilizing mechanism must be in place, or the rack must be bolted to the fl...

  • Page 24: Installing The Chassis Into A Rack

    SUPERSERVER 8048B-TR4FT USER'S MANUAL Figure 2-4. Installing the Chassis into a Rack Note: fi gures are for illustrative purposes only. Always install servers into racks from the bottom up. Installing the Chassis into a Rack Installing the Chassis into a Rack: 1.

  • Page 25: Removing The Chassis From The Rack

    Chapter 2: Server Installation Removing the Chassis from the Rack Caution! It may be dangerous for a single person to off-load the heavy chassis from the rack without assistance. Be sure to have suffi cient assistance supporting the chassis when removing it from the rack. Figure 2-5.
  • Page 26 SUPERSERVER 8048B-TR4FT USER'S MANUAL Notes 2-10...

  • Page 27: Chapter 3 System Interface

    Chapter 3: System Interface Chapter 3 System Interface Overview There are several LEDs on the control panel as well as others on the drive carriers to keep you constantly informed of the overall status of the system as well as the activity and health of specifi...

  • Page 28: Control Panel Buttons

    SUPERSERVER 8048B-TR4FT USER'S MANUAL Control Panel Buttons There are two push-buttons included on the control panel: a power button and a reset button. Power The main power button is used to apply or remove power from the power supply to the server system. Turning off system power with this button removes the main power but keeps standby power supplied to the system, consequently you must unplug the power cord before servicing the system.

  • Page 29: Nic1

    Chapter 3: System Interface NIC1 Indicates network activity on GLAN1 when fl ashing. NIC2 Indicates network activity on GLAN2 when fl ashing. Universal Information LED See the following table for the status shown by this LED. Universal Information LED Status Description Continuously on and red An overheat condition has occurred.

  • Page 30: Drive Carrier Leds

    SUPERSERVER 8048B-TR4FT USER'S MANUAL Drive Carrier LEDs The chassis includes externally accessible SAS/SATA drives. Each drive carrier displays two status LEDs on the front of the carrier. LED Color State Status Activity LED Green Solid On SAS drive installed Green...

  • Page 31: Chapter 4 Standardized Warning Statements For Ac Systems

    The following statements are industry standard warnings, provided to warn the user of situations which have the potential for bodily injury. Should you have questions or experience difficulty, contact Supermicro's Technical Support department for assistance. Only certifi ed technicians should attempt to install or confi gure components.
  • Page 32 SUPERSERVER 8048B-TR4FT USER'S MANUAL Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befi nden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
  • Page 33 Warning Statements for AC Systems ‫ﺟﺴﺪﯾﺔ‬ ‫اﺻﺎﺑﺔ‬ ‫ﺗﺘﺴﺒﺐ ﻓﻲ‬ ‫ﺣﺎﻟﺔ ﯾﻤﻜﻦ أن‬ ‫اﻧﻚ ﻓﻲ‬ ‫ﺧﻄﺮ‬ ‫ﯾﻌﻨﻲ‬ ‫ھﺬا اﻟﺮﻣﺰ‬ !‫ﺗﺤﺬﯾﺮ‬ ‫اﻟﺪواﺋﺮ‬ ‫ﺑﺎﻟﻤﺨﺎطﺮ اﻟﻨﺎﺟﻤﺔ ﻋﻦ‬ ‫ﻦ ﻋﻠﻰ ﻋﻠﻢ‬ ، ‫ﻛ‬ ‫ﻣﻌﺪات‬ ‫ﺗﻌﻤﻞ ﻋﻠﻰ أي‬ ‫ﻗﺒﻞ أن‬ ‫اﻟﻜﮭﺮﺑﺎﺋﯿﺔ‬ ‫ﺣﻮادث‬ ‫أي‬ ‫وﻗﻮع‬ ‫ﻤﻨﻊ‬ ‫ﻟ‬ ‫اﻟﻮﻗﺎﺋﯿﺔ‬...

  • Page 34: Installation Instructions

    SUPERSERVER 8048B-TR4FT USER'S MANUAL Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 設置手順書 システムを電源に接続する前に、 設置手順書をお読み下さい。 警告 将此系统连接电源前,请先阅读安装说明。 警告 將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación.

  • Page 35: Circuit Breaker

    Chapter 4: Warning Statements for AC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 250 V, 20 A. サーキッ ト ・ ブレーカー この製品は、 短絡 （過電流） 保護装置がある建物での設置を前提としています。 保護装置の定格が250 V、...

