6

PROFIBUS DEVICE DATA

6.1

Device data (GSD file)

A GSD file is required to connect the inverter (FR-A8NP) to the Profibus network and use Profibus configuration software. The
GSD file contains information on the communication setting of the inverter (FR-A8NP).
GSD file can be downloaded from the web site.
Mitsubishi Electric FA Site
www.MitsubishiElectric.co.jp/fa
The download is free.
Contact your sales representative for details.
When editing this file, use a text editor.
For installation instructions, refer to the instruction manual of the PROFIBUS-DP Configuration Software.
Although this product complies with PPO type specification, it includes specifications which do not support PPO type
specification (FR-A5NP intercompatibility protocol). This manual states the section supporting PPO type specification as PPO
type support specification and the section not supporting PPO type as PPO type non-support specification.
NOTE
• You cannot use the device data which does not include PPO supporting specification (data for the FR-A5NP).
