Network Speed Dome
User Manual
UD.6L0201D1827A01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-2DF5220S-DE4/Ww and is the answer not in the manual?

Questions and answers

Related Manuals for HIKVISION DS-2DF5220S-DE4/Ww

Summary of Contents for HIKVISION DS-2DF5220S-DE4/Ww

  • Page 1 Network Speed Dome User Manual UD.6L0201D1827A01...
  • Page 2 SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.
  • Page 3 User Manual of Network Speed Dome IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS. © Hikvision...
  • Page 4 (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For more information see: www.recyclethis.info. Industry Canada ICES-003 Compliance This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements. © Hikvision...
  • Page 5 Never attempt to disassemble the product yourself. (We shall not assume any responsibility for problems caused by unauthorized repair or maintenance.)  Please do not look directly into the laser light within 6 meters because laser is hazardous to humans. © Hikvision...
  • Page 6 Please use a soft and dry cloth when clean inside and outside surfaces of the product cover. Do not use alkaline detergents.  Improper use or replacement of the battery may result in hazard of explosion. Please use the manufacturer recommended battery type. © Hikvision...

  • Page 7: Table Of Contents

    Configuring Smart Tracking ....................45 Configuring PTZ Control Priority .................... 46 Clearing PTZ Configurations ....................47 Chapter 6 Speed Dome Configuration ..................48 Configuring Local Parameters ....................48 Configuring Time Settings ...................... 49 Configuring Network Settings ....................52 © Hikvision...
  • Page 8 Record Settings ......................99 Configuring NAS Settings ....................... 99 Initializing and Configuring Storage ..................100 Configuring Recording Schedule ..................101 Configuring Snapshot Settings ..................... 105 Chapter 8 Playback ......................... 107 Chapter 9 Log Searching ......................111 Chapter 10 Others ........................112 © Hikvision...
  • Page 9 Appendix 6 RS485 Bus Connection ....................131 Appendix 7 24VAC Wire Gauge & Transmission Distance ..............134 Appendix 8 12VDC Wire Gauge & Transmission Distance ..............135 Appendix 9 Table of Wire Gauge Standards ..................136 Appendix 10 Alarm In/Out Connections ..................137 © Hikvision...

  • Page 10: Chapter 1 Overview

    In manual tracking mode, when a target object goes directly beneath the dome, the video will automatically flips 180 degrees in horizontal direction to maintain continuity of tracking. This function can also be realized by auto mirror image © Hikvision...
  • Page 11 This feature varies depending on speed dome models.  White Balance (WB) White balance can remove the unrealistic color casts. White balance is the white rendition function of the camera to adjust the color temperature according to the © Hikvision...
  • Page 12 The noise will be much less and the video will be clearer.  Dual-VCA Combine the detected VCA information into the video stream, which can be used for the second-time analysis on the back-end device. © Hikvision...

  • Page 13: Chapter 2 Network Connection

     To test the network speed dome, you can directly connect the network speed dome to the computer with a network cable as shown in Figure 2-1.  Refer to the Figure 2-2 to set the network speed dome over the LAN via a switch or a router. © Hikvision...

  • Page 14: Activating The Speed Dome

    1. Power on the speed dome, and connect the speed dome to the network. 2. Input the IP address into the address bar of the web browser, and click Enter to enter the activation interface. The default IP address of the speed dome is 192.168.1.64. © Hikvision...
  • Page 15 SADP according to the prompts. Follow the steps to activate the speed dome. Steps: 1. Run the SADP software to search the online devices. 2. Check the device status from the device list, and select an inactive device. © Hikvision...
  • Page 16 5. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP. © Hikvision...
  • Page 17 Get the client software from the supplied disk or the official website, and install the software according to the prompts. Follow the steps to activate the camera. Steps: 1. Run the client software and the control panel of the software pops up, as shown in the figure below. © Hikvision...
  • Page 18 3. Check the device status from the device list, and select an inactive device. 4. Click the Activate button to pop up the Activation interface. 5. Create a password and input the password in the password field, and confirm the password. © Hikvision...
  • Page 19 Figure 2-9 Modifying the Network Parameters 9. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP. 10. Input the password to activate your IP address modification. © Hikvision...

  • Page 20: Setting The Network Speed Dome Over The Wan

    Connecting the network speed dome with static IP directly  You can also save the static IP in the speed dome and directly connect it to the internet without using a router. Refer to Section 2.1.2 for detailed IP address configuration of the speed dome. © Hikvision...

