MINI SPARROWHAWK EP Instruction Manual.
Epoxy.
Epoxy.
Rudder control horn.

INSTALLING THE FUSELAGE SERVOS.

Because the size of servos differ, you
may need to adjust the size of the precut open-
ing in the mount. The notch in the sides of the
mount allow the servo lead to pass through.
1) Install the rubber grommets and brass
collets onto the throttle servo. Test fit the servo
Elevator control horn.
into the aileron servo mount.
2) Secure the servos with the screws pro-
vided with your radio system.
INSTALL RUDDER CONTROL HORN.
Cut.
Elevator servo.
6
