Administration
This page can be used to control the SDK host and apply the following settings:
Parameter
Parameter
Administrative status
Scheduling priority
Maximum flash usage
Enable watchdog
The status page informs you about the current status of the SDK. It provides an overview
about any finished jobs, you can also stop a running job there and view the script output
in the troubleshooting section where you will also find links for downloading the manuals
and examples.
Job Management
This page can be used to set up scripts, triggers and jobs. It is usually a good idea to
create a trigger first which is made up by the following parameters:
Parameter
Name
Type
Condition
Timespec
Event
You can now add your personal script to the system by applying the following parame-
ters:
NB3700 User Manual 3.8
SDK Administration Settings
Description
Specifies whether SDK scripts should run or not
Specifies the process priority of the sdkhost, higher priorities
will speed up scheduling your scripts, lower ones will have
less impact to the host system
The maximum amount of MBytes your scripts can write to
the internal flash
This option will enable watchdog supervision for each script
which leads to a reboot of the system if the script does not
respond or stopped with an exit code not equal zero.
SDK Trigger Parameters
A meaningful name to identify the trigger
The type of the trigger, either time-based or event-based
Specifies the time condition for time-based triggers (e.g.
hourly)
The time specification which, together with the condition,
specifies the time(s) when the trigger should be pulled
The system event upon which the trigger should be pulled
