Chapter 1
Name
WPS
Signal Strength
Note:
1. If the Internet LED is off, please check your Internet connection first. Refer to
information about how to make Internet connection correctly. If you have already made a right connection,
please contact your ISP to make sure your Internet service is available now.
2. If the Signal Strength LED is off, please check your Internet LED first. If your Internet LED is also off, please refer
to Note 1. If your Internet LED is on, please relocate the router to a location that receives a strong mobile Internet
signal, such as near a window.
1 3 2

The Back Panel

The router's back panel shows the connection ports, buttons and antennas (view from
left to right). Refer to the following for detailed instructions.
Item
POWER
POWER ON/OFF
LAN1, LAN2, LAN3,
LAN4/WAN

LED Explanation

Status
The LED stays on for no more than 5 minutes when a WPS
On/ Off
connection is established, then turns off.
Flashing WPS connection is in progress. This may take up to 2 minutes.
Indicates the mobile Internet signal strength the router
On receives in the current location. More lit bars indicates a
better signal strength.
Off No signal. Please refer to
For connecting the router to power socket via the provided power adapter.
The switch for the power. Press it to power on or off the
For connecting to your PCs or other Ethernet network devices.
In wireless router mode, the LAN4/WAN port is used for connecting to a
Cable/FTTH/VDSL/ADSL device.
Get to Know About Your 4G LTE Router
Indication
Note 2 for troubleshooting.
Connect Your 4G LTE Router
Description
router..
for more
