5-inch high-definition network speed dome
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
5-inch High-definition Network
Speed Dome
DS-2DF5276 series
User Manual
UD.6L0201D1107A01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-2DF5276 Series and is the answer not in the manual?

Questions and answers

Related Manuals for HIKVISION DS-2DF5276 Series

Summary of Contents for HIKVISION DS-2DF5276 Series

  • Page 1 5-inch High-definition Network Speed Dome DS-2DF5276 series User Manual UD.6L0201D1107A01...
  • Page 2 Certification does not cover the performance or reliability of the security or signaling aspects of this product. UL MAKES NO REPRESENTATIONS, WARRANTIES OR CERTIFICATIONS WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING RELATED FUNCTIONS OF THIS PRODUCT.” 0500041030710 © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 3 The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For more information see: www.recyclethis.info. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 4  If the product does not work properly, please contact your dealer or the nearest service center. Never attempt to disassemble the product yourself. (We shall not assume any responsibility for problems caused by unauthorized repair or maintenance.) © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 5  Please use a soft and dry cloth when clean inside and outside surfaces of the product cover. Do not use alkaline detergents.  Improper use or replacement of the battery may result in hazard of explosion. Please use the manufacturer recommended battery type. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 6: Table Of Contents

    Configuring Smart Tracking ....................40 Clearing PTZ Configurations ....................41 Chapter 6 Speed Dome Configuration ..................42 Configuring Local Parameters .................... 42 Configuring Time Settings ....................43 Configuring Network Settings.................... 46 © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 7 Viewing Device Information .................... 100 10.6 Maintenance ........................101 10.6.1 Rebooting the Speed Dome ..................101 10.6.2 Restoring Default Settings ..................101 10.6.3 Importing/Exporting Configuration File ..............102 10.6.4 Upgrading the System ..................... 103 © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 8 User Manual of Network Speed Dome 10.7 RS-485 Settings ....................... 104 Appendix ............................105 Appendix 1 SADP Software Introduction ..................105 Appendix 2 Port Mapping ......................107 © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 9: Chapter 1 Overview

    The dome can be programmed to move within the limit stops (left/right, up/down).  Scan Modes The dome provides 5 scan modes: auto scan, tilt scan, frame scan, random scan and panorama scan. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 10  Slow Shutter In slow shutter mode, the shutter speed will automatically slow down in low illumination conditions to maintain clear video images by extending the exposure © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 11 Comparing with the general 2D digital noise reduction, the 3D digital noise reduction function processes the noise between two frames besides processing the noise in one frame. The noise will be much less and the video will be clearer. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 12: Chapter 2 Network Connection

    Figure 2-1.  Refer to the Figure 2-2 to set the network speed dome over the LAN via a switch or a router. Network Cable Figure 2-1 Connecting Directly © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 13: Detecting And Changing The Ip Address

     For accessing the network speed dome from different subnets, please set the gateway for the network speed dome after you logged in. For detailed information, please refer to Section 6.3.1 Configuring TCP/IP Settings. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 14: Setting The Network Speed Dome Over The Wan

    Please call the router manufacturer for assistance with port mapping. Refer to Appendix 2 for detailed information about port mapping. 5. Visit the network speed dome through a web browser or the client software over © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 15: Dynamic Ip Connection

    5. Apply a domain name from a domain name provider. 6. Configure the DDNS settings in the setting interface of the router. 7. Visit the speed dome via the applied domain name. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 16 2. Configure the DDNS settings in the DDNS Settings interface of the network speed dome. Refer to Section 6.3.4 Configuring DDNS Settings for detailed configuration. 3. Visit the speed dome via the applied domain name. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 17 2. Access the network speed dome through the LAN with a web browser or the client software. 3. Enable DDNS and select IP Server as the protocol type. Refer to Section 6.3.4 Configuring DDNS Settings for detailed configuration. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 18: Chapter 3 Access To The Network Speed Dome

    The default user name is admin, password is 12345. Figure 3-1 Login Interface 5. Install the plug-in before viewing the live video and operating the speed dome. Please follow the installation prompts to install the plug-in. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 19 User Manual of Network Speed Dome Figure 3-2 Download and Install Plug-in Figure 3-3 Install Plug-in (1) Figure 3-4 Install Plug-in (2) © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 20: Accessing By Client Software

    Follow the installation prompts to install the client software and WinPcap. The configuration interface and live view interface of client software are shown bellow. Figure 3-6 iVMS-4200 PCNVR Control Panel © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 21  For detailed information about client software of our company, please refer to the user manual of the software. This manual mainly introduces accessing to the network speed dome by web browser. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 22: Chapter 4 Live View