  • Page 21: Dynamic Ip Connection

    Refer to Appendix 2 for detailed information about port mapping. 5. Apply a domain name from a domain name provider. 6. Configure the DDNS settings in the setting interface of the router. 7. Visit the speed dome via the applied domain name. © Hikvision...
  • Page 22 2. Configure the DDNS settings in the DDNS Settings interface of the network speed dome. Refer to Section 6.3.4 Configuring DDNS Settings for detailed configuration. 3. Visit the speed dome via the applied domain name.  Private Domain Name Resolution © Hikvision...
  • Page 23 2. Access the network speed dome through the LAN with a web browser or the client software. 3. Enable DDNS and select IP Server as the protocol type. Refer to Section 6.3.4 Configuring DDNS Settings for detailed configuration. © Hikvision...

  • Page 24: Chapter 3 Access To The Network Speed Dome

    The device IP address gets locked if the admin user performs 7 failed password attempts (5 attempts for the user/operator). Figure 3-1 Login Interface 6. Install the plug-in before viewing the live video and operating the speed dome. Please follow the installation prompts to install the plug-in. © Hikvision...
  • Page 25 User Manual of Network Speed Dome Figure 3-2 Download and Install Plug-in Figure 3-3 Install Plug-in (1) Figure 3-4 Install Plug-in (2) © Hikvision...

  • Page 26: Accessing By Client Software

    The product CD contains the client software. You can view the live video and manage the speed dome with the client software. Follow the installation prompts to install the client software and WinPcap. The configuration interface and live view interface of client software are shown below. Figure 3-6 iVMS-4200 Control Panel © Hikvision...
  • Page 27  If you use third party VMS software, please contact technical support of our branch for camera firmware.  For detailed information about client software of our company, please refer to the user manual of the software. This manual mainly introduces accessing to the network speed dome by web browser. © Hikvision...

  • Page 28: Chapter 4 Live View

    The live video page allows you to view live video, capture images, realize PTZ control, set/call presets and configure video parameters. Log in the network speed dome to enter the live view page, or you can click on the menu bar of the main page to enter the live view page. © Hikvision...

  • Page 29: Starting Live View

    Configure the image size and stream type of the live video. 4.3 Starting Live View In the live view window as shown in Figure 4-3, click on the toolbar to start the live view of the speed dome. © Hikvision...
  • Page 30 You can double-click on the live video to switch the current live view into full-screen or return to normal mode from the full-screen. Regional Focus: Steps: 1. Click the on the toolbar to enter the regional focus operation mode. © Hikvision...
  • Page 31 2. Click a moving object in the live video. The speed dome will track the object automatically. Please refer to the following sections for more information:  Configuring remote recording in Section 7.3 Configuring Recording Schedule. © Hikvision...

  • Page 32: Recording And Capturing Pictures Manually

    PTZ control panel or click hide it. Click the direction buttons to control the pan/tilt movements. Click the zoom/iris/focus buttons to realize lens control. Figure 4-4 PTZ Control Panel Table 4-2 Descriptions of PTZ Control Panel Button Description © Hikvision...

  • Page 33: Setting / Calling A Preset

    4. You can click to delete the preset. You can configure up to 300 presets.  Calling a Preset: In the PTZ control panel, select a defined preset from the list and click to call the preset. © Hikvision...
  • Page 34 Start tilt scan Call pattern 1 Start panorama scan Call pattern 2 Call patrol 5 Call pattern 3 Call patrol 6 Call pattern 4 Call patrol 7 Automatically Create Patrol Call patrol 8 Start to set limit stops © Hikvision...

  • Page 35: Setting / Calling A Patrol

    Steps: 1. In the PTZ control panel, click to enter the patrol settings interface. 2. Select a patrol number from 3. Click to enter the adding interface of preset, as shown in Figure 4-8. Figure 4-8 Adding Presets © Hikvision...
  • Page 36 Figure 4-9 Calling a Patrol  Buttons on the Patrols interface: Buttons Description Save a patrol Call a patrol Stop a patrol Enter the adding interface of preset Modify a preset Delete a preset Delete all the presets in the selected patrol © Hikvision...

  • Page 37: Setting / Calling A Pattern

     Buttons on the Patterns interface: Buttons Description Start to record a pattern. Stop recording a pattern. Call the current pattern. Stop the current pattern. Delete the current pattern. These 4 patterns can be operated separately and with no priority level.  © Hikvision...

  • Page 38: Configuring Live View Parameters

    Please refer to Section 6.4.1 Configuring Video Settings for more detailed parameter settings of the main stream and sub-stream respectively.  Image Size: You can scale up/down the live view image by clicking . The image size can be 4:3, 16:9, original or auto. © Hikvision...

