Seagull Models Mini Sparrowhawk EP Assembly Manual page 9

3) Attach the motor to the front of the electric
motor box using four 3mm blind nut, four
M3x15mm hex head bolts to secure the motor.
Please see picture shown.
4mm.
M3 x 15mm.
110mm.
Epoxy.
Balsa.
www.seagullmodels.com
Electric motor.
Epoxy.
4) Locate the plywood battery tray to the
fuselage.
1800mAh-2100mAh.
5) Attach the speed control to the side of the
motor box using two-sided tape and tie wraps.
Connect the appropriate leads from the speed
control to the motor. Make sure the leads will
not interfere with the operation of the motor.
Speed control.
15A-30A.
COWLING.
1) Slide the fiberglass cowl over the mo-
tor and line up the back edge of the cowl with
the marks you made on the fuselage then trim
and cut as shown.
Battery.
Battery.
9
