Summary of Contents for Extron electronics XTP T HWP 101
- Page 1 User Guide XTP Systems XTP T HWP 101 XTP Transmitter – Decora Wallplate ® 68-2422-01 Rev. B 01 16...
-
Page 2: Safety Instructions
Safety Instructions Safety Instructions • English Инструкция по технике безопасности • Русский WARNING: This symbol, , when used on the product, is intended to ПРЕДУПРЕЖДЕНИЕ: Данный символ, , если указан alert the user of the presence of uninsulated dangerous voltage within the на... - Page 3 “Extron Safety and Regulatory Compliance Guide” on the Extron website. Copyright © 2016 Extron Electronics. All rights reserved. Trademarks All trademarks mentioned in this guide are the properties of their respective owners. The following registered trademarks , registered service marks...
- Page 4 Conventions Used in this Guide Notifications The following notifications are used in this guide: Potential risk of severe injury or death. WARNING: AVERTISSEMENT : Risque potentiel de blessure grave ou de mort. ATTENTION: • Risk of property damage. • Risque de dommages matériels. NOTE: A note draws attention to important information.
-
Page 5: Table Of Contents
UL Listed Metal Junction Box Installation ..7 Rear Panel Connectors ........8 XTP System Configuration Software ..21 Mounting the XTP T HWP 101 ......9 Software Installation........... 21 Front Panel Connectors ........10 Software Download Center Page ....21 Connection Details .......... - Page 6 XTP T HWP 101 Wallplate Transmitter • Contents...
-
Page 7: Introduction
XTP matrix switcher (see Power Connection on page 13). To configure and control the XTP T HWP 101, connect a host device, such as a computer, to the USB Config port and enter Simple Instruction Set (SIS) commands (see Configuration and Control... -
Page 8: System Compatibility
The following diagram shows one way the XTP T HWP 101 can be integrated in an XTP point-to-point application. The transmitter can also be used with an XTP matrix switcher (see the XTP matrix switcher user guide for more details on matrix applications and configuration). -
Page 9: Features
Remote power capability — Allows the XTP T HWP 101 to be powered by an XTP • CrossPoint Matrix Switcher or XTP Power Injectors to simplify integration. -
Page 10: Installation
• Connection Details Installation Overview The XTP T HWP 101 can be installed into the provided mud ring or a UL Listed metal electrical junction box. NOTE: If using a junction box, use a metal one only. Prepare the mounting surface. -
Page 11: Metal Junction Box Or Mud Ring Installation
Route and connect cables to the rear panel connectors (see Rear Panel Connectors on page 8). Mount the XTP T HWP 101 to the mud ring or metal junction box (see Mounting the XTP T HWP 101 on page 9). -
Page 12: Mud Ring Installation
Backing Clip Backing Clip 0.75" #6-32 Screw 1.25" #6-32 Screw Figure A Figure B Figure 3. Backing Clip Installation Use a cross-head (Phillips) screwdriver to fasten the screws and backing clips in place. XTP T HWP 101 Wallplate Transmitter • Installation... -
Page 13: Ul Listed Metal Junction Box Installation
Le blindage tressé et le blindage en aluminium devraient être connectés à la masse d’un équipement à l’autre bout du câble. XTP T HWP 101 Wallplate Transmitter • Installation... -
Page 14: Rear Panel Connectors
Rear Panel Connectors XTP output connector — Connect a twisted pair cable to the RJ-45 connector labeled “XTP OUT” on the XTP T HWP 101 and the XTP input port on another XTP TP Cable Termination and Recommendations device to pass all signals (see page 11). -
Page 15: Mounting The Xtp T Hwp 101
Figure 7. Installing the XTP T HWP 101 in a Metal Junction Box Align the mounting screws on the XTP T HWP 101 with the available holes on the mud ring (see figure 6, ) or metal junction box (see figure 7,... -
Page 16: Front Panel Connectors
The maximum HDMI cable length is 15 feet (4.6 meters). • Use an Extron HDMI LockIt Cable Lacing Bracket to secure the HDMI connector to the device (see HDMI Connection on the next page). XTP T HWP 101 Wallplate Transmitter • Installation... -
Page 17: Connection Details
Orange Green Orange White-green White-orange White-green Blue Blue Blue White-blue White-blue White-blue Orange Green Green White-brown White-brown White-brown Brown Brown Insert Twisted Pair Wires Brown RJ-45 Connector Figure 10. TP Cable Termination XTP T HWP 101 Wallplate Transmitter • Installation... - Page 18 Supported cables The XTP T HWP 101 is compatible with shielded twisted pair (F/UTP, SF/UTP, and S/FTP) cable. ATTENTION: • Do not use Extron UTP23SF-4 Enhanced Skew-Free AV UTP cable or STP201 cable to link the XTP products. • N’utilisez pas le câble AV Skew-Free UTP version améliorée UTP23SF d’Extron ou le câble STP201 pour relier les produits XTP.
