Nb3700 Status Indicators - NetModule NB3700 User Manual

Label Color State
DO1
DO2
DI1
DI2
NB3700 User Manual 3.8
Function
on Normally open output port 1 is closed.
off Normally open output port 1 is open.
on Normally closed output port 2 is closed.
off Normally closed output port 2 is open.
on Input port 1 is set.
off Input port 1 is not set.
on Input port 2 is set.
off Input port 2 is not set.
Table 3.2.: NB3700 Status Indicators