    Log in the network speed dome to enter the live view page, or you can click on the menu bar of the main page to enter the live view page. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 23: Starting Live View

    Configure the image size and stream type of the live video. 4.3 Starting Live View In the live view window as shown in Figure 4-3, click on the toolbar to start the live view of the speed dome. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 24  Left click a position of the live video. The corresponding position will be moved to the center of the live video.  Hold down the mouse button and drag the mouse to the lower right on left © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 25: Recording And Capturing Pictures Manually

    Configuration > Local Configuration interface. To configure remote automatic recording, please refer to Section 7.2 Configuring Recording Schedule. The captured image will be saved as a JPEG file in your computer. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 26: Operating Ptz Control

    A preset is a predefined image position. For the defined preset, you can click the calling button to quickly view the desired image position.  Setting a Preset: Steps: 1. In the PTZ control panel, select a preset number from the preset list. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 27 The following presets are predefined with special commands. You can only call them but not configure them. For instance, preset 99 is the “Start auto scan”. If you call the preset 99, the speed dome starts auto scan function. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 28: Setting / Calling A Patrol

    1. In the PTZ control panel, click to enter the patrol settings interface. 2. Select a patrol number from 3. Click to enter the adding interface of preset as shown in Figure 4-7. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 29  Calling a Patrol: In the PTZ control panel, select a defined patrol from and click to call the patrol as shown in Figure 4-8. Figure 4-8 Calling a Preset © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 30: Setting / Calling A Pattern

    4-10 is displayed on the screen. • Pan the speed dome to the right or left. • Tilt the speed dome up or down. • Zoom in or out. • Refocus the lens. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 31: Configuring Live View Parameters

    The default setting of stream type is Please refer to Section 6.4.1 Configuring Video Settings for more detailed parameter settings of the main stream and sub-stream respectively. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 32 User Manual of Network Speed Dome  Image Size: You can scale up/down the live view image by clicking . the image size can be 4:3, 16:9, original or auto. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 33: Chapter 5 Ptz Configuration

    3. Click Set to save the position. Call/delete an Initial Position:  You can click to call the initial position. You can click delete the initial position and restore the factory default initial position. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 34: Configuring Basic Ptz Parameters

     Auto Scan Speed: The dome provides 5 scan modes: auto scan, tilt scan, frame scan, random scan and panorama scan. The scan speed can be set from level 1 to 40. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 35: Configuring Ptz Limit Stops

    The dome can be programmed to move within the configurable limit stops (left/right, up/down). Steps: 1. Enter the Limit Configuration interface: Configuration > Advanced Configuration > PTZ > Limit Figure 5-3 Configure the PTZ Limit © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 36: Configuring Scheduled Tasks

    You can configure the network dome to perform a certain action automatically in a user-defined time period. Steps: 1. Enter the Scheduled Task Settings interface: Configuration> Advanced Configuration> PTZ > Scheduled Tasks Figure 5-4 Configure Scheduled Tasks © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 37 Start Time and End Time for each task, and click Enter on your keyboard to enter the time. (4) Choose the task type from the drop-down list. You can choose scan, preset, pattern and etc. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 38: Configuring Park Actions

    Scheduled Tasks function is prior to Park Action function. When these two functions are set at the same time, only the Scheduled Tasks function takes effect. Steps: 1. Enter the Park Action Settings interface: Configuration > Advanced Configuration> PTZ > Park Action © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 39: Configuring Privacy Mask

    Privacy mask enables you to cover certain areas on the live video to prevent certain spots in the surveillance area from being live viewed and recorded. Steps: 1. Enter the Privacy Mask Settings interface: Configuration > Advanced Configuration> PTZ > Privacy Mask © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 40 Privacy Mask List area; you can select a mask and click to delete it from the list; you can also define the color of the masks. Figure 5-10 Privacy Mask List © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 41: Configuring Smart Tracking

    Configuration > Advanced Configuration> PTZ > Smart Tracking Figure 5-12 Configure Smart Tracking 2. Check the check box to enable smart tracking function. 3. Click the PTZ buttons to select an object. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 42: Clearing Ptz Configurations

    1. Enter the Clearing Configuration interface: Configuration > Advanced Configuration> PTZ > Clear Config 2. Check the checkbox of the items you want to clear. 3. Click to clear the settings. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 43: Chapter 6 Speed Dome Configuration

    UDP: Provides real-time audio and video streams. HTTP: Allows the same quality as of TCP without setting specific ports for streaming under some network environments. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 44: Configuring Time Settings

