Led Explanation - TP-Link Archer C3150 User Manual

Chapter 1
Name
(LED)
(Power)
(Wireless 2.4GHz)
(Wireless 5GHz)
(Internet)
(LAN)
(WPS)
(USB 3.0)
(USB 2.0)

LED Explanation

Status
All LEDs work normally.
On
All LEDs are off without affecting the router's performance.
Off
System initialization completes.
On
System initialization or firmware upgrade is in process. Do not
Flashing
disconnect or power off the router.
Power is off. Please ensure that the power adapter is connected
Off
correctly.
The wireless 2.4GHz band is working properly.
On
The wireless 2.4 GHz band is disabled.
Off
The wireless 5GHz band is working properly.
On
The wireless 5GHz band is disabled.
Off
The router is connected to the internet.
White
The WAN port is connected, but there is no internet connection.
Orange
The WAN port is not connected.
Off
At least one LAN port is connected.
On
No LAN port is connected.
Off
A wireless device has been successfully added to the network
On
by WPS function.
WPS handshaking is in process and will continue for about
2 minutes. Please press the WPS button on other wireless
Flashing
devices that you want to add to the network while the LED is
flashing.
The router is not in the WPS process.
Off
The USB device connected to the USB 3.0 port is identified and
On
ready to use.
The USB device connected to the USB 3.0 port is being
Flashing
identified.
No USB device is plugged into the USB 3.0 port or the USB
Off
device is not identified or USB device has been safely ejected.
The USB device connected to the USB 2.0 port is identified and
On
ready to use.
The USB device connected to the USB 2.0 port is being
Flashing
identified.
No USB device is plugged into the USB 2.0 port or the USB
Off
device is not identified or USB device has been safely ejected.
Get to Know Your Router
Indication
6