  • Page 36: Power Disconnection Warning

    SUPERSERVER 8048B-TR4FT USER'S MANUAL ‫ﻓﻲ‬ ‫اﻟﺘﻲ ﺗﻢ ﺗﺜﺒﯿﺘﮭﺎ‬ ‫ﻣﻦ اﻟﺪواﺋﺮاﻟﻘﺼﯿﺮة‬ ‫اﻟﺤﻤﺎﯾﺔ‬ ‫ﻣﻌﺪات‬ ‫ﯾﻌﺘﻤﺪ ﻋﻠﻰ‬ ‫ھﺬا اﻟﻤﻨﺘﺞ‬ ‫اﻟﻤﺒﻨﻰ‬ ‫أﻛﺜﺮ ﻣﻦ‬ ‫ﻟﯿﺲ‬ ‫ﻮﻗﺎﺋﻲ‬ ‫اﻟ‬ ‫اﻟﺠﮭﺎز‬ ‫ﺗﻘﯿﯿﻢ‬ ‫أن‬ ‫ﺗﺄﻛﺪ ﻣﻦ‬ 20A, 250V 경고! 이 제품은 전원의 단락(과전류)방지에 대해서 전적으로 건물의 관련 설비에 의존합니다. 보호장치의 정격이 반드시 250V(볼트), 20A(암페어)를 초과하지...
  • Page 37 Chapter 4: Warning Statements for AC Systems Warnung Das System muss von allen Quellen der Energie und vom Netzanschlusskabel getrennt sein, das von den Spg.Versorgungsteilmodulen entfernt wird, bevor es auf den Chassisinnenraum zurückgreift, um Systemsbestandteile anzubringen oder zu entfernen. ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema.

  • Page 38: Equipment Installation

    SUPERSERVER 8048B-TR4FT USER'S MANUAL Equipment Installation Warning! Only trained and qualifi ed personnel should be allowed to install, replace, or service this equipment. 機器の設置 トレーニングを受け認定された人だけがこの装置の設置、 交換、 またはサービスを許可 されています。 警告 只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。 警告 只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifi...

  • Page 39: Restricted Area

    Chapter 4: Warning Statements for AC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwalifi ceerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.

  • Page 40: Battery Handling

    SUPERSERVER 8048B-TR4FT USER'S MANUAL ‫אזור עם גישה מוגבלת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ .('‫כלי אבטחה בלבד )מפתח, מנעול וכד‬ ‫ﻣﺤﻈﻮرة‬ ‫ﻣﻨﺎطﻖ‬ ‫ﻟﺘﺮﻛﯿﺒﮭﺎ ﻓﻲ‬ ‫ھﺬه اﻟﻮﺣﺪة‬ ‫ﺗﺨﺼﯿﺺ‬ ‫ﺗﻢ‬ ،‫أداة ﺧﺎﺻﺔ‬ ‫ﻣﻦ ﺧﻼل اﺳﺘﺨﺪام‬...
  • Page 41 Chapter 4: Warning Statements for AC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.

  • Page 42: Redundant Power Supplies

    SUPERSERVER 8048B-TR4FT USER'S MANUAL Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 冗長電源装置 このユニッ トは複数の電源装置が接続されている場合があります。 ユニッ トの電源を切るためには、 すべての接続を取り外さなければなりません。 警告 此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。 警告 此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden.

  • Page 43: Backplane Voltage

    Chapter 4: Warning Statements for AC Systems ‫اﻣﺪاد اﻟﻄﺎﻗﺔ‬ ‫ﺑﻮﺣﺪات‬ ‫ﻋﺪة اﺗﺼﺎﻻت‬ ‫ﺠﮭﺎز‬ ‫اﻟ‬ ‫ﯾﻜﻮن ﻟﮭﺬا‬ ‫ﻗﺪ‬ ‫اﻟﻜﮭﺮﺑﺎء‬ ‫ﻋﻦ‬ ‫ﻮﺣﺪة‬ ‫اﻟ‬ ‫ﻟﻌﺰل‬ ‫ﻛﺎﻓﺔ اﻻﺗﺼﺎﻻت‬ ‫ﯾﺠﺐ إزاﻟﺔ‬ 경고! 이 장치에는 한 개 이상의 전원 공급 단자가 연결되어 있을 수 있습니다. 이 장치에 전원을...

  • Page 44: Comply With Local And National Electrical Codes

    SUPERSERVER 8048B-TR4FT USER'S MANUAL Attention Lorsque le système est en fonctionnement, des tensions électriques circulent sur le fond de panier. Prendre des précautions lors de la maintenance. ‫מתח בפנל האחורי‬ !‫הרה‬ ‫אז‬ ‫קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך‬...

  • Page 45: Product Disposal

    Chapter 4: Warning Statements for AC Systems ¡Advertencia! La instalacion del equipo debe cumplir con las normas de electricidad locales y nacionales.Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ ‫הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫התקנת‬...

