NetModule NB3700 User Manual page 40

Parameter
IP address
Subnet mask
Alias IP address
Alias subnet mask
When running in WAN mode, the interface may be configured with the following settings:
Parameter
WAN mode
MTU
When running as DHCP client, no further configuration is required because all IP-related
settings (address, subnet, gateway, DNS server) will be retrieved from a DHCP server
in the network. You may also define static values but caution has to be taken to assign
an unique IP address as it would otherwise raise IP conflicts in the network.
PPPoE is commonly used when communicating with another WAN access device (like
a DSL modem). The following settings can be applied:
Parameter
User name
Password
Service name
Access concentrator
name
NB3700 User Manual 3.8
LAN IP Settings
The IP interface address
The subnet mask for this interface
The alias IP interface address
The alias subnet mask for this interface
WAN IP Settings
The WAN operation mode, defines whether the interface
should run as DHCP client, statically configured or over
PPPoE.
The Maximum Transmission Unit for the interface, if pro-
vided it will specify the largest size of a packet transmitted
on the interface.
PPPoE Configuration
PPPoE user name for authenticating at the access device
PPPoE password for authenticating at the access device
Specifies the service name set of the access concentrator and
can be left blank unless you have multiple services on the
same physical network and need to specify the one you want
to connect to.
The name of the concentrator (the PPPoE client will con-
nect to any access concentrator if left blank)
40