  • Page 39: Chapter 5 Ptz Configuration

    3. Click Set to save the position. Call/delete an Initial Position:  You can click to call the initial position. You can click to delete the initial position and restore the factory default initial position. 5.2 Configuring Basic PTZ Parameters Purpose: © Hikvision...
  • Page 40 The scan speed can be set from level 1 to 40.  Zooming Speed: The zoom speed is adjustable from level 1 to 3.  Manual Control Speed: The manual control speed can be set as Compatible, Pedestrian, Non-motor Vehicle, Motor Vehicle or Self-adaptive. © Hikvision...

  • Page 41: Configuring Ptz Limits

    5.3 Configuring PTZ Limits Purpose: The dome can be programmed to move within the configurable PTZ limits (left/right, up/down). Steps: 1. Enter the Limit Configuration interface: Configuration > Advanced Configuration > PTZ > Limit © Hikvision...

  • Page 42: Configuring Scheduled Tasks

    4. Click Set to save the limits or click Clear to clear the limits. 5.4 Configuring Scheduled Tasks Purpose: You can configure the network dome to perform a certain action automatically in a user-defined time period. Steps: 1. Enter the Scheduled Task Settings interface: © Hikvision...
  • Page 43 (2) Choose the day you want to set the task schedule. (3) Click All Day to set the schedule as all day; or click Customize and input the Start Time and End Time for each task, and click Enter on your keyboard to © Hikvision...

  • Page 44: Configuring Park Actions

    Scheduled Tasks function is prior to Park Action function. When these two functions are set at the same time, only the Scheduled Tasks function takes effect. Steps: 1. Enter the Park Action Settings interface: Configuration > Advanced Configuration> PTZ > Park Action Figure 5-7 Set the Park Action © Hikvision...

  • Page 45: Configuring Privacy Mask

    Figure 5-9 Draw the Privacy Mask 2. Click the PTZ control buttons to find the area you want to set the privacy mask. 3. Click ; click and drag the mouse in the live video window to draw the © Hikvision...

  • Page 46: Configuring Smart Tracking

    You are allowed to draw up to 24 areas on the same image. 5.7 Configuring Smart Tracking Purpose: The speed dome tracks the moving objects automatically after you configure this function. Steps: 1. Enter the Smart Tracking Settings interface: Configuration > Advanced Configuration> PTZ > Smart Tracking © Hikvision...

  • Page 47: Configuring Ptz Control Priority

     The operation of Operator is prior to that of User. When the Operator is controlling the speed dome, the User cannot control it. When the Operator finishes, the User can control the speed dome after the Delay time. The Delay time can be set in Priority PTZ interface as shown follows. © Hikvision...

  • Page 48: Clearing Ptz Configurations

    PTZ limits, scheduled tasks and park actions. Steps: 1. Enter the Clearing Configuration interface: Configuration > Advanced Configuration> PTZ > Clear Config 2. Check the checkbox of the items you want to clear. 3. Click to clear the settings. © Hikvision...

  • Page 49: Chapter 6 Speed Dome Configuration

    HTTP: Allows the same quality as of TCP without setting specific ports for streaming under some network environments. MULTICAST: It’s recommended to select the protocol type to when using the Multicast function. For other information about Multicast, refer to Section 6.3.1 Configuring TCP/IP Settings. © Hikvision...

  • Page 50: Configuring Time Settings

    Time (DST) functions for setting the time. Time Synchronization consists of auto mode by Network Time Protocol (NTP) server and manual mode. To enter the Time Settings interface: Configuration > Basic Configuration > System > Time Settings Or Configuration > Advanced Configuration > System > Time Settings © Hikvision...
  • Page 51 National Time Center (IP Address: 210.72.145.44). If the speed dome is set in a customized network, NTP software can be used to establish a NTP server for time synchronization. © Hikvision...
  • Page 52 The time will be adjusted automatically when the Daylight Saving Time(DST) comes. Steps: (1) Enter the DST interface by Configuration > Advanced Configuration > System > DST (2) Check to enable the DST function. © Hikvision...

  • Page 53: Configuring Network Settings

    TCP/IP settings must be properly configured before you operate the speed dome over network. IPv4 and IPv6 are both supported. Steps: 1. Enter TCP/IP Settings interface: Configuration > Basic Configuration > Network > TCP/IP Or Configuration > Advanced Configuration > Network > TCP/IP © Hikvision...
  • Page 54  If the DNS server settings are required for some applications (e.g., sending email), you should properly configure the Preferred DNS Server and Alternate DNS server.  Check the checkbox of Enable Multicast Discovery, and then the speed dome can be detected by client software in the LAN. © Hikvision...

  • Page 55: Configuring Port Settings

    HTTPS Port: The default port number is 443. Server Port: The default port number is 8000. 3. Click to save the settings. 6.3.3 Configuring PPPoE Settings Purpose: If you have no router but only a modem, you can use Point-to-Point Protocol over Ethernet (PPPoE) function. © Hikvision...