  • Page 46: Hot Swap Fan Warning

    SUPERSERVER 8048B-TR4FT USER'S MANUAL Warnung Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen des Landes erfolgen. ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement.
  • Page 47 Chapter 4: Warning Statements for AC Systems 当您从机架移除风扇装置，风扇可能仍在转动。小心不要将手指、螺丝起子和其他 物品太靠近风扇 警告 當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他 物品太靠近風扇。 Warnung Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt. ¡Advertencia! Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.

  • Page 48: Power Cable And Ac Adapter

    fi re. Electrical Appliance and Material Safety Law prohibits the use of UL or CSA -certifi ed cables (that have UL/CSA shown on the code) for any other electrical devices than products designated by Supermicro only. 電源コードとACアダプター...
  • Page 49 Appareils électroménagers et de loi sur la sécurité Matériel interdit l'utilisation de UL ou CSA câbles certifi és qui ont UL ou CSA indiqué sur le code pour tous les autres appareils électriques que les produits désignés par Supermicro seulement.
  • Page 50 Elektrisch apparaat en veiligheidsinformatiebladen wet verbiedt het gebruik van UL of CSA gecertifi ceerde kabels die UL of CSA die op de code voor andere elektrische apparaten dan de producten die door Supermicro alleen.

  • Page 51: Chapter 5 Advanced Serverboard Setup

    Chapter 5: Advanced Serverboard Setup Chapter 5 Advanced Serverboard Setup This chapter covers the steps required to connect the data and power cables and install add-on cards. All serverboard jumpers and connections are also described. A layout and quick reference chart are included in this chapter for your reference. Remember to completely close the chassis when you have fi...

  • Page 52: Connecting Cables

    (make sure the red wires connect to the pin 1 locations). If you are confi guring the system, keep the airfl ow in mind when routing the cables. The following cables need to be connected for the SuperServer 8048B-TR4FT system: •...

  • Page 53: Control Panel Connectors And I/O Ports

    Chapter 5: Advanced Serverboard Setup Control Panel Connectors and I/O Ports The I/O ports on the are located at the rear of the system. See Figure 5-1 and Figure 5-2 below for the locations of the various I/O ports. See Figure 6-1 for the location of these ports on the rear of the chassis.

  • Page 54: Connecting The Control Panel

    SUPERSERVER 8048B-TR4FT USER'S MANUAL Figure 5-2. Rear I/O Ports (Horizontal) Back Panel I/O Ports USB Port USB Port Serial (COM) Port Connecting the Control Panel JF1 contains header pins for various front control panel connectors. See Figure 5-3 for the pin locations of the various front control panel buttons and LED indicators.

  • Page 55: Processor And Heatsink Installation

    CPU socket cap is in place and none of the socket pins are bent; otherwise, contact your retailer immediately. • Refer to the Supermicro website for updates on CPU support. • When one CPU is installed, be sure to installed to CPU Socket 1.
  • Page 56 SUPERSERVER 8048B-TR4FT USER'S MANUAL 2. Press the second load lever labeled Release the lever labeled "Close 1st" "Close 1st" to release the load plate from its locked position. 3. With the second lever fully Open the load retracted, gently push down on the plate.
  • Page 57 Chapter 5: Advanced Serverboard Setup 6. Carefully lower the CPU straight down into the socket. Do not move the CPU horizontally, and do not rub the pins of the socket. This may damage the CPU or the socket. Caution: You can only install the CPU into the socket in one direction. Make sure that the CPU is properly inserted into the socket before closing the load plate.

  • Page 58: Installing A Passive Cpu Heatsink

    SUPERSERVER 8048B-TR4FT USER'S MANUAL 9. Close and lock the "Open 1st" lever. Push down and lock the lever labeled "Open 1st" Installing a Passive CPU Heatsink 1. Do not apply any thermal grease to the heatsink or the CPU die; the required amount has already been applied.

  • Page 59: Removing The Heatsink

    9. Reverse the steps above to remove DIMM modules. Memory Support With all eight cards fully populated, the system will support up to a total of 12 TB of DDR4-1866/1600/1333/1066 MHz speed ECC RDIMM/3DS LRDIMM memory. Check the Supermicro website (www.supermicro.com) for the latest memory support information.
  • Page 60 SUPERSERVER 8048B-TR4FT USER'S MANUAL Figure 5-4. X10QBi-MEM2 Memory Card Layout PRESENT LEDs DIMM D1 DIMM B1 DIMM D2 DIMM B2 DIMM B3 DIMM D3 DIMM C1 DIMM A1 DIMM C2 DIMM A2 DIMM C3 DIMM A3 BAR CODE X10QBi-MEM2 Rev. 1.01...
  • Page 61 Chapter 5: Advanced Serverboard Setup After populating DIMMs on the memory cards, follow the table below to Install one or two populated memory cards for each CPU installed on the baseboard. The baseboard has eight slots to accommodate eight memory cards. CPUs and their Corresponding Memory Cards CPU# Corresponding DIMM Modules...

