5.1.
Physical
Height
Width
Depth
Weight
MTBF
Temperature
5.2.
AC
Input
Input Cord
Voltage Range
Switched
Receptacle
Capacity
When using this product, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and injury to
persons, including the following:
.
1
Read and understand all instructions.
2.
Follow all warnings and marked on the product.
3.
Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners
or aerosol cleaners. Use a damp cloth for cleaning.
4.
Do not use this product in an outdoor environment or near water, for example, near a
bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a
swimming pool.
5.
Do not place this product on an unstable cart, stand, or table. The product may fall,
causing serious damage to the product.
6.
Slots and openings in this product and the back or bottom are provided for ventilation
to protect it from overheating; these openings must not be blocked or covered. The
openings should never be blocked by placing the product on the bed, sofa, rug, or
other similar surface. This product should never be placed near or over a radiator or
heat register. This product should not be placed in a built-in installation unless proper
ventilation is provided.
7.
This product should be operated only from the type of power source indicated on the
marking label. If you are not sure of the type of power supply to your home, consult
your dealer or local power company.
8.
This product is equipped with a three wire grounding type plug, a plug having a third
(grounding) pin. This plug will only fit into a grounding type power outlet. This is a
safety feature. If you are unable to insert the plug into the outlet, contact your
electrician to replace your obsolete outlet. Do not defeat the safety purpose of the
grounding type plug. Do not use a 3-to-2 prong adapter at the receptacle; use of this
type adapter may result in risk of electrical shock and/or damage to this product.
9.
Do not allow anything to rest on the power cord. Do not locate this product where the
cord will be abused by persons walking on it.
V181217N
5. Specifications
2.0" 60mm
3.2" 82mm
4.2" 107mm
8.6 oz 244g
400,000 Hours
0 – 50 degrees C
IEC 320 C14
16AWGX3C 10A 250
UL/CSA/VDE Rated
(1.25mm2X3C)
Auto Sensing 105-240 VAC
IEC 320 C13
12 A Max at 105-125 VAC,
10 A Max at 210-240 VAC
6. Important Safety Instructions
Save These Instructions
iBoot-IO
5.3.
Input and Output Connections
Four position removable screw terminals.
18AWG maximum.
Maximum distance 330feet/100m using 24AWG wire.
Relay Coil Sensitivity: 44ma @ 12 VDC
5.4.
Compliance
UL60950 Listed I.T.E File No. 188
UL/cUL
Directives 89/336/EEC, 92/31/EEC and
93/68/EEC
CE
EN 60950: 3rd Edition
EN 55022: 1998 Class B
FCC
Part 15 Class B
10. Do not overload wall outlets and extension cords as this can result in the risk of fire or
electric shock.
11. Never push objects of any kind into this product through slots as they may touch
dangerous voltage points or short out parts that could result in a risk of fire or
electrical shock. Never spill liquid of any kind on the product.
12. To reduce the risk of electrical shock, do not disassemble this product, but take it to a
qualified serviceman when some service or repair work is required. Opening or
removing covers may expose you to dangerous voltages or other risks. Incorrect re-
assembly can cause electric shock when the appliance is subsequently used.
13. Unplug this product from the wall outlet and refer servicing to qualified service
personnel under the following conditions:
a)
When the power supply cord or plug is damaged or frayed.
b)
If liquid has been spilled into the product.
c)
If the product has been exposed to rain or water.
d)
If the product does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions
because improper adjustment of other controls may result in damage and will
often require extensive work by a qualified technician to restore the product to
normal operation.
e)
If the product has been dropped or has been damaged.
f)
If the product exhibits a distinct change in performance.
14. Avoid using a telephone (other than a cordless type) during an electrical storm.
There may be a remote risk of electric shock from lightning.
15. Do not use the telephone to report a gas leak in the vicinity of the leak.
16. Do not exceed the maximum output rating of the auxiliary power receptacle.
Page 6
