OptiFresh Bean
10 Remove and clean the coffee outlet (E).
11 Make sure the wiper (F) is centered. The wiper should be in
between the two arms (G).
12 Replace the brewer chamber. Make sure the brewer chamber
is connected to its place.
13 Replace the coffee outlet (E).
14 Close the machine door.
15 Press the confirm button. The brewer chamber moves down.
5.2.6 Replacing the filter
1 Open the machine door.
2 Press the Brewer open / close button (C) from the control
panel on the inside of the machine. The brewer chamber
moves up.
3 Remove the brewer chamber (D).
4 Clean the surface of the brewer with the cleaning brush.
5 Remove the coffee outlet (E).
6 Use the filter disassembly tool (B) to loosen the filter (A).
7 Remove the filter.
2015/02 Rev. 1.0
F
78
F
E
C
D
E
A
B
A
B
G