  • Page 62: Populating Rdimm/3Ds Lrdimm (Ecc) Memory Modules

    Mixing of DIMMs of different types or speeds is not allowed. Note 2: For detailed information on memory support and updates, please refer to the Supermicro Recommended Memory List on our website at http://supermicro. com/support/resources/mem.cfm.

  • Page 63: I/O Module Board

    Chapter 5: Advanced Serverboard Setup I/O Module Board Figure 5-6. AOM-X10QBi-A I/O Module Layout AOM-X10QBi-A Rev. 1.00 JPB1 JPG1 JPL1 LAN CTRL LED28 JEDUID1 Jumpers Location Jumper Description Default JPL1 LAN Enable/Disable Pins 1-2 (Enabled) JPB1 BMC Enable/Disable Pins 1-2 (Enabled) JPG1 VGA Enable/Disable Pins 1-2 (Enabled)
  • Page 64 SUPERSERVER 8048B-TR4FT USER'S MANUAL Slot for I/O Module X10QBi Rev:1.00 BAR CODE MAC CODE MAC CODE 5-14...

  • Page 65: Adding Pci Expansion Cards

    Chapter 5: Advanced Serverboard Setup Adding PCI Expansion Cards The 8048B-TR4FT supports up to 11 PCI Express cards (four x16 and seven x8 slots). Installing an Expansion Card 1. After powering down the system, remove the PCI slot shield. 2. Fully seat the card into the slot, pushing down with your thumbs evenly on both sides of the card.

  • Page 66: Baseboard Details

    SUPERSERVER 8048B-TR4FT USER'S MANUAL Baseboard Details Figure 5-8. X10QBi Baseboard Layout JIPMB1 FAN10 LED10 LED9 LED8 LED7 LED14 I-SATA5 LED13 LED12 LED11 I-SATA4 JIO1 I-SATA3 JWD1 I-SATA2 JI2C1 LEDIO1 JBT1 JI2C2 I-SATA0 JVRM_I2C1 JPME2 JPME1 LED15 LED28 LED23 JPT1 LED2...
  • Page 67 Chapter 5: Advanced Serverboard Setup X10QBi Quick Reference Jumper Description Default Setting JBT1 Clear CMOS See Section 5-10 C1/JI SMB to PCI-E Slots Pins 2-3 (Disabled) JPB1 (on I/O module) BMC Enabled Pins 1-2 (Enabled) JPG1 (on I/O module) VGA Enable Pins 1-2 (Enabled) JPME1 ME Mode Recovery...

  • Page 68: Connector Defi Nitions

    SUPERSERVER 8048B-TR4FT USER'S MANUAL Connector Defi nitions Power Connectors ATX Power 24-pin Connector Pin Defi nitions A 24-pin main power supply connector Pin # Defi nition Pin # Defi nition (JPW 1) and six 8-pin power connectors +3.3V +3.3V (JPW2-JPW7) are located on the X10DBi -12V +3.3V...
  • Page 69 Chapter 5: Advanced Serverboard Setup PW_ON Connector Power Button Pin Defi nitions The Power Button connection is located (JF1) on pins 1 and 2 of JF1. Momentarily Pin# Defi nition contacting both pins will power on/off Signal the system. This button can also be Ground configured to function as a suspend button (with a setting in the BIOS - See...
  • Page 70 SUPERSERVER 8048B-TR4FT USER'S MANUAL NIC1/2 (LAN1/2) LED Indicators NIC1/2 LEDs Pin Defi nitions (JF1) The NIC (Network Interface Controller) Pin# Defi nition LED cLED indicator onnections for GLAN NIC2 Activity LED port 1 are located on pins 11 and 12 of...
  • Page 71 Chapter 5: Advanced Serverboard Setup Universal Serial Bus (USB) Type A USB (USB4/5) Pin Defi nitions Three Universal Serial Bus headers Pin# Defi nition provide six USB connections on the baseboard (USB 0/1, 2/3, 6/7). Additionally, two Type A USB connectors (USB4, USB5) are also located on the board (cables not included).
  • Page 72 SUPERSERVER 8048B-TR4FT USER'S MANUAL Ethernet LAN Ports LAN Ports Pin Defi nition Two Ethernet ports (LAN1/LAN2) are Pin# Defi nition Pin# Defi nition located on the AOM-X10QBi-A I/O P2V5SB SGND module. In addition, a dedicated IPMI LAN is also located on the I/O module...
  • Page 73 Note: UID can also be triggered via the IPMI on the system serverboard. For more information on the IPMI, please refer to the IPMI User's Guide posted on our website at http://www.supermicro. com. Serial Ports Serial COM) Ports Pin Defi nitions COM1 is located on the AOM-X10QBi-A Pin # Defi...
  • Page 74 SUPERSERVER 8048B-TR4FT USER'S MANUAL Power LED/Speaker PWR LED Connector Pin Defi nitions On the JD1 header, pins 1-3 are used for Pin Setting Defi nition power LED indication, and pins 4-7 are Pin 1 Anode (+) for the speaker. See the tables on the...

