8 Replace a clean filter (A).
9 Make sure the filter is locked to its place (B).
10 Make sure the wiper (F) is centered. The wiper should be in
between the two arms (G).
11 Replace the brewer chamber. Make sure the brewer chamber
is connected to its place.
12 Replace the coffee outlet (E).
13 Press the Brewer open / close button (C) from the control
panel on the inside of the machine.
14 Close the machine door.
15 Press the confirm button. The brewer chamber moves down.
5.2.7 Cleaning/Emptying the waste bin
1 Open the machine door.
2 Lift the outlet. See cleaning instructions sticker on the waste
bin (A).
3 Take out the waste bin.
4 Clean/Empty the waste bin.
5 Replace the waste bin.
6 Lower the outlet.
7 Close the machine door.
5.2.8 Cleaning the exterior and interior
1 Clean the exterior and interior with a damp cloth.
EN
A
F
79
OptiFresh Bean
B
A
G
C
F
E
A
