LifeSpan Everest 3 User Manual

Ultra high incline treadmill

Advertisement

Quick Links

Everest 3 Ultra High
Incline Treadmill
Product may vary slightly from the item pictured due to model upgrades.
Read all instructions carefully before using this product.
Retain this owner's manual for future reference.
NOTE:
This manual should not be used to guide your purchasing decision. Your product, and the contents inside its carton, may vary
from what is listed in this manual. This manual may also be subject to updates or changes. Updated manuals are available
through our website at
www.lifespanfitness.com.au
USER MANUAL
Find the
Digital Manual
Online

Advertisement

loading
Need help?

Need help?

Do you have a question about the Everest 3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for LifeSpan Everest 3

  • Page 1 Everest 3 Ultra High Incline Treadmill USER MANUAL Find the Digital Manual Online Product may vary slightly from the item pictured due to model upgrades. Read all instructions carefully before using this product. Retain this owner’s manual for future reference.
  • Page 2 TABLE OF CONTENTS Important Safety Instructions ....... 03 II. Important Electrical Information ......05 III.
  • Page 3 I. IMPORTANT SAFETY INSTRUCTIONS WARNING: Read all instructions before using this treadmill. It is important your treadmill receives regular maintenance to prolong its lifespan. Failing to regularly maintain your treadmill may void your warranty. DANGER To reduce the risk of electric shock, disconnect your treadmill from the electrical outlet prior to cleaning and/or service work.
  • Page 4 • The treadmill is intended for in-home use only and is not suitable for commercial environments. • To disconnect, turn all controls to the off setting, remove the safety key, and then remove the plug from the outlet. • The pulse sensors are not medical devices. Various factors, including the user’s movement, may affect the accuracy of heart rate readings.
  • Page 5 II. IMPORTANT ELECTRICAL INFORMATION WARNING! Before starting any exercise program, consult with your physician or health professional. 2. Check all the bolts are securely locked. 3. Never put the treadmill in a humid area, or it will cause troubles. 4. We take no responsibility for any troubles or hurts due to above reasons. 5.
  • Page 6 III. IMPORTANT OPERATING INSTRUCTIONS Plug the power cord of the treadmill directly into a dedicated grounded circuit. This product must be grounded. If it has breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. 2.
  • Page 7 IV. PARTS LIST Key No. Description Qty. Key No. Description Qty. Bottom frame Rubber cushion Main frame Rubber pad 3L/R Upright tube Belt Spacer φ32*φ25*14 Computer frame 5L/R Tablet holder clip Armrest 1pr. Adjustable foot pad Strengthen tube Hole wire Oil tube connection Front roller Cushion...
  • Page 8 Key No. Description Qty. Key No. Description Qty. Phillips screw M5*8 Circuit breaker Phillips screw M4*8 Switch Phillips tapping screw ST4*35 Power socket Phillips tapping screw ST4*16 Rheostat Phillips tapping screw Inverter ST4.0*12 Power wire Phillips tapping screw ST2.9*8 Computer upper wire Phillips tapping screw ST4.0*16 Computer middle wire...
  • Page 9 V. EXPLODED DIAGRAM EXPLODED DIAGRAM |...
  • Page 10 VI. ASSEMBLY INSTRUCTIONS Before assembly, ensure you have adequate space for step up. You may require a second person to assist with assembly. STEP 1 Open the package, take out the following parts and place the main frame flat on the ground. | ASSEMBLY INSTRUCTIONS...
  • Page 11 STEP 2 Connect Computer middle wire (84) and Computer middle and lower wire (85.) 2. Pre assembly Upright tube (3L/R) to the bottom frame (1) with In ner hex bolt M10*20 (40) and Serrated lock washer φ 10*1.2 (69). NOTE: Do not clamp the wires. The Inner-hex bolt M10*20 (40) should not be locked yet. ASSEMBLY INSTRUCTIONS |...
  • Page 12 STEP 3 Connect Computer upper wire (83) and Computer middle wire (84). 2. Attach Computer frame (4) to Upright tube (3L/R) with Inner-hex bolt M1020 (40) and Serrated lock washer 101.2 (69). NOTE: Do not clamp the wires. | ASSEMBLY INSTRUCTIONS...
  • Page 13 STEP 4 1 Insert Armrest (5L/R) into the connecting tubes of Upright tube (3L/R). 2. Connect handle pulse upper wire (88) and lower wire (89), shortcut key upper wire (90) and lower wire (91), and insert the connectors into the designated slots of Computer frame (4). 3.