  • Page 56: Configuring Ddns Settings

     For your privacy and to better protect your system against security risks, we strongly recommend the use of strong passwords for all functions and network devices. The password should be something of your own choosing (using a © Hikvision...
  • Page 57 (4) Enter the User Name and Password registered on the DynDNS website. (5) Click to save the settings. Figure 6-12 DynDNS Settings IP Server:  Steps: (1) Enter the Server Address of the IP Server. (2) Click to save the settings. © Hikvision...

  • Page 58: Configuring Snmp Settings

    You can use SNMP to get speed dome status and parameters related information. Before you start: Before setting the SNMP, please use the SNMP software and manage to receive the speed dome information via SNMP port. By setting the Trap Address, the speed dome © Hikvision...
  • Page 59 2. Check the corresponding version checkbox (Enable SNMP v1, Enable SNMP v2c, Enable SNMP v3) to enable the feature. 3. Configure the SNMP settings. The configuration of the SNMP software should be the same as the settings you configure here. 4. Click to save and finish the settings. © Hikvision...

  • Page 60: Configuring 802.1X Settings

     For your privacy and to better protect your system against security risks, we strongly recommend the use of strong passwords for all functions and network devices. The password should be something of your own choosing (using a © Hikvision...

  • Page 61: Configuring Qos Settings

    Steps: 1. Enter the QoS Settings interface: Configuration >Advanced Configuration > Network > QoS Figure 6-18 QoS Settings 2. Configure the QoS settings, including video / audio DSCP, event / alarm DSCP and © Hikvision...

  • Page 62: Configuring Ftp Settings

     For your privacy and to better protect your system against security risks, we strongly recommend the use of strong passwords for all functions and network devices. The password should be something of your own choosing (using a © Hikvision...

  • Page 63: Configuring Upnp™ Settings

    Universal Plug and Play (UPnP™) is a networking architecture that provides compatibility among networking equipment, software and other hardware devices. The UPnP protocol allows devices to connect seamlessly and to simplify the implementation of networks in the house and corporate environments. © Hikvision...

  • Page 64: Configuring Nat (Network Address Translation) Settings

    To port mapping with the customized port numbers: Choose And you can customize the value of the port No. by yourself. Figure 6-23 Configure the Port No. 2. Click to save the settings. 6.3.11 Configuring Email Settings Purpose: © Hikvision...
  • Page 65 Interval: The interval refers to the time between two actions of sending attached pictures. Authentication (optional): If your email server requires authentication, check this checkbox to use authentication to log in to this server and enter the login © Hikvision...

  • Page 66: Configuring Https Settings

    If you set the port number as 443 and the IP address is 192.168.1.64, you may access the device by inputting https://192.168.1.64:443 via the web browser. Steps: 1. Enter the HTTPS settings interface. Configuration > Advanced Configuration > Network > HTTPS 2. Create the self-signed certificate or authorized certificate. © Hikvision...
  • Page 67 2) Download the certificate request and submit it to the trusted certificate authority for signature. 3) After receiving the signed valid certificate, import the certificate to the device. 3. There will be the certificate information after you successfully create and install the certificate. © Hikvision...
  • Page 68 User Manual of Network Speed Dome Figure 6-27 Installed Certificate Property You can click configure the HTTPS port No. on your demand; refer to Section 6.3.2 Configuring Port Settings for details. 4. Check the checkbox of Enable HTTPS and click the Save button. © Hikvision...

  • Page 69: Configuring Video And Audio Settings

    Video Type is Video&Audio. Resolution: Select the resolution of the video output. Bitrate Type: Select the bitrate type to constant or variable. Video Quality: When bitrate type is selected as Variable, 6 levels of video quality are selectable. Frame Rate: © Hikvision...

  • Page 70: Configuring Audio Settings

    Configuration > Basic Configuration > Video / Audio > Audio Or Configuration > Advanced Configuration > Video / Audio > Audio Figure 6-29 Audio Settings 2. Configure the following settings. Audio Encoding: G.722.1, G.711ulaw, G.711alaw, MP2L2, PCM and G.726 selectable. © Hikvision...

  • Page 71: Configuring Roi Settings

    6.4.3 Configuring ROI Settings Before you start: ROI (Region of Interest) encoding is used to enhance the quality of images which are specified in advance. Enter the ROI Settings interface: Configuration > Advanced Configuration > Video / Audio > ROI © Hikvision...
  • Page 72 6. Enter a Region Name and click Save to save the settings. Dynamic Region: The device can automatically calculate the region with motion.  Set the Image Quality Enhancing level for ROI encoding. Steps: © Hikvision...

