TP-Link RE580D Quick Installation Manual

Quick Installation Guide

AC1900 Wi-Fi Range Extender
RE580D
Option ONE
Using your Web Browser
1
Power on
Plug the extender's adapter into an
electrical outlet near your router. Then turn
on the extender and wait until the Power
LED is lit and solid blue.
3
Configure
Launch a web browser, type
1
http://tplinkrepeater.net in the address
bar and use admin (all lowercase) for both
Username and Password to log in.
http://tplinkrepeater.net
admin
admin
If the login window does not pop up,
please refer to the FAQ > Q1.
2 Create a new username and password
for secure management purpose, and
click Confirm.
4
Relocate
1. Plug in the extender halfway between your wireless router (Host Network) and the Wi-Fi dead zone.
2. Wait for the extender to reconnect and the
Enjoy!
Both extended networks share the
if you have customized them during the configuration.
2
3
Login
LED turns solid blue. If not, relocate it closer to the router to achieve better signal quality.
Host Network
Router
same Wi-Fi passwords

LED Explanation

(RE)
Blinking: WPS connection is in process.
Solid blue: The extender has established a secure
connection, and the signal strength is adequate.
Solid orange: The extender has established a secure
connection, but the signal strength is too weak.
Off: No active connection.
(5GHz)/
On: The extender is connected to the 2.4GHz/5GHz wireless network of your host network.
Off: No connection.
Button Explanation
LED button: To turn all LEDs on or off, press the LED button.
Power button: To turn on or off the extender, press the Power button.
Connect to the Extender
via Wireless
10:31
Not connected
Connection are available
Wireless Network Connection
TP-LINK_Extender_2.4GHz
Connect automatically Connect
√
1. Unplug the Ethernet cable from your computer (if any).
2. Click the Wi-Fi icon on the taskbar and connect to the
extender's network (e.g. TP-LINK_Extender_2.4G or _5GHz).
Select your router's 2.4GHz/5GHz host
network, enter the password, and then click
Next.
2.4GHz Host Network Wireless Settings
5GHz Host Network
Please select 2.4GHz host network or skip this network.
MAC Address
SSID Signal Security
Your router wireless name 30-B5-C1-33-99-76
Host 2.4GHz Password: 12345678 Next
TP-LINK_123456 23-B5-C0-30-90-06
Exit Other... Rescan
If your router does not support 5GHz wireless
network, please click Skip to continue.
Extended Network
Ideal Extender Placement
as those of your host networks, but may have
(2.4GHz)
via Ethernet Cable
or
1. Disable the Wi-Fi on your computer.
2. Connect your computer to the extender via an Ethernet cable.
4 Either keep the default SSIDs or customize
them for the extended networks, and then
click Next.
2.4GHz Host Network
Summary
5GHz Host Network
Your network name
Extended 2.4GHz SSID:
Hide SSID broadcast
Note: The extended 2.4GHz password is the same as your Host password.
Extended 5GHz SSID: Your network name_5G
Hide SSID broadcast
Note: The extended 5GHz password is the same as your Host password.
Skip
5 Verify your wireless settings and click Finish.
Corresponding LED(s) (
should turn solid on.
Clients
different wireless network names
(Ethernet)
On: The Ethernet port is connected.
Off: The Ethernet port is not connected.
(Power)
On: The extender is on.
Blinking: The extender is initializing.
Off: The extender is off.
Wireless Settings
Summary
Copy Host SSID
Copy Host SSID
Back Next
2.4GHz/ 5GHz)
