Daikin ARXG35E3V1B Service Manual page 65

Instruction
To set the clock
1. Press "CLOCK button".
is displayed.
blinks.
2. Press "TIMER setting button" to
set the clock to the present time.
Holding down "
increases or decreases the time display.
3. Press "CLOCK button".
blinks.
NOTE
Tips for saving energy
• Be careful not to cool (heat) the room too much.
Keeping the temperature setting at a moderate level helps save energy.
• Cover windows with a blind or a curtain.
Blocking sunlight and air from outdoors increases the cooling (heating) effect.
• Clogged air filters cause inefficient operation and waste energy. Clean them once in about every two weeks.
Please note
• The air conditioner always consumes 15-35 watts of electricity even while it is not operating.
• If you are not going to use the air conditioner for a long period, for example in spring or autumn, turn the breaker OFF.
• Use the air conditioner in the following conditions.
Mode
COOL
HEAT
DRY
• Operation outside this humidity or temperature range may cause a safety device to disable the system.
54
" or " " button rapidly
Operating conditions
Outdoor temperature:〈2MXS40〉 10 to 46˚C
〈2MXS52〉 –10 to 46˚C
〈3/4/5MXS〉 –10 to 46˚C
〈RXG〉 10 to 46˚C
Indoor temperature: 18 to 32˚C
Indoor humidity: 80% max.
Outdoor temperature:〈2MXS40〉 –10 to 15.5˚C
〈2MXS52〉 –15 to 15.5˚C
〈3/4/5MXS〉 –15 to 15.5˚C
〈RXG〉 –15 to 20˚C
Indoor temperature: 10 to 30˚C
Outdoor temperature:〈2MXS40〉 10 to 46˚C
〈2MXS52〉 –10 to 46˚C
〈3/4/5MXS〉 –10 to 46˚C
〈RXG〉 10 to 46˚C
Indoor temperature: 18 to 32˚C
Indoor humidity: 80% max.
Recommended temperature setting
For cooling:26°C – 28°C
For heating:20°C – 24°C
If operation is continued out of this range
• A safety device may work to stop the operation.
• Condensation may occur on the indoor unit and drip.
• A safety device may work to stop the operation.
• A safety device may work to stop the operation.
• Condensation may occur on the indoor unit and drip.
SiBE04-809
2
1, 3
9
Operation Manual