    There are Time Zone, Time Synchronization, Daylight Saving Time(DST) functions for setting the time. Time Synchronization consists of auto mode by Network Time Protocol(NTP) server and manual mode. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 45 National Time Center (IP Address: 210.72.145.44). If the speed dome is set in a customized network, NTP software can be used to establish a NTP server for time synchronization. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 46 Purpose: If there is the habit of adjusting clocks forward in your country in certain time period of a year, you can turn this function on. The time will be adjusted © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 47: Configuring Network Settings

    TCP/IP settings must be properly configured before you operate the speed dome over network. IPv4 and IPv6 are both supported. Steps: 1. Enter TCP/IP Settings interface: Configuration > Basic Configuration > Network > TCP/IP Or Configuration > Advanced Configuration > Network > TCP/IP © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 48  If the DNS server settings are required for some applications (e.g., sending email), you should properly configure the Preferred DNS Server and Alternate DNS server. Figure 6-8 DNS Server Settings © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 49: Configuring Port Settings

    6.3.3 Configuring PPPoE Settings Purpose: If you have no router but only a modem, you can use Point-to-Point Protocol over Ethernet (PPPoE) function. Steps: 1. Enter the PPPoE Settings interface: © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 50: Configuring Ddns Settings

    Registration on the DDNS server is required before configuring the DDNS settings of the speed dome. Steps: 1. Enter the DDNS Settings interface: Configuration > Advanced Configuration > Network > DDNS © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 51 (4) Enter the User Name and Password registered on the DynDNS website. (5) Click to save the settings. Figure 6-12 DynDNS Settings IP Server:  Steps: (1) Enter the Server Address of the IP Server. (2) Click to save the settings. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 52 (2) In the Domain text field, enter the domain name obtained from the NO-IP website. (3) Enter the Port of NO-IP server. (4) Enter the User Name and Password registered on the NO-IP website. (5) Click to save the settings. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 53: Configuring Snmp Settings

    The SNMP version you select should be the same as that of the SNMP software. Steps: 1. Enter the SNMP Settings interface: Configuration > Advanced Configuration > Network > SNMP Figure 6-15 SNMP Settings 2. Check the corresponding version checkbox ( © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 54: Configuring 802.1X Settings

    Before connecting the Network Camera to the protected LAN, please apply a  digital certificate from a Certificate Authority. The network camera requests access to the protected LAN via the  © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 55: Configuring Qos Settings

    6.3.7 Configuring QoS Settings Purpose: QoS (Quality of Service) can help solve the network delay and network congestion by configuring the priority of data sending. Steps: 1. Enter the QoS Settings interface: © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 56: Configuring Ftp Settings

    You can set a FTP server and configure the following parameters for uploading captured pictures. Steps: 1. Enter the FTP Settings interface: Configuration >Advanced Configuration > Network > FTP Figure 6-19 FTP Settings © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 57: Configuring Nat Settings

    Wide Area Network via the router. Steps: 1. Enter the UPnP settings interface. Configuration >Advanced Configuration > Network > NAT 2. Check the Enable UPnP checkbox © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 58: Configuring Email Settings

    Before you start: Please configure the DNS Server settings under Basic Configuration > Network > TCP/IP or Advanced Configuration > Network > TCP/IP before using the Email function. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 59 SMTP Port: The SMTP port. The default TCP/IP port for SMTP is 25. Enable SSL: Check the checkbox to enable SSL if it is required by the SMTP server. Attached Image: Check the checkbox of Attached Image if you want to send © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 60 Receiver: Select the receiver to which the email is sent. Up to 2 receivers can be configured. Receiver: The name of the user to be notified. Receiver’s Address: The email address of user to be notified. 3. Click to save the settings. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 61: Configuring Video And Audio Settings

    Select the stream type to video stream, or video & audio composite stream. The audio signal will be recorded only when the Video Type is Video & Audio. Resolution: Select the resolution of the video output. Bitrate Type: © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 62: Configuring Audio Settings

    Or Configuration > Advanced Configuration > Video / Audio > Audio Figure 6-25 Audio Settings 2. Configure the following settings. Audio Encoding: G.711ulaw, G.711alaw and G.726 selectable. 3. Click to save the settings. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 63: Configuring Roi Settings

    4. Adjust the Enhance the level from 1 to 6. The higher the value, the better image quality in the red frame. 5. Enter a Region Name and click Save to save the settings. Figure 6-26 Region of Interest © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 64: Configuring Image Settings

