QuickSpecs
Memory
DIMM installation guidelines:
1. All DIMMs must be DDR3 registered memory modules (R-DIMMs)
2. All four DIMM slots in a memory bank must be populated. For each CPU, the memory blanks are designated as follows:
first bank consists of pairs A and B, second bank consists of pairs C and D and the third bank consists of pairs E and F.
3. Banks must be populated in sequential Alphabetic order, starting with bank A and B for CPU0, followed by banks A and B
for CPU1, etc.
4. All four DIMMs in a memory bank must be identical. Install identical DIMMs in quads, starting with DIMM pairs A and B
CPU0.
5. DIMMs must be installed in decreasing capacity with the largest DIMMs installed in the smallest numbered DIMM slot.
HP Integrity BL890c i2 Server Blade
Standard Memory
16 GB PC3 10600 DDR3 1333MHz ECC DIMMs (4 x 4 GB)
Memory Bus Bandwidth: 4.8GT/s
Standard Memory Plus Optional Memory
Up to 1.5 TB of DDR3 registered (R-DIMMs)memory is available.
Following are memory options available from HP:
HP Memory HP Integrity BL8x0c i2 8GB (2x4GB) PC3-10600 Registered CAS 9 Memory Kit
HP Integrity BL8x0c i2 16GB (2x8GB) PC3-10600 Registered CAS 9 Memory Kit
HP BL8x0c i2 32GB (2x16GB) PC3-10600 Registered CAS-9 Memory Kit
NOTE: Must be installed in quads. Therefore, memory modules must be ordered
two (2) at a time, to reach quads (4) to be installed.
NOTE: DIMMs must be installed in decreasing capacity with the largest DIMMs
smallest numbered slot.
c04111605 — DA – 13619 Worldwide — Version 24 — June 01, 2015
HP Integrity BL890c i2 Server Blade
AM327A
AM328A
AM363A
Page 26
