QuickSpecs

Configuration Information - Factory Integrated Models

NOTE: This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations
are ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for information on
CTO product offerings and requirements.
NOTE: HP does not allow factory integration of options into standard models listed above.
Configure-to-order servers must start with a CTO Enclosure
NOTE: FIO indicates that this option is a Factory Installable Option.
Step 1: Choose Required Base Server Blade Configuration
HP Models
HP Integrity BL890c i2 c7000 Server Blade
NOTE: Choose the base models.
NOTE: Adding Option code "#0D1" to the Server Blade P/N will integrate the
configured blade into the enclosure (which must be on the same order)
NOTE: When adding Option code "#0D1," must select whether server blade should be
installed in an odd slot of the c7000 enclosure (AH384A#001) or in an even slot
(AH384A#002).
HP Integrity BL890c i2 c3000 Server Blade
NOTE: Choose the base models.
NOTE: Adding Option code "#0D1" to the Server Blade P/N will integrate the
configured blade into the enclosure (which must be on the same order)
NOTE: When adding Option code "#0D1," must select whether server blade should be
installed in an odd slot of the c3000 enclosure (AM330A#001) or in an even slot
(AM330A#002).
Base unit standard features:
Sixteen embedded 10 Gigabit Ethernet NIC ports plus (1) additional 10/100 NIC
dedicated to Integrity iLO 3iLO 3 Management
Four Integrated HP Smart Array p410i SAS Controller for internal HDDs
Eight small form factor (SFF) SAS hot plug hard drive bays
HP Integrity Integrated Lights-Out 3
Step 2: Choose Required Options (one of the following from each list unless otherwise
noted):
HP Processors NOTE: Select minimum four (4) and maximum eight (8) processors.
Quad-Core Processors
HP BL8x0c i2 Itanium 9320 (1.33GHz/4-core/16MB/155W) Processor Kit
HP BL8x0c i2 Itanium 9340 (1.6GHz/4-core//20MB/185W) Processor Kit
HP BL8x0c i2 Itanium 9350 (1.73GHz/4-core/24MB/185W) Processor Kit
Dual-Core Processor
HP BL8x0c i2 Itanium 9310 (1.6GHz/2-core/10MB/130W) Processor Kit
HP Memory NOTE: Select minimum four (4) and maximum forty eight (48) memory modules.
HP Integrity BL8x0c i2 8GB (2x4GB) PC3-10600 Registered CAS 9 Memory Kit
HP Integrity BL8x0c i2 16GB (2x8GB) PC3-10600 Registered CAS 9 Memory Kit
HP BL8x0c i2 32GB (2x16GB) PC3-10600 Registered CAS-9 Memory Kit
NOTE: Memory Modules consist of two individual DIMMs.
NOTE: DIMMs must be installed in quads. Therefore, memory modules must be
ordered two (2) at a time, to reach quads (4) to be installed.
c04111605 — DA – 13619 Worldwide — Version 24 — June 01, 2015
HP Integrity BL890c i2 Server Blade
AH384A
AM330A
AH386A
AH387A
AH388A
AH385A
AM327A
AM328A
AM363A