  • Page 73: Configuring Image Settings

    Configuration > Basic Configuration> Image> Display Settings Or Configuration > Advanced Configuration> Image> Display Settings 2. You can select the Mounting Scenario in the dropdown list with different predefined image parameters. 3. Set the image parameters of the speed dome. © Hikvision...

  • Page 74: Image Adjustment

    The value ranges from 0 to 100. This function varies depending on the models of speed dome. Exposure Settings  Exposure Mode The Exposure Mode can be set to Auto, Iris Priority, Shutter Priority, Manual.  Auto: © Hikvision...
  • Page 75 The slow shutter value can be set to Slow Shutter*2, *4, *6, *12, *16, *24 and *32. Figure 6-35 Slow Shutter Focus Settings  Focus Mode The Focus Mode can be set to Auto, Manual, Semi-auto. © Hikvision...
  • Page 76 In Schedule mode, you can set the time schedule for day mode as shown in Figure 6-37. The rest time out of the schedule is for night mode. This function varies depending on the models of speed dome. © Hikvision...
  • Page 77 WDR balances the brightness level of the whole image and provide clear images with details. You can enable or disable the WDR function as shown in Figure 6-38. The wide dynamic level ranges from 0 to 100. © Hikvision...

  • Page 78: White Balance

    You can select this mode when there are sodium lamps installed near the speed dome.  Auto-Track In Auto-Track mode, white balance is continuously being adjusted in real-time according to the color temperature of the scene illumination. This function varies depending on the models of speed dome. © Hikvision...

  • Page 79: Image Enhancement

    You can set the Video Standard to 50hz(PAL) or 60hz(NTSC) according to the video system in your country. This function varies depending on the models of speed dome. Capture Mode: You can set the Capture Mode to OFF, 1280*720@25fps, and 1280*960@25fps. © Hikvision...

  • Page 80: Configuring Osd Settings

    Preset Title: Identifies preset being called. Camera Name: Identifies the name of speed dome. You can customize the on screen display of time. Steps: 1. Enter the OSD Settings interface: Configuration > Advanced Configuration > Image > OSD Settings Figure 6-41 OSD Settings © Hikvision...

  • Page 81: Configuring Text Overlay Settings

    2. Check the checkbox in front of textbox to enable the on-screen display. 3. Input the characters in the textbox. 4. Use the mouse to click and drag the red text frame in the live view window to adjust the text overlay position. © Hikvision...

  • Page 82: Configuring And Handling Alarms

    Configuration > Advanced Configuration> Basic Event > Motion Detection 2. Check the checkbox of the Enable Motion Detection to enable this function. You can check the Enable Dynamic Analysis for Motion checkbox if you want the detected object get marked with rectangle in the live view. © Hikvision...
  • Page 83 • You can draw up to 8 motion detection areas on the same image. • You can click to clear all of the areas. (3) Move the slider to set the sensitivity of the detection.  Expert © Hikvision...
  • Page 84 Proportion of Object on Area: When the size proportion of the moving object exceeds the predefined value, the alarm will be triggered. The less the value is, the easier the alarm will be triggered. 4. Set the Arming Schedule for Motion Detection. (1) Click in Figure 6-46. © Hikvision...
  • Page 85 The time of each period cannot be overlapped. Up to 8 periods can be configured for each day. 5. Set the Alarm Actions for Motion Detection. You can specify the linkage method when an event occurs. The following contents are about how to configure the different types of linkage method. © Hikvision...
  • Page 86  Trigger Alarm Output Trigger one or more external alarm outputs when an event occurs. To trigger an alarm output when an event occurs, please refer to Section 6.6.5 Configuring Alarm Output to set the alarm output parameters. © Hikvision...

  • Page 87: Configuring Video Loss Alarm

    Please Step 3 in Section 6.6.1 Configuring Motion Detection. 5. Click to save the settings. 6.6.3 Configuring Video Tampering Alarm Purpose: You can configure the speed dome to trigger the alarm actions when the lens is © Hikvision...

  • Page 88: Configuring External Alarm Input

    Steps: 1. Enter the Alarm Input Settings interface: Configuration > Advanced Configuration> Events > Alarm Input 2. Choose the alarm input No. and the Alarm Type. The alarm type can be NO (Normally Open) and NC (Normally Closed). © Hikvision...
  • Page 89 6. You can also choose the PTZ linking for the alarm input. Check the relative checkbox and select the No. to enable Preset Calling, Patrol Calling or Pattern Calling. 7. You can copy your settings to other alarm inputs. 8. Click to save the settings. © Hikvision...