  • Page 75: 5-10 Jumper Settings

    Chapter 5: Advanced Serverboard Setup IPMB IPMB Header Pin Defi nitions A System Management Bus header for Pin# Defi nition IPMI 2.0 is located at JIPMB1. Connect Data the appropriate cable here to use the Ground IPMB I C connection for your system. Clock No Connection 5-10 Jumper Settings...
  • Page 76 SUPERSERVER 8048B-TR4FT USER'S MANUAL BMC Enable BMC Enable/Disable Jumper Settings Jumper JPB1 allows you to enable the Jumper Setting Defi nition BMC controller on the X10QBi-A I/O Pins 1-2 BMC Enable module for IPMI/KVM support. The default setting is Normal. Refer to the...
  • Page 77 Chapter 5: Advanced Serverboard Setup C Bus to PCI-Exp. Slots C for PCI-E Slots Jumper Settings Use JI C1 and JI C2 to connect the Jumper Setting Defi nition System Management Bus (I C) to Closed Enabled the PCI-E slots to improve system Open Normal performance.

  • Page 78: 5-11 Onboard Indicators

    SUPERSERVER 8048B-TR4FT USER'S MANUAL 5-11 Onboard Indicators LAN LEDs GLAN LED Link Speed Activity Two 10Gbps Ethernet LAN ports are located on the IO Backplane on the serverboard. Each LAN port has two LAN Port Activity LED (Left) LEDs. The Orange LED indicates LED State activity.

  • Page 79: 5-12 Serial Ata Ports

    3.0 and four SATA 2.0 ports). See the table on the right for pin defi nitions. Note: For more information on SATA or RAID confi guration, please refer to the Intel SATA HostRAID User's Guide on our website at http://www.supermicro.com. 5-29...

  • Page 80: 5-13 Installing Software

    SUPERSERVER 8048B-TR4FT USER'S MANUAL 5-13 Installing Software The Supermicro FTP site contains drivers and utilities for your system at ftp://ftp. supermicro.com. Some of these must be installed, such as the chipset driver. After accessing the FTP site, go into the CDR_Images directory and locate the ISO fi...

  • Page 81: Superdoctor® 5

    Chapter 5: Advanced Serverboard Setup SuperDoctor® 5 The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface in Windows and Linux operating systems. The program monitors system health information such as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 82: 5-14 Onboard Battery

    SUPERSERVER 8048B-TR4FT USER'S MANUAL 5-14 Onboard Battery Caution: There is a danger of explosion if the onboard battery is installed upside down, which will reverse its polarites (see Figure 5-11). This battery must be replaced only with the same or an equivalent type recommended by the manufacturer (CR2032).
  • Page 83 Chapter 5: Advanced Serverboard Setup Notes 5-33...

  • Page 84: Chapter 6 Advanced Chassis Setup

    Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform maintenance on the SC848XTS-R3240BP chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered.

  • Page 85: Control Panel

    SUPERSERVER 8048B-TR4FT USER'S MANUAL Figure 6-1. Front and Rear Chassis Views Control Panel Hard Drives (24) Power Supplies (4) I/O Ports Control Panel The control panel is located on the front left handle of the chassis. See Chapter 3 for details on the LEDs and the control panel buttons.

  • Page 86: Installing Hard Drives

    2. Use the handle to pull the drive carrier out of the chassis. Figure 6-2. Removing a Hard Drive Carrier Note: Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, visit the Supermicro website at http://www.supermicro.com/products/nfo/files/storage/SAS-1-...
  • Page 87 SUPERSERVER 8048B-TR4FT USER'S MANUAL Warning: Except for short periods of time (swapping hard drives), do not operate the server with the hard drive bays empty. Installing a Hard Drive to the Carrier 1. Remove the two screws securing the dummy drive to the drive carrier and remove the dummy drive.

  • Page 88: Accessing The Inside Of The System

    Chapter 6: Advanced Chassis Setup Accessing the Inside of the System Removing the Chassis Cover You will need to access the inside of the system to complete certain procedures such as replacing fans. Removing the Chassis Cover 1. Power down the system and unplug the cords from the back of the power supplies.

