Installation

This section contains information for mounting, connecting, and wiring the XTP T HWP 101.
Topics in this section include:
•
•
•
•
•
•

Installation Overview

The XTP T HWP 101 can be installed into the provided mud ring or a UL Listed metal
electrical junction box.
NOTE: If using a junction box, use a metal one only.
1.
2.
Installation Overview
Metal Junction Box or Mud Ring Installation
Rear Panel Connectors
Mounting the XTP T HWP 101
Front Panel Connectors
Connection Details
Prepare the mounting surface.
CAUTION: Risk of personal injury. Failure to check the items listed below may
result in personal injury.
ATTENTION : Risque de blessure. La non-vérification des éléments listés
ci-dessous peut provoquer des blessures.
ATTENTION:
• Failure to check the items listed below may result in property damage.
• La non-vérification des éléments listés ci-dessous peut provoquer des
dommages matériels.
Ensure there are no utility cables or pipes at the intended location that might be
•
damaged or cause injury when installing the device.
Check that the installation meets building, electrical, and safety codes.
•
Ensure there is sufficient space behind the device.
•
Choose a location that will allow cable runs without interference.
•
NOTES:
• Cables may need to be installed in the wall or conduits before installation.
• The mud ring does not require attachment to wall studs.
• For metal junction boxes, refer to the manufacturer for more installation
requirements.
Cut a hole in the mounting surface (see
page).
Mounting Surface Preparation
XTP T HWP 101 Wallplate Transmitter • Installation
on the next
