SiBE04-809
Step
7 Pull out the limit switch.
Disconnect the
8
terminals from the
board.
Cut the clamps.
9
10 Disconnect the
connector for the signal
receiver PCB (S46).
Removal Procedure
Procedure
Indoor Unit
Points
Pb free soldering is adopted
for PCB.
When replacing PCB, use
the particular solder and
iron.
Black······(1)
White······(2)
Red ········(3)
Clamps should be used all
the time.
Fix it as it was before.
155