  • Page 90: Configuring Alarm Output

    5. Click to enter the Edit Schedule Time interface. The time schedule configuration is the same as the settings of the arming schedule for motion detection. Refer to Step 2 in Section 6.6.1 Configuring Motion Detection. © Hikvision...

  • Page 91: Handling Exception

    Configuration > Advanced Configuration> Events > Exception 2. Check the checkbox to set the actions taken for the Exception alarm. Refer to Step 3 in Section 6.6.1 Configuring Motion Detection. Figure 6-54 Exception Settings 3. Click to save the settings. © Hikvision...

  • Page 92: Detecting Audio Exception

    The arming schedule configuration is the same as the setting of the arming schedule for motion detection. Refer to Step 2 in Section 6.6.1 Configuring Motion Detection. 6. Check the checkbox to select the linkage method taken for audio exception. © Hikvision...

  • Page 93: Configuring Dual-Vca

    Intrusion detection can set an area in the surveillance scene and once the area is entered, a set of alarm action is triggered. Steps: 1. Enter the intrusion detection interface: Configuration > Advanced Configuration > Events > Intrusion Detection 2. Check the Enable Intrusion Detection checkbox. © Hikvision...
  • Page 94  Detection Target: You can select human, vehicle, or all (human &vehicle) as the detection target from the dropdown list. If Human is selected, only © Hikvision...

  • Page 95: Configuring Line Crossing Detection

    4. The event triggered and park action related PTZ movement will be locked for 180 seconds after you enter the line crossing detection interface. Optionally, you can click the button to manually activate the movement, or lock the movement when the button turns to by clicking it. © Hikvision...
  • Page 96 Refer to Step 2 in Section 6.6.1 Configuring Motion Detection. 8. Check the checkbox to select the linkage method, including Notify surveillance © Hikvision...

  • Page 97: Configuring Face Detection

    5. Check the checkbox to select the linkage method taken for the face detection. Notify surveillance center, send email, upload to FTP, trigger channel, smart tracking and trigger alarm output are selectable. Please refer to Step 3 in Section 6.6.1 Configuring Motion Detection. 6. Click to save the settings. © Hikvision...

  • Page 98: Region Entrance Detection

    (human &vehicle) as the detection target from the dropdown list. If Human is selected, only human beings will be identified as detection objects and as well as Vehicle. 7. Click the button to set the arming schedule. Refer to Step 2 in Section 6.6.1 Configuring Motion Detection. © Hikvision...

  • Page 99: Region Exiting Detection

    5. Click on the live video to specify the four vertexes of the detection region, and right click to complete drawing. Repeat the step to configure other regions. Up to 4 regions can be set. You can click the button to clear all pre-defined regions. © Hikvision...

  • Page 100: Chapter 7 Record Settings

    8 characters, including upper case letters, lower case letters, numbers and special characters) in order to increase the security of your product.  Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. © Hikvision...

  • Page 101: Initializing And Configuring Storage

    (2) If the status of the disk is Uninitialized as shown in Figure 7-3, check the corresponding checkbox to select the disk and click to start initializing the disk. Figure 7-3 Initialize Disk Figure 7-4 Initializing © Hikvision...

  • Page 102: Configuring Recording Schedule

    By default, the record files of scheduled recording are stored in the SD card (if supported) or in the network disk. Steps: 1. Enter the Record Schedule Settings interface: Configuration > Advanced Configuration> Storage > Record Schedule © Hikvision...
  • Page 103 For example, if an alarm triggered recording ends at 11:00, and the post-record time is set as 5 seconds, the speed dome records until 11:00:05. The Post-record time can be configured as 5 s, 10 s, 30 s, 1 min, 2 min, 5 min or 10 min. © Hikvision...
  • Page 104 Alarm, Motion | Alarm, Motion & Alarm, Face Detection, Intrusion Detection, Line Crossing Detection, Audio Exception Detection and All events.  Continuous If you select Continuous, the video will be recorded automatically according to the time of the schedule.  Record Triggered by Motion Detection © Hikvision...
  • Page 105 (3) Check the checkbox and click to copy settings of this day to the whole week. You can also check any of the checkboxes before the date and click (4) Click to save the settings and exit the Edit Record Schedule © Hikvision...

  • Page 106: Configuring Snapshot Settings

    Figure 7-10 Snapshot Settings 2. Check the Enable Timing Snapshot checkbox to enable continuous snapshot, and configure the schedule of timing snapshot. Check the Enable Event-triggered Snapshot checkbox to enable event-triggered snapshot. 3. Select the quality of the snapshot. © Hikvision...
  • Page 107 Settings interface. Please refer to Section 6.3.8 Configuring FTP Settings for more details to configure FTP parameters. 3) Check checkbox in Motion Detection Settings or Alarm Input interface. Please refer to Step 3 in Section 6.6.1 Configuring Motion Detection. © Hikvision...

