Technical Specifications - HP Integrity BL890c i2 Quickspecs

QuickSpecs

Technical Specifications

System Unit
SAS RAID HP p410e
Controller
Embedded Dual
Broadcom BCM57711E 10
Gigabit NICs with Flex-10
Dimensions
Shipping Dimensions
Weight
Temperature Range*
Relative Humidity**
*All temperature ratings shown are for sea level. An altitude derating of 1°C per 304.8 m (1.8°F per
1,000 ft) to 3048 m (10,000 ft) is applicable. No direct sunlight allowed. Upper operating limit is
3,048m (10,000 ft) or 70 Kpa/10.1 psia. Upper non-operating limit is 9,144 m (30,000 ft) or 30.3
KPa/4.4 psia.
**Storage maximum humidity of 90% is based on a maximum temperature of 45°C (113°F). Altitude
maximum for storage corresponds to a pressure minimum of 70 KPa.
Disk Drive and Enclosure
Interface
SAS Connectors
Cache Memory Speed
Server Interface
SAS Speed
Cache Memory
Logical Drives Supported
Maximum Logical Drive
Capacity
Host Memory Addressing
RAID Support
Upgradeable Firmware
Network Interface
Compatibility
Data Transfer Method
c04111605 — DA – 13619 Worldwide — Version 24 — June 01, 2015
Height
Depth
Width
Height
Depth
Width
Maximum
Operating
Non-Operating
Storage
Maximum Wet Bulb
Temperature
Operating
Shipping
Storage
3Gb SAS (Serial Attached SCSI)
8 internal (SFF8484) x4 wide port connector
DDR2-800 memory provides up to 4.2 GB/s maximum bandwidth
X1 5.0Gbps PCIe provides 1GB/s maximum bandwidth
Eight x 1 3G SAS provides 2400MB/s maximum bandwidth
Not supported
Up to 32 logical volumes
Up to 64 logical
64-bit, supporting greater than 4GB server memory space
RAID 0 (striping) and 1 (Mirroring), and RAID 0+1 (mirrored and striped)
(not supported with BL8x0c i2 blades)
Upgradeable Firmware with Recovery ROM features Online Drive Flash
requires 256MB, 512MB, or 1GB cache module
10000Base-Sx
IEEE 802.3ib QoS 802.3x flow control, and 802.3ap 10GBase-KR
PCI Express, four lanes (x4)
HP Integrity BL890c i2 Server Blade
14.42 in (36.63 cm)
20.05 in (50.93 cm)
8.29 in (20.82 cm)
20.28 in (51.51 cm)
26.57 in (67.49 cm)
15.94 in (40.49 cm)
106lbs. (48.08 kg)
10° to 35° C (50° to 95° F)
-40° to 60° C (-40° to 140° F)
-20° to 60° C (-4° to 140° F)
30° C (86° F)
15% to 80%
10% to 90%
10% to 90%
Page 29
