Daikin ARXG35E3V1B Service Manual page 179

Outdoor Unit
Step
4 Disconnect the fan
motor connector [S70].
5 The illustration shows
arrangement of the fan
motor lead wire.
Loosen the fixing hooks
6
and release the lead
wire.
Loosen the 4 screws to
7
remove the fan motor.
168
Procedure
S70
Fan motor
lead wire
Fan motor
Points
(R7199)
(R7200)
Put the lead wire through the
back of the motor when
reassembling. (so as not to
be entangled with the
propeller fan)
Lead wire
(R7201)
DC fan motor
(R7202)
Removal Procedure
SiBE04-809
Propeller fan
(R3249)