  • Page 108: Chapter 8 Playback

    Task 1: To play back the video files Steps: 1. Click on the menu bar to enter playback interface. Figure 8-1 Playback Interface 2. Select the date and click Figure 8-2 Search Video 3. Click to play the video files found on this date. © Hikvision...
  • Page 109 You can also click to zoom out/in the progress bar. Figure 8-4 Set Playback Time Figure 8-5 Progress Bar The different colors of the video on the progress bar stand for the different video types as shown in Figure 8-6. © Hikvision...
  • Page 110 3. Set the start time and end time. Click Search. The corresponding picture files are listed on the left. 4. Check the checkbox in front of the files that you need to download. 5. Click to download the files. © Hikvision...
  • Page 111 User Manual of Network Speed Dome Figure 8-8 Picture Downloading interface © Hikvision...

  • Page 112: Chapter 9 Log Searching

    Minor Type, Start Time and End Time as shown in Figure 9-2. 3. Click to search log files. The matched log files will be displayed on the Log interface. Figure 9-2 Log Searching 4. To export the log files, click to save the log files in your computer. © Hikvision...

  • Page 113: Chapter 10 Others

    The level indicates the permissions you give to the user. You can define the user as Operator or User. 3. In the Basic Permission field and Camera Configuration field, you can check or uncheck the permissions for the new user. 4. Click to finish the user addition. © Hikvision...
  • Page 114 1. Click to select the user from the list and click 2. Modify the User Name, Level or Password. 3. In the Basic Permission field and Camera Configuration field, you can check or uncheck the permissions. 4. Click to finish the user modification. Figure 10-3 Modify a User © Hikvision...

  • Page 115: Configuring Authentication

    Steps: 1. Enter the Anonymous Visit interface: Configuration> Advanced Configuration> Security > Anonymous Visit Figure 10-4 Anonymous Visit 2. Set the Anonymous Visit permission Enable or Disable in the drop-down list to enable or disable the anonymous visit. © Hikvision...

  • Page 116: Configuring Ip Address Filter

    Filter Type Description Forbid the IP addresses added in the IP Address Forbidden Filter interface to log in. Allow only the IP addresses added in the IP Allowed Address Filter interface to log in. Figure 10-6 IP Address Filter © Hikvision...

  • Page 117: Configuring Security Service Settings

    Alarm Input and Number of Alarm Output are displayed. The information cannot be changed in this menu. It is the reference for maintenance or modification in future. Figure 10-7 Device Information 10.7 Maintenance 10.7.1 Rebooting the Speed Dome © Hikvision...

  • Page 118: Restoring Default Settings

    Configuration > Basic Configuration> System > Maintenance Or Configuration > Advanced Configuration> System > Maintenance 2. Click to select the local configuration file and then click start importing configuration file. You need to reboot the speed dome after importing configuration file. © Hikvision...

  • Page 119: Upgrading The System

    The upgrading process will take 1 to 10 minutes. Please do not disconnect the power of the speed dome during the upgrading process. The speed dome reboots automatically after upgrading. Figure 10-10 Remote Upgrade © Hikvision...

  • Page 120: Configuring Rs-485

    Configuration> Advanced Configuration> System > Service 2. Check the checkbox to enable the supplement light function, and then the light will be turned on automatically when the illumination is not enough for the video monitoring. 3. Click the button to activate the settings. © Hikvision...

  • Page 121: Configuring Remote Connection

    2. Input a number in text field as the upper limit of the remote connection number. E.g. when you specify the remote connection number as 10, then the 11th remote connection cannot be established. Figure 10-12 Live View Connection Settings 3. Click the button to activate the settings. © Hikvision...

  • Page 122: Appendix

    Device can be searched and displayed in the list in 15 seconds after it went online; it will be removed from the list in 45 seconds after it went offline.  Search online devices manually You can also click to refresh the online device list manually. The © Hikvision...
  • Page 123 8 characters, including upper case letters, lower case letters, numbers and special characters) in order to increase the security of your product.  Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. Figure A.1.2 Modify Network Parameters © Hikvision...

  • Page 124: Appendix 2 Port Mapping

     In the speed dome, the 8200~8210 ports change with the 8000 port with a constant value of 200. E.g. if the 8000 port is changed to 8005, then the 8200~8210 ports should be changed to 8205~8215. Example: © Hikvision...
  • Page 125 Figure A.2.3 Port Mapping The port of the network speed dome cannot conflict with other ports. For example, some web management port of the router is 80. Change the speed dome port if it is the same as the management port. © Hikvision...

