Specifications - Dataprobe iBoot-DC Manual

12.1. Physical
Height
Width
Depth
Weight
MTBF
Temperature
12.1. DC
Input
Voltage Range
Switched Receptacle
Current Capacity
12.2. Compliance
FCC
12.3. Network
Dual 10/100 Unshielded Twisted Pair Ethernet Jacks.
IP Addressed, DHCP assigned or Static
Internal HTTP Web Server
Forms Processing Browser required
Telnet Server
User Settings
Location:
MAC Address:
IP Address:
Subnet Mask:
Gateway:
iboot-dc_v181024e
12.

Specifications

2.0" 60mm
3.2" 82mm
4.2" 107mm
8.6 oz 244g
360,000 hours
0 – 50 degrees C
Screw Terminals
Auto Sensing 5-48VDC
Screw Terminals
5.0 – 29.9 VDC
30.0 – 48VDC 2 Amps Max
Part 15 Class B
Record your Setup here for reference
iBoot-DC
12 Amps Max
HTTP Port:
Auto-Ping Address:
Auto-Ping Port:
Heartbeat Port:
Page 27