  • Page 89: Installing The Air Shroud

    SUPERSERVER 8048B-TR4FT USER'S MANUAL Installing the Air Shroud Air Shrouds Air shrouds concentrate airfl ow to maximize fan effi ciency. The SC848XTS chassis air shrouds (p/n MCP-310-41804-0B) do not require screws to install them. Installing the Air Shroud 1. Power down the system, remove the cords from the back of the power supplies and open the chassis top cover.

  • Page 90: Cooling System

    Chapter 6: Advanced Chassis Setup Cooling System The SC848XTS chassis contains four 9-cm system fans that provide cooling for the chassis and three 8-cm exhaust fans at the rear of the chassis for expelling hot air. All fans are hot-swappable, there is no need to power down the system when replacing fans.
  • Page 91 SUPERSERVER 8048B-TR4FT USER'S MANUAL the SC848 chassis includes three hot-swappable external cooling fans that may be replaced without powering down the system. Replacing an Exhaust Fan 1. Press the release tab on the top of the fan you wish to replace.

  • Page 92: Power Supply

    Chapter 6: Advanced Chassis Setup Power Supply The 8048B-TR4FT has four (2+2) redundant, high-effi ciency 1620 Watt power supplies. The power supply modules are auto-switching capable, enabling them to automatically sense and operate at a 100v to 240v input voltage.
  • Page 93 SUPERSERVER 8048B-TR4FT USER'S MANUAL Notes 6-10...

  • Page 94: Chapter 7 Bios

    AMI BIOS setup utility. This setup utility can be accessed by pressing <Delete> at the appropriate time during system boot. Note: For AMI UEFI BIOS Recovery, please refer to the UEFI BIOS Recovery User Guide posted at http://www.supermicro.com/support/manuals/.

  • Page 95: Starting The Setup Utility

    SUPERSERVER 8048B-TR4FT USER'S MANUAL Starting the Setup Utility Normally, the only visible Power-On Self-Test (POST) routine is the memory test. As the memory is being tested, press the <Delete> key to enter the main menu of the AMI BIOS setup utility. From the main menu, you can access the other setup screens.

  • Page 96: Advanced Setup Confi Gurations

    Chapter 7: BIOS Supermicro X10QBi Version This item displays the SMC version of the BIOS ROM used in this system. Build Date This item displays the date that the BIOS setup utility was built. Memory Information Total Memory This item displays the amount of memory that is available in the system.
  • Page 97 SUPERSERVER 8048B-TR4FT USER'S MANUAL AddOn ROM Display Mode Use this item to set the display mode for the Option ROM. Select Keep Current to use the current AddOn ROM Display setting. Select Force BIOS to use the Option ROM display set by the system BIOS. The options are Force BIOS and Keep Current.
  • Page 98 Chapter 7: BIOS Restore on AC Power Loss Use this item to set the power state after a power outage. Select Stay Off for the system power to remain off after a power outage. Select Power On to turn on the system power after a power outage.
  • Page 99 SUPERSERVER 8048B-TR4FT USER'S MANUAL Cores Enabled Use this item to set the number of CPU cores to be enabled in your system. Enter "0" to enable all cores. There are 14 cores available in the system. The default setting is 0.
  • Page 100 Chapter 7: BIOS DCU (Data Cache Unit) Streamer Prefetcher (Available when supported by the CPU) If set to Enable, the DCU Streamer Prefetcher will prefetch data streams from the cache memory to the DCU to speed up data accessing and processing for CPU performance enhancement.
  • Page 101 SUPERSERVER 8048B-TR4FT USER'S MANUAL Down Stream PECI (Platform Environment Control Interface) Select Enable to allow the client server to interact with the host server directly to achieve better host-client communication in the PECI platform, which will result in power saving and energy use effi ciency. The options are Disable and Enable.

  • Page 102: Cpu T State Control

    Chapter 7: BIOS  CPU C State Control (Available when Power Technology is set to Custom) C2C3TT (C2-to-C3 Transaction Timer) This item is used to set the transaction timer from the C2 state to the C3 state. Enter 0 for Auto, which will allow the BIOS to confi gure the transaction timer automatically.

