- Page 1 OWNER'S MANUAL ENTERTAINER Product may vary slightly from the item pictured due to model upgrades ENTERTAINER...
-
Page 2: Important Safety Instructions
When running, make sure the plastic clip is fastened on your clothing. It is for your safety, should you fall or move too far back on the treadmill. Keep hands away from all moving parts. Never operate the treadmill if it has a damaged cord or plug. Keep the cord away from heated surfaces. ENTERTAINER... -
Page 3: Important Electrical Information
NEVER expose this treadmill to rain or moisture. This treadmill is not designed for use outdoors, near a pool, or in any other high humidity environment. 1.2 IMPORTANT OPERATION INSTRUCTIONS Be sure to read the entire manual before operating your machine. ENTERTAINER... - Page 4 A safety key is provided with this machine. Remove the safety key will stop the walking belt immediately; the treadmill will shut off automatically. Insert the safety key will reset the display. Do not use excessive pressure on console control keys. They are precision set to function properly with little finger pressure. ENTERTAINER...
-
Page 5: Assembly Instructions
When you open the carton, you will find the below spare parts: SPARE PARTS: DESCRIPTION REMARKS Q’TY UPRIGHT CONNECTED SYPHON MAIN FRAME LEFT UPRIGHT RIGHT UPRIGHT COMPUTER PLASTIC COVER BOLT M10*20 SCREW M6*10 FLAT WASHER ALLEN WRENCH ALLEN WRENCH WRENCH W/SCREW DRIVER ENTERTAINER... - Page 6 2. Insert left upright (3) into main frame (2), and then connect them with bolts (14) and flat washers (38). CAUTION: A. Please don’t damage the wires while doing assembly. B. Please don’t tighten ALL BOLTS before STEP (3) ENTERTAINER...
- Page 7 Insert computer left handlebar board into left upright (3) and right upright (4). Connect them with the bolts M8*20 (38) and flat washer (14). 7. To lock the computer right fixed board into the right upright (4). CAUTION: Tighten all the bolts again. ENTERTAINER...
-
Page 8: Technical Parameter
4. Children should not be allowed to play on the treadmill or move the treadmill deck up and down. TECHNICAL PARAMETER BUILT UP SIZE(mm) POWER 220~240V （50~60HZ） 1870*880*1510 RUNNING BELT SIZE(mm) SPEED RANGE 3000 x520 1—20Km/h FOLDABLE SIZE(mm) 1220*880*1615 NET WEIGHT 144KGS LED DISPLAY SPEED, DISTANCE, CALORIES, PULSE, TIME and INCLINE ENTERTAINER... -
Page 9: Exercise Guide
So as you can see, the fitter you are, the healthier and greater you will feel. Warm-up Start each workout with 5 to 10 minutes of stretching and some light exercises. A proper warm-up increases your body temperature, heart rate and circulation in preparation for exercise. Ease into your exercise. ENTERTAINER... -
Page 10: Workout Guidelines
The most important factor here is the amount of effort you put in. The harder and longer you work the more calories you will burn. Effectively this is the same as if you were training to improve your fitness, the difference is the goal. ENTERTAINER... -
Page 11: Operation Guide
1、"CAL/ PULSE" windows: Display the total workout calories or the total workout pulse, normally display calories from 0-999 and to 999 spill over to clear 0. When your workout count/counts down from the inverse direction, it will counts down to 0. When the data will be ENTERTAINER... -
Page 12: Button Functions
D. “VOL+” “VOL-“: volume plus/minus button: When you display SD card or outside connected the video, press the button, you can adjust the volume. E. “MUTE”: is whisht button: Press the button without any voice when you play the SD card or outside frequency. ENTERTAINER... -
Page 13: Start-Up Quickly(Manual)
3 seconds later and the buzzer will make some sounds. 3、 When start the machine, you can press “SPEED UP” “SPEED DOWN” or speed shortcut key to adjust the speed, and press “INCLINE UP” “INCLINE DOWN” or incline shortcut key to adjust the incline. ENTERTAINER... -
Page 14: Manual Mode
TIME window display flashes. Display the advance setting time10:00, press “INCLINE” “SPEED” to set up the exercise time what you need. Press ENTER to enter into the ENTERTAINER... -
Page 15: Program Exercise Chart
“TIME” window will come back to the actual running time to positive direction to count. Program exercise chart: SPEED，INCLINE（Divided into inclines and each incline is the 1/20 of the general incline）. Each program will divide into 20 grades for the exercise time and each time sect has the speed and incline accordingly. ENTERTAINER... - Page 16 8 10 6 8 10 6 INCLINE 1 SPEED INCLINE 1 SPEED INCLINE 1 9 11 9 9 11 9 SPEED INCLINE 2 8 10 8 8 10 8 SPEED INCLINE 2 SPEED 8 10 8 8 10 8 INCLINE 2 ENTERTAINER...
