SYMBOLS USED ON THE APPLIANCE

Main switch or key switch symbol
It is used on the instrument panel to indicate the green or red warning light showing that the main key switch is either on (I) or
off (0).
Symbol used in the solution tank to indicate the maximum temperature of the water used to fill the solution tank.
Tap position symbol.
Used on the rear of the solution canister to indicate the position of the detergent solution tap.
Water quantity regulation symbol.
Used on the rear of the solution tank to indicate the knob for adjusting the quantity of water supplied to the device's water
system.
Indicates the risk of crushed hands.
Symbol used on the serial number plate to indicated the maximum gradient.
Label with instructions for the use of standard or concentrated detergents (FSS system only).
Label with warnings on the type of detergent to use (FSS system only).
Label with Ph value of the detergent to use (FSS system only).
Label with forward speed symbol (only for BT versions).
Used on the instrument panel to indicate the position of the potentiometer that controls the device's movement speed.
Detergent percentage adjustment symbol (FSS system only).
Used on the control panel to indicate the knob for adjusting the percentage of detergent present in the machine's water circuit.
Page 7