  • Page 14 STEP 5 1. Tighten all the Inner-hex bolts (40) that were not locked earlier. 2. Insert I-pad up cover (26) into Computer frame (4) and secure it with Phillips screw M5*8 (57). 3. Attach Bottom frame protective cover (24L/R) to Bottom frame (1) using Phillips tapping screw ST4*16 (60). 4.
  • Page 15 VII. OPERATION INSTRUCTIONS Window and Key Description: 1. LED Window Functions: A. Point array window: a) Standby or select the three inverted modes of time, distance and calories b) Displays the speed dot matrix diagram when selecting the program c) Display fat measurement mode and error d) Display the runway and the number of laps, or the speed lift dot pattern.
  • Page 16 3. Function key instructions: o Program key: Press to cycle through programs (manual mode, P01-P12, U01-U03). o Mode Key: Selects manual mode (normal, time, distance, calorie countdown). o Start Key: Starts the motor. o Stop/Pause Key: Stops the motor. o Speed +/-: Adjusts speed. o Incline +/-: Adjusts incline level.
  • Page 17 Fixed Program Mode: 1. Settings: o Default time: 30 minutes (adjustable 5:00-99:00). o Each program has 20 segments with pre-set speeds and inclines. 2. Operation: o Press Start to begin the selected program. o Speed and incline adjust automatically. o Press Stop to halt the program. Setup time / 20 = each segment of the running time PROGRAM TIME...
  • Page 18 Custom Programs: 1. User-Defined Settings (U01-U03): o Select U01-U03 in standby mode. o Configure speed and incline for each of the 20 segments. o Settings are saved permanently until manually changed. 2. Starting a Custom Program: o Select the custom program and press Start. Display Range of Various Parameters: Set parameters Initial value...
  • Page 19 Error Codes and Troubleshooting: Error Possible Cause Solutions Communication failure Check cable connections. Voltage issue Ensure correct voltage. Sensor malfunction Check and reconnect sensors. Lift motor failure Reconnect or replace lift motor. Overcurrent Check motor and controller. Open circuit in motor Reconnect motor interface.
  • Page 20 VIII. EXERCISE GUIDE PLEASE NOTE: Before beginning any exercise program, consult your physician. This is important for individuals over the age of 45 or with pre-existing health problems. The pulse sensors are not medical devices. Various factors, including the user’s movement, may affect the accuracy of heart rate readings.
  • Page 21 COOL DOWN Finish each workout with a light jog or walk for at least 1 minute. Then complete 5 to 10 minutes of stretching to cool down. This will increase the flexibility of your muscles and will help prevent post- exercise problems.
  • Page 22 - Use a damp cloth with mild soap for the belt. Do not let liquid enter the treadmill. - Annually: Remove the motor cover and vacuum inside. Video Tutorial Available at: http://youtu.be/TcuPbJ7KuxQ Lifespan Fitness YouTube Channel: http://www.youtube.com/user/treadmillsvideos | OPERATION GUIDE...
  • Page 23 2. The moving parts should turn freely and quietly. Abnormality of moving parts will affect the safety of the equipment. Inspect and tighten bolts regularly. 3. To better maintain the treadmill and prolong its lifespan, it is suggested that maintenance be done on a regular basis.
  • Page 24 X. REPLACING MOTOR BRUSHES After extended use, the motor brushes in your treadmill motor will wear down, and this can lead to motor failure. It is important that you maintain your motor by replacing the brushes on either side of the motor when they are worn down.
  • Page 25 5. Slide the motor brush out from its slot. If the brush 6. Slide the motor brush lead off the terminal using is shorter than 1cm on the longest side, you will need another small screwdriver or needle nosed pliers. to replace both brushes.
  • Page 26 Any claim against this warranty must be made through your original place of purchase. Proof of purchase is required before a warranty claim may be processed. If you have purchased this product from the Official Lifespan Fitness website, please visit https://lifespanfitness.com.au/warranty-form For support outside of warranty, if you wish to purchase replacement parts or request a repair or service, please visit https://lifespanfitness.com.au/warranty-form and fill in our Repair/Service...
  • Page 27 XII. HAND PULSE TECHNOLOGY This product comes equipped with hand pulse sensors which are used to pick up tiny EKG/ECG signals that run through the body when your heart beats. These electrical EKG/ECG signals are very small and that they must be amplified 1000 times to make the signal useful for the computer to display your pulse.
  • Page 28 W W W. L I F E S PA N F IT N ESS .CO M. AU...