-
Page 17: Range Of Program
2. Attach the magnet end of the safety pulling rope to the computer and also attach the clip of the safety pulling rope to your clothing. 3. To end your workout safely, press the STOP button or pull out the safety pulling rope, then the treadmill will stop immediately. MULTIMEDIA DISPLAY OPERATION EXPLANATION: ENTERTAINER... -
Page 18: Troubleshooting Guide
1.If the plug and the line is 1. Checking the plug and 1.Insert the plug and the line Treadmill loosen. the line is connected well. well. will not start. 2.Not plugged in. 2. Checking the power 2.Reset the power. ENTERTAINER... - Page 19 3.Put both hands to bedew The hand pulse does not a little or scrub with both 3.Reset to test. touch well hands. 1.the connected wire is 1.Use the multimeter to test the Message failure wrong. wire is stand or fall. ENTERTAINER...
- Page 20 1．Safety lock badness 1．Change the safety lock Out of safety lock 2．Test the iron piece of the 2．Computer badness safety lock is dropped out or change the computer. 1． Change 24C02 EEPROM 24C02 message failure 1．Data transfer failure ENTERTAINER...
-
Page 21: Maintenance Instructions
• Inspect the power cord. If the power cord is damaged, contact Lifespan Fitness. • Make sure the power cord is not underneath the treadmill or in any other area where it can become pinched or cut. - Page 22 It may be necessary to lubricate your treadmill running deck at least once every six months to maintain optimal performance of your treadmill (refer to section 4.4 for information). Only use lubricant provided by Lifespan Fitness! Please contact Lifespan Fitness with questions about applying lubricant to your treadmill.
-
Page 23: General Cleaning
IF YOU FAIL TO COMPLY WITH LIFESPAN’S MAINTENANCE AND SERVICING STEPS ABOVE, YOU MAY VOID YOUR WARRANTY. IF YOU REQUIRE A SKILLED LIFESPAN REPRESENTATIVE TO UNDERTAKE ONE OF THE STEPS ABOVE, PLEASE EMAIL US AT lifespanfitness@hotmail.com. 2 General Cleaning ... -
Page 24: How To Check The Running Mat For Proper Lubrication
If the surface is dry to the touch, apply a suitable silicone lubricant. We recommend you use a silicone based spray to lubricate your Lifespan Treadmill. This Can be purchased from your local sports Retailer or a local hardware store. -
Page 25: Belt Tracking Adjustment
If during use, the belt continues to move toward one side, adjustments are necessary. The procedures are as below: ▲ First set speed at approximately 3.5km/h. ▲ Second check the belt shifts to which side. ENTERTAINER... -
Page 26: Warranty Registration
Over adjusting the belt can cause damage to the mat. If the belts has drifted to the RIGHT If the belts has drifted to the LEFT WARRANTY REGISTRATION Please visit the following link to complete the product warranty form online. Please visit: ENTERTAINER... - Page 27 PLEASE NOTE: YOUR WARRANTY IS ONLY VALID IF YOU CAN PROVE YOU ARE THE ORIGINAL PURCHASER ON THIS ITEM (i.e. A copy of the receipt, invoice, delivery date or internet confirmation). ENTERTAINER...
-
Page 28: Exploded Drawing
EXPLODED DRAWING ENTERTAINER... -
Page 29: Parts List
SPRING WASHER COVER FLAT WASHER CUSHION ADJUST CAP PLASTIC COVER RIGHT REAR BOTTOM COVER 120 LEFT REAR BOTTOM COVER LEAD DIRECTION CONNECTED MOTOR ASSEMBLY LEFT END CAP HATCH WASHER RIGHT END CAP 123 MIDDLE-EMPTY INNER TUBE CUSHION ADJUST CLUB ENTERTAINER... - Page 30 φ16*718 CUSHION CONNECTED CLUB AC SINGLE WIRE φ1.5*34 PULL SPRING AC SINGLE WIRE AIR PRESSURE BAR SENSOR φ20*φ8.2*9 OILINESS AXIS SET φ12*516*M6 LEAD DIRECTION MANDRIL φ10*φ8.5*7 MOVING WHEEL BUSHING 1210*630*20 RUNNING BOARD LINE 2600 POWER CABLE φ16*φ28*28 MAGNETIC RING ENTERTAINER...