  • Page 103: North Bridge

    SUPERSERVER 8048B-TR4FT USER'S MANUAL  CPU Advanced PM (Power Management) Tuning  Energy Perf (Performance) BIAS Energy Performance Tuning Select BIOS to allow the system BIOS to confi gure the 'Energy-Performance Tuning Bias' setting below. The options are BIOS and OS.
  • Page 104 Chapter 7: BIOS CPU-PCH DMI/Onboard LAN/CPU1 Slot1 x8/CPU1 Slot2 Use the items below to confi gure the PCI-E settings for a PCI-E port specifi ed by the user. The following items will display: • PCI-E Port Link Status • PCI-E Port Link Max •...
  • Page 105 SUPERSERVER 8048B-TR4FT USER'S MANUAL IIO2 Confi guration CPU3 Slot6 x8/CPU3 Slot7 x8/CPU3 Slot9 x16 Use the items below to confi gure the PCI-E settings for a PCI-E port specifi ed by the user. The following items will display: • PCI-E Port Link Status •...
  • Page 106 Chapter 7: BIOS No Snoop Select Enable to support no-snoop mode for each CB device. The options are Disable and Enable. Disable TPH Select Enable to de-activate TLP Processing Hint support. The options are Disable and Enable.  Intel VT for Directed I/O (VT-d) ®...
  • Page 107 SUPERSERVER 8048B-TR4FT USER'S MANUAL QPI (Quick Path Interconnect) Confi guration QPI Status The following information will display: • Number of CPU • Number of IIO • LInk Speed • Current QPI Link Frequency • QPI Global MMIO Low Base/Limit •...
  • Page 108 Chapter 7: BIOS MMIOL Resource Allocation Ratio Use this feature to set the Memory-Mapped IO resource-allocation ratio (from 0-8). The default setting is 1. IIO UniPhy Disable Select Yes to hide the entire UNIFY in L2 cache. The options are No and Yes. Memory Confi...

  • Page 109: Memory Topology

    SUPERSERVER 8048B-TR4FT USER'S MANUAL 3DS LRDIMM (Load-Reduction DIMM) Module Delay When this item is set to Disabled, the MRC (Memory Regulator Controller) will not use SPD bytes 90-95 for module delay on 3DS LRDIMM memory. The options are Disabled and Auto.
  • Page 110 Chapter 7: BIOS Memory RAS (Reliability_Availability_Serviceability) Confi guration This submenu will display the following items: • Current Memory Mode • Mirroring • Sparing Memory Rank Sparing This item indicates if memory rank sparing is supported by the motherboard. Memory rank sparing enhances system performance. The options are Enabled and Disabled.
  • Page 111 SUPERSERVER 8048B-TR4FT USER'S MANUAL Demand Scrub Demand Scrubbing is a process that allows the CPU to correct correctable memory errors found on a memory module. When the CPU or I/O issues a demand-read command, and the read data from memory turns out to be a correctable error, the error is corrected and sent to the requestor (the original source).

  • Page 112: South Bridge

    Chapter 7: BIOS South Bridge This feature is used to confi gure Intel South Bridge settings. USB Confi guration The following USB items will display. • USB Module Version • USB Devices Legacy USB Support (Available when USB Functions is not Disabled) Select Enabled to support legacy USB devices.
  • Page 113 SUPERSERVER 8048B-TR4FT USER'S MANUAL  Software Feature Mask Confi guration Low Power Device Detection Support Select Enabled for the low-power device to be detected by the BIOS. The options are Enabled and Disabled. Aggressive LPM Support Select Enabled for the PCH chip to aggressively enter the Link-Power state. The options are Enabled and Disabled.
  • Page 114 Chapter 7: BIOS SATA Device Type Use this feature to confi gure the SATA device type for the device installed on selected a SATA port for use of IDE mode, RAID mode or AHCI mode. The options are Solid State Device and Hard Disk Drive. Link L0p Enable Select Enable for Link L0p support.
  • Page 115 SUPERSERVER 8048B-TR4FT USER'S MANUAL Maximum Read Request Select Auto to allow the system BIOS to automatically set the maximum Read Request size for a PCI-E device to enhance system performance. The options are Auto, 128 Bytes, 256 Bytes, 512 Bytes, 1024 Bytes, 2048 Bytes, and 4096 Bytes.

  • Page 116: Acpi Settings

    Chapter 7: BIOS Onboard LAN OpROM (Option ROM) Select Select iSCSI to use the iSCSI Option ROM to boot the computer using a iSCSI network device. Select PXE (Preboot Execution Environment) to use an PXE Option ROM to boot the computer using a PXE network device. The options are iSCSI and PXE.
  • Page 117 SUPERSERVER 8048B-TR4FT USER'S MANUAL TPM (Trusted-Platform Module) State Select Enabled to enable TPM security settings to improve data integrity and network security. The options are Disabled and Enabled. Pending Operation Use this item to schedule an operation for the security device. The options are None, Enable Take Ownership, Disable Take Ownership, and TPM Clear.
  • Page 118 Chapter 7: BIOS Super IO Confi guration Super IO Chip: This item displays the Super IO chip used in the motherboard. Serial Port 1 Confi guration Serial Port Select Enabled to enable a serial port specifi ed by the user. The options are Enabled and Disabled.

  • Page 119: Serial Port Console Redirection

    SUPERSERVER 8048B-TR4FT USER'S MANUAL Change Settings This option specifi es the base I/O port address and the Interrupt Request address of Serial Port 2 (SOL). Select Disabled to prevent the serial port from accessing any system resources. When this option is set to Disabled, the serial port becomes unavailable.