    Steps: 1. Enter the Display Settings interface: Configuration > Basic Configuration> Image> Display Settings Or Configuration > Advanced Configuration> Image> Display Settings 2. Set the image parameters of the speed dome. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 65 This feature enhances the difference in color and light between parts of an image. The value ranges from 0 to 100. Saturation This feature is used to adjust color saturation of the image. The value ranges from 0 to 100. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 66 The value of iris needs to be adjusted manually. The shutter and gain values will be adjusted automatically according to the brightness of the environment. Figure 6-28 Manual Iris  Shutter Priority: © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 67  Schedule In Schedule mode, you can set the time schedule for day mode as shown in Figure 6-32. The rest time out of the schedule is for night mode. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 68 The slow shutter value can be set to Low, Normal and High. Figure 6-34 Slow Shutter Lens Initialization The lens operates the movements for initialization when you check the check box of Lens Initialization. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 69 This function varies depending on the models of speed dome. 3D Digital Noise Reduction You can enable or disable the 3D Digital Noise Reduction function as shown in Figure 6-36. The level ranges from 0 to 100. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 70: Configuring Osd Settings

    Direction: Displays panning and tilting direction, with the format of PXXX TXXX. The XXX following P indicates the degrees in pan direction, while the XXX following T indicates the degrees in tilt position. Time: Supports for time display. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 71 4. Select from the drop-down list to set the time format, date format and display mode. 5. You can use the mouse to click and drag the text frame in the live view window to adjust the OSD position. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 72: Configuring Text Overlay Settings

    4. Use the mouse to click and drag the red text frame in the live view window to adjust the text overlay position. 5. Click There are up to 8 text overlays configurable. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 73: Configuring And Handling Alarms

    Steps: 1. Set the Motion Detection Area. Steps: (1) Enter the motion detection settings interface Configuration > Advanced Configuration> Events > Motion Detection (2) Check the checkbox of Enable Motion Detection. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 74 (5) Move the slider to set the sensitivity of the detection. 2. Set the Arming Schedule for Motion Detection. Steps: (1) To edit the arming schedule as shown in Figure 6-43, click Figure 6-42. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 75 (Optional). (5) Click to save the settings. The time of each period can’t be overlapped. Up to 4 periods can be configured for each day. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 76 Send an exception or alarm signal to remote management software when an event occurs.  Send Email Send an email with alarm information to a user or users when an event occurs. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 77: Configuring Video Loss Alarm

    6.6.5 Configuring Alarm Output to set the alarm output parameters. 6.6.2 Configuring Video Loss Alarm Steps: 1. Enter the Video Loss Setting interface: Configuration > Advanced Configuration> Events > Video Loss © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 78: Configuring Tamper-Proof Alarm

    6.6.3 Configuring Tamper-proof Alarm Purpose: You can configure the speed dome to trigger the alarm actions when the lens is covered. Steps: 1. Enter the Tamper-proof Settings interface: © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 79: Configuring External Alarm Input

    Step 3 Set the Alarm Actions for Motion Detection in Section 6.6.1 Configuring Motion Detection. 6. Click to save the settings. 6.6.4 Configuring External Alarm Input Steps: 1. Enter the Alarm Input Settings interface: © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 80 6. You can also choose the PTZ linking for the alarm input. Check the relative checkbox and select the No. to enable Preset Calling, Patrol Calling or Pattern Calling. 7. You can copy your settings to other alarm inputs. 8. Click to save the settings. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 81: Configuring Alarm Output

    Refer to Step 2 Set the Arming Schedule for Motion Detection in Section 6.6.1 Configuring Motion Detection. 6. You can copy the settings to other alarm outputs. 7. Click to save the settings. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 82: Handling Exception

    2. Check the checkbox to set the actions taken for the Exception alarm. Refer to Step 3 Set the Alarm Actions Taken for Motion Detection in Section 6.6.1 Configuring Motion Detection. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 83 User Manual of Network Speed Dome Figure 6-50 Exception Settings 3. Click to save the settings. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 84: Chapter 7 Record Settings

    (2) If the status of the disk is Uninitialized as shown in Figure 7-2, check the corresponding checkbox to select the disk and click to start initializing the disk. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 85: Configuring Recording Schedule

