5.3.7. Digital I/O

The Digital I/O page displays the current status of the I/O ports and can be used to
turn output ports on or off.
You can apply the following settings:
Parameter
DO1 after reboot
DO2 after reboot
Besides on and off you may keep the default status as the hardware has initialized it
after power-up.
The digital inputs and outputs can also be monitored and controlled by SDK scripts.
NB3700 User Manual 3.8
Figure 5.19.: Digital I/O Ports
Digital I/O Settings
Initial status of DO1 after system has booted
Initial status of DO2 after system has booted
58