  • Page 120: Console Redirection Settings

    Chapter 7: BIOS Console Redirection Settings This feature allows the user to specify how the host computer will exchange data with the client computer, which is the remote computer used by the user. Terminal Type This feature allows the user to select the target terminal emulation type for Console Redirection.
  • Page 121 SUPERSERVER 8048B-TR4FT USER'S MANUAL VT-UTF8 Combo Key Support Select Enabled to enable VT-UTF8 Combination Key support for ANSI/VT100 terminals. The options are Enabled and Disabled. Recorder Mode Select Enabled to capture the data displayed on a terminal and send it as text messages to a remote server.
  • Page 122 Chapter 7: BIOS Out-of-Band Management Port The feature selects a serial port used by the Microsoft Windows Emergency Management Services (EMS) to communicate with a remote server. The options are COM1 Console Redirection and COM2/SOL Console Redirection. Terminal Type This feature allows the user to select the target terminal emulation type for Console Redirection.

  • Page 123: Event Logs

    SUPERSERVER 8048B-TR4FT USER'S MANUAL Event Logs Use this feature to confi gure Event Log settings.  Change SMBIOS Event Log Settings This feature allows the user to confi gure SMBIOS Event settings. Enabling/Disabling Options SMBIOS Event Log Select Enabled to enable SMBIOS (System Management BIOS) Event Logging during system boot.

  • Page 124: Ipmi

    Chapter 7: BIOS IPMI Select the IPMI (Intelligent Platform Management Interface) tab to access the following submenu items. These items indicates your system IPMI fi rmware revision number and status. • IPMI Firmware Revision • IPMI Statu  System Event Log Enabling/Disabling Options SEL Components Select Enabled to enable all system event logging support at bootup.
  • Page 125 SUPERSERVER 8048B-TR4FT USER'S MANUAL When SEL is Full This feature allows the user to determine what the AMI BIOS should do when the system event log is full. Select Erase Immediately to erase all events in the log when the system event log is full. The options are Do Nothing and Erase Immediately.

  • Page 126: Security

    Chapter 7: BIOS Security This menu allows the user to confi gure the following security settings for the system. Administrator Password Use this item to set the administrator password which is required to enter the BIOS setup utility. The length of the password should be from 3 characters to 20 characters long.

  • Page 127: Boot

    SUPERSERVER 8048B-TR4FT USER'S MANUAL Boot This submenu allows the user to confi gure the following boot settings for the system. Boot Mood Select Use this item to confi gure boot mood select settings for the machine. The options are Legacy, UEFI, and Dual.

  • Page 128: Save & Exit

    Chapter 7: BIOS  Hard Disk Drive BBS Priorities This item sets the boot sequence of available hard disk drives. • Boot Option #1  Network Drive BBS Priorities • Boot Option #1  UEFI Application Boot Priorities • Boot Option #1 Save &...
  • Page 129 SUPERSERVER 8048B-TR4FT USER'S MANUAL Save Changes and Reset When completing the system confi guration changes, select this option to save the changes and reboot the computer so that the new system confi guration settings can take effect. Save Options Save Changes Select this option and press <Enter>...

  • Page 130: Bios Error Beep Codes

    Appendix A: BIOS Error Beep Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed at each system boot, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue to boot.
  • Page 131 SUPERSERVER 8048B-TR4FT USER'S MANUAL Notes...
  • Page 132 1GB, 2GB, 4GB, 8GB, 16GB, 32GB or 64GB size ECC RDIMM/3DS LRDIMM memory. Note: refer to Section 5-5 for details on installation. Note: Check the Supermicro website for the latest memory support information. SATA Drive Bays Up to twenty-four (24) hot-swap drive bays to house 3.5" hard drives.
  • Page 133 SUPERSERVER 8048B-TR4FT USER'S MANUAL Chassis SC848XTS-R3240BP (4U rackmount) Dimensions: (WxHxD) 17.2 x 1.7 x 32.1 in. (437 x 43 x 815 mm) Weight Gross (Bare Bone): 150 lbs. (68 kg.) System Cooling The system has Four 9-cm and three 8-cm system fans and three 8-cm rear...
  • Page 134 Appendix B: System Specifi cations Regulatory Compliance Electromagnetic Emissions: FCC Class A, EN 55022 Class A, EN 61000-3-2/-3- 3, CISPR 22 Class A Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11) Safety: CSA/EN/IEC/UL 60950-1 Compliant, UL or CSA Listed (USA and Canada), CE Marking (Europe) California Best Management Practices Regulations for Perchlorate Materials:...
  • Page 135 SUPERSERVER 8048B-TR4FT USER'S MANUAL (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in signifi...

Table of Contents