-
Page 19: Power Connection
Power Supply Output Cord Figure 11. Power Wiring The XTP T HWP 101 can be connected to a local power supply. See the notifications on the next page for local power considerations. XTP T HWP 101 Wallplate Transmitter • Installation... - Page 20 La longueur idéale est de 5 mm (3/16 inch). TIP: Do not tin the stripped power supply leads. Tinned wires are not as secure in the captive screw connectors and could be pulled out. XTP T HWP 101 Wallplate Transmitter • Installation...
- Page 21 Remote power The XTP T HWP 101 can be powered remotely through an XTP Power Injector or through an XTP matrix switcher. ATTENTION: • XTP remote power is intended for indoor use only. No part of the network that uses XTP remote power should be routed outdoors.
-
Page 22: Operation
(see EDID Minder on page 29). The XTP T HWP 101 can record and save EDID in a user memory location, select a pre-defined EDID, or use EDID from a display connected to a receiver. EDID stored in the user memory location can come from the display connected to a receiver or a custom EDID imported through the XTP System Configuration Software. -
Page 23: Reset Mode
DO mistake, cycle power to NOT operate the firmware the device to return to the version that results from this firmware version running prior mode reset. to the reset. XTP T HWP 101 Wallplate Transmitter • Operation... -
Page 24: Sis Configuration And Control
Error Responses When the XTP T HWP 101 receives an SIS command and determines that it is valid, it performs the command and sends the corresponding response to the host device. If the command is determined invalid or contains invalid parameters, the transmitter returns an error response to the host. -
Page 25: Using The Command And Response Tables For Sis Commands
= Carriage return with no line feed = Pipe (can be used interchangeably with the character). • = Space = Escape key = Can be used interchangeably with the character. XTP T HWP 101 Wallplate Transmitter • SIS Configuration and Control... -
Page 26: Command And Response Tables For Sis Commands
0 = video or TMDS not detected = Video signal status = video or TMDS detected = no source = HDCP status = HDCP-compliant source = non-HDCP compliant source XTP T HWP 101 Wallplate Transmitter • SIS Configuration and Control... -
Page 27: Xtp System Configuration Software
Configuration Software This section contains installation and configuration procedures for the XTP System Configuration Software for configuring and controlling the XTP T HWP 101. It can also be controlled with SIS commands (see SIS Configuration and Control on page 18). Topics in... -
Page 28: Software Product Page
Open the executable (.exe) file from the save location. Follow the instructions that appear on the screen. By default, the installation creates a directory in the Program Files or Program Files (x86) folder. XTP T HWP 101 Wallplate Transmitter • XTP System Configuration Software... -
Page 29: Software Operation
Software Operation The XTP T HWP 101 can be controlled directly from the rear panel configuration port (see figure on page 8) or remotely from an XTP matrix switcher. Connections The XTP System Configuration Software opens to the screen. This screen is Connections used to establish communication with an XTP device through USB connection. -
Page 30: Menu Bar
Backup and Restore Commissioning Report available when directly connected to the XTP T HWP 101. See an XTP matrix switcher user guide (www.extron.com) for more information on these features. XTP T HWP 101 Wallplate Transmitter • XTP System Configuration Software... -
Page 31: Update Firmware
This option resets all disabled confirmation dialogs to the default settings. From the menu, select . The Tools Software Preference Software Preference dialog box opens. Figure 24. Software Preference Dialog Box Click the button. The dialog box closes. Reset XTP T HWP 101 Wallplate Transmitter • XTP System Configuration Software... - Page 32 This option opens the XTP System Configuration Software help file in a Web browser. From the menu, select Help Help Extron Website This option opens the Extron website in a Web browser. From the menu, select Help Extron Website XTP T HWP 101 Wallplate Transmitter • XTP System Configuration Software...
-
Page 33: Device Settings
Factory Reset settings except for firmware. NOTE: This is the same as the SIS command (see the Reset mode ZXXX command on page 20). XTP T HWP 101 Wallplate Transmitter • XTP System Configuration Software... - Page 34 HDCP — Displays the HDCP status of the input. Current EDID Information section EDID — Displays the current resolution and refresh rate. Audio Information section This section does not apply to the XTP T HWP 101. XTP T HWP 101 Wallplate Transmitter • XTP System Configuration Software...
-
Page 35: Edid Minder
Navigate to and select the desired EDID file and click . The EDID file appears in the Open panel ( Available EDID Assign the EDID file from the panel to import the EDID to the device. Available EDID XTP T HWP 101 Wallplate Transmitter • XTP System Configuration Software... - Page 36 Common Timings Connected Outputs listing the EDID settings common among the selected outputs. Select the desired common EDID. The EDID is shown in the panel. Available EDID XTP T HWP 101 Wallplate Transmitter • XTP System Configuration Software...
-
Page 37: Reference Information
CUT-OUT AREA FOR WALL MOUNT Top Panel Figure 30. Mounting Template for 1-Gang Mud Rings (Not to Full Scale) Please measure the printed template before cutting. NOTE: Measure the template before cutting. XTP T HWP 101 Wallplate Transmitter • Reference Information... - Page 38 Extron Electronics makes no further warranties either expressed or implied with respect to the product and its quality, performance, merchantability, or fitness for any particular use. In no event will Extron Electronics be liable for direct, indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been advised of such damage.