  • Page 126: Appendix 3 Statics, Interference Lightning And Surge Protection

    Figure A.3.1 Lightning & Surge Protection Grounding for Cement Pole/Wall Installation: When the speed dome is installed in environment where is relatively insulating to the earth, e.g., cement pole or cement wall, then only the control center requires proper grounded locally. Refer to © Hikvision...
  • Page 127 User Manual of Network Speed Dome the following figure. Power Power Display Power supply board Power supply board Video cable Operating center Control line Keyboard Cement pole/wall 1.5m underground Figure A.3.2 Grounding in Cement Pole/Wall Installation © Hikvision...
  • Page 128 Refer to the following figure. Power Power Display Power supply board Power supply board Video cable Control line Operating Center Keyboard Cement pole/wall 1.5m 1.5m underground underground Figure A.3.3 Lightening-protection Grounding in Cement Pole/Wall Installation © Hikvision...
  • Page 129 Figure A.3.4 Grounding in Metal Pole Installation Note: If the fiber optics, lightening protector or other device are applied during the transmission of speed dome, such devices as well as the video cables routing through must be proper grounded. © Hikvision...

  • Page 130: Appendix 4 Waterproof

    Make sure that the L-shape pole mount is designed with a certain inclination angle as shown in following figure. Water won’t flow from the pole into the speed dome with the inclination angle. θ Figure A.4.1 Customized Mount © Hikvision...

  • Page 131: Appendix 5 Bubble Maintenance

    1. Wipe off the water-drop or oil by soft cloth and dry the bubble. 2. Use oil free cotton cloth to wipe the bubble with alcohol or detergent. 3. Change the cloth to wipe the bubble until the bubble is clean. © Hikvision...

  • Page 132: Appendix 6 Rs485 Bus Connection

    RS485 industry standard so that it will lead to some problems such as signal reflection, anti-jamming ability decline when the devices are faraway. At this time, the dome will be uncontrollable, or self-running, etc. © Hikvision...
  • Page 133 3. The RS485 wire is 3. Reconnect the RS485 wire remotely. disconnected. tightly. 4. RS485 wire is broken. 4. Change a RS485 wire. The speed 1. Reconnect the RS485 wire 1. The connection is loose. dome can tightly. © Hikvision...
  • Page 134 2. Change a RS485 wire. controlled broken. but not 3. The speed dome is too far away 3. Add a terminal resistor. smoothly. from the remote control device. 4. Too many speed domes are 4. Add a RS485 distributor. connected. © Hikvision...

  • Page 135: Appendix 7 24Vac Wire Gauge & Transmission Distance

    65(19) 164(49) 23(7) 37(11) 59(17) 150(45) 21(6) 34(10) 55(16) 139(42) 20(6) 32(9) 51(15) 129(39) 18(5) 30(9) 47(14) 120(36) 17(5) 28(8) 44(13) 113(34) 16(4) 26(7) 42(12) 106(32) 15(4) 25(7) 39(11) 100(30) 14(4) 23(7) 37(11) 95(28) 14(4) 22(6) 35(10) 90(27) © Hikvision...

  • Page 136: Appendix 8 12Vdc Wire Gauge & Transmission Distance

    26(7) 69(20) 9.7(2.8) 15(4) 23(7) 62(18) 8.9(2.5) 14(4) 21(6) 56(16) 8.1(2.3) 13(4) 20(6) 51(15) 7.5(2.1) 11.8(3.4) 18(5) 47(14) 7(2) 11(3.1) 17(5) 44(13) 6.5(1.9) 10.2(2.9) 16(4) 41(12) 6.1(1.7) 9.6(2.7) 15(4) 39(11) 5.7(1.6) 9(2.6) 14(4) 36(10) 5.4(1.5) 8.5(2.4) 13(4) 34(10) © Hikvision...

  • Page 137: Appendix 9 Table Of Wire Gauge Standards

    Appendix 9 Table of Wire Gauge Standards American Cross-sectional Bare Wire British Wire Wire Gauge Area of Bare Gauge(mm) Gauge SWG Wire(mm 0.750 0.4417 0.800 0.5027 0.900 0.6362 1.000 0.7854 1.250 1.2266 1.500 1.7663 2.000 3.1420 2.500 4.9080 3.000 7.0683 © Hikvision...

  • Page 138: Appendix 10 Alarm In/Out Connections

     For DC power supply (left diagram), the input voltage must be no more than 30VDC, 1A.  For AC power supply, the external relay must be used (right diagram) to prevent damages to the speed dome and avoid risk of electric shock. 0503001050326 © Hikvision...

Table of Contents
