STEVAL-IHT008V1 silk-screen

11 STEVAL-IHT008V1 silk-screen
C16, C17, C18, C19, C20, C21, C24, C26, C27
32/37
Figure 23: STEVAL-IHT008V1 silk-screen (Top side)
Table 5: Bill of material
Reference
C1, C9
C2, C4, C5, C8
C6, C7
C10
C11, C14
C13, C15, C38
C22
C23
C25
C28
C29
C30
C31, C37
C32
DocID029048 Rev 1
Part / Value
1000 µF / 250 V
2.2 nF / 440 VAC
56 nF / 300 V
1 nF / 50 V
1 µF / 25 V
1 nF / 50 V
10 nF / 50 V
100 nF / 50 V
10 µF / 16 V
680 nF / 25 V
220 µF / 16 V
1.5 mF / 16 V
220 µF / 63 V
100 µF / 16 V
10 µF / 450 V
UM2027
