Specifications - Dataprobe iBoot-G2 Instructions Manual

12.1. Physical
Height
Width
Depth
Weight
MTBF
Temperature
12.2. AC
Input
Input Cord
Voltage Range
Switched Receptacle
Capacity
12.3. Compliance
UL/cUL
CE
FCC
12.4. Network
Dual 10/100 Unshielded Twisted Pair Ethernet Jacks.
IP Addressed, DHCP assigned or Static
Internal HTTP Web Server
Forms Processing Browser required
Telnet Server
User Settings
Location:
MAC Address:
IP Address:
Subnet Mask:
Gateway:
V110120E
12.

Specifications

2.0" 60mm
3.2" 82mm
4.2" 107mm
8.6 oz 244g
360,000 hours
0 – 50 degrees C
IEC 320 C14
16AWGX3C 10A 250 UL/CSA/VDE Rated (1.25mm2X3C)
Auto Sensing 105-240 VAC
IEC 320 C13
12 A Max at 105-125 VAC, 10 A Max at 210-240 VAC
UL60950 Listed I.T.E
File No. E225914
Directives 89/336/EEC, 92/31/EEC and 93/68/EEC
EN 60950: 3rd Edition
EN 55022: 1998 Class B
Part 15 Class B
Record your Setup here for reference
iBoot-G2
HTTP Port:
Auto-Ping Address:
Auto-Ping Port:
Heartbeat Port:
Page 20
