AutoView 200 Installer/User Guide
Connecting your Remote Peripherals
4. Plug a standard Category 5 Unshielded Twisted Pair cable (up to 500
5. Route the Category 5 cable to the location where you intend to
6. Place the LongView Receiver near the monitor and connect your
7. Connect the Category 5 cable to the modular jack on the rear of
8. There are two power ports for the LongView Receiver. One on the
feet) into the RJ-45 style modular jack on the rear of the AutoView 200.
Cybex C5T or Cybex P5T cable is strongly recommended to achieve
best performance and maximum distance. If you use a different
Category 5 cable, make sure it is terminated to the EIA (TIA) 568 B
standard, commonly used for 10BaseT Ethernet.
place the secondary monitor, keyboard and mouse.
monitor, keyboard and mouse to the connectors on the rear of the
Receiver just as you would connect them to your PC. Make sure you
connect your monitor's power supply to appropriate electrical outlets.
(Please note that the
not used in an AutoView 200 configuration. Do not connect any-
thing to the connector on the rear of the Receiver.)
the Receiver.
back of the AutoView 200 and one on the Receiver. Connect the
circular power plug from the wall mount power supply to either
power port, whichever is most convenient for you. Then plug the
power supply into a convenient electrical outlet. Verify that the
Receiver's POWER light is now lit.
connector on the rear of the Receiver is
6