    By default, the record files of scheduled recording are stored in the SD card (if supported) or in the network disk. Steps: 1. Enter the Record Schedule Settings interface: Configuration > Advanced Configuration> Storage > Record Schedule © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 86 The Post-record time can be configured as 5 s, 10 s, 30 s, 1 min, 2 min, 5 min or 10 min.  Overwrite: If you enable his function and the HDD is full, the new record files overwrite the oldest record files automatically. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 87  Record Triggered by Motion Detection If you select Motion Detection, the video will be recorded when the motion is detected. Besides configuring the recording schedule, you have to set the motion © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 88 Besides configuring the recording schedule, you have to configure the settings on the Motion Detection and Alarm Input Settings interfaces. Please refer to Section 6.6.1 and Section 6.6.4 for detailed information. Figure 7-8 Edit Record Schedule © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 89: Configuring Snapshot Settings

    1) Configure the FTP settings and check checkbox in FTP Settings interface. Please refer to Section 6.3.8 Configuring FTP Settings for more details to configure FTP parameters. 2) Check the Enable Timing Snapshot checkbox. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 90 Detection in Section 6.6.1 Configuring Motion Detection, or Step 4 Configuring External Alarm Input in Section 6.6.1 Configuring Motion Detection. 3) Check the Enable Event-triggered Snapshot checkbox. Figure 7-9 Snapshot Settings © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 91: Chapter 8 Playback

    Task 1: To play back the video files Steps: 1. Click on the menu bar to enter playback interface. Figure 8-1 Playback Interface 2. Select the date and click Figure 8-2 Search Video © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 92 Set playback time field. You can also click to zoom out/in the progress bar. Figure 8-4 Set Playback Time © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 93  You can click to stop the downloading.  The total number displays the amount of the video files.  The video files listed page. click © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 94 3. Set the start time and end time. Click Search. The corresponding picture files are listed on the left. 4. Check the checkbox in front of the files that you need to download. 5. Click to download the files. Figure 8-8 Picture Downloading interface © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 95: Chapter 9 Log Searching

    Minor Type, Start Time and End Time as shown in Figure 9-2. 3. Click to search log files. The matched log files will be displayed on the Log interface. Figure 9-2 Log Searching © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 96 User Manual of Network Speed Dome 4. To export the log files, click to save the log files in your computer. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 97: Chapter 10 Others

    Operator or User. 3. In the Basic Permission field and Camera Configuration field, you can check or uncheck the permissions for the new user. 4. Click to finish the user addition. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 98 2. Modify the User Name, Level or Password. 3. In the Basic Permission field and Camera Configuration field, you can check or uncheck the permissions. 4. Click to finish the user modification. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 99  Delete a User Steps: 1. Left-click the user name you want to delete and click 2. Click on the pop-up dialogue box to delete the user. Figure 10-4 Delete a User © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 100: Configuring Rtsp Authentication

    When you enable this function, you can log into the camera without a username and password. In login interface, check the Anonymous checkbox and click Login to enter the camera as shown in Figure 10-7. Figure 10-6 Anonymous Login © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 101: Configuring Ip Address Filter

    Or Configuration > Advanced Configuration> System > Device Information In the Device Information interface, you can edit the Device Name. Other information of the network speed dome, such as Model, Serial No., Firmware © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 102: Maintenance

    Configuration > Basic Configuration> System > Maintenance Or Configuration > Advanced Configuration> System > Maintenance: 2. Click to reboot the network speed dome. Figure 10-10 Reboot the Device 10.6.2 Restoring Default Settings Steps: © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 103: Importing/Exporting Configuration File

    You need to reboot the speed dome after importing configuration file. 3. Click and set the saving path to save the configuration file in local storage. Figure 10-12 Import/Export Configuration File © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 104: Upgrading The System

    The upgrading process will take 1 to 10 minutes. Please don't disconnect power of the speed dome during the process. The speed dome reboots automatically after upgrading. Figure 10-13 Remote Upgrade © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 105: Settings

    Parity and Flow Control is None. The Baud Rate, PTZ Protocol and PTZ Address parameters of the speed dome should be exactly the same as those of the remote control device. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 106: Appendix

    45 seconds after it went offline.  Search online devices manually You can also click to refresh the online device list manually. The newly searched devices will be added to the list. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 107 Serial code is a series of characters combined by the start time and the serial number of the device. 2. Input the code in the Serial code field and click to restore the default password. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.

  • Page 108: Appendix 2 Port Mapping

    3. Set the port mapping in the virtual severs of Forwarding. You need to forward ports 80, 8000, 8200~8210 and 554 for a speed dome.  You can change 80, 8000 and 554 ports value in the speed dome with web browser or © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 109 The port of the network speed dome cannot conflict with other ports. For example, some web management port of the router is 80. Change the speed dome port if it is the © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
  • Page 110 User Manual of Network Speed Dome same as the management port. © Hikvision Digital Technology Co., Ltd. All Rights Reserved.
